10-Port Lite Managed Multi-Gigabit Switch

QNAP QSW-L2110-10T

The QSW-L2110-10T combines eight 2.5GbE RJ45 ports with two 10GbE BASE-T RJ45 ports for endpoint access, high-speed uplinks and direct connections to critical devices. Its Lite Managed feature set includes VLAN, QoS, LACP, port mirroring, IGMP Snooping and practical traffic controls through an intuitive web interface.

What is the QNAP QSW-L2110-10T?

It is a 10-port Lite Managed desktop switch designed to remove bandwidth bottlenecks for Wi-Fi 6, Wi-Fi 6E and Wi-Fi 7 access points, NAS devices, servers and workstations. The compact, fanless metal enclosure supports quiet office or studio deployment, while QSS provides web-based management and online firmware checks.

8 x 2.5GbEMulti-Gigabit RJ45 ports for endpoint devices

2 x 10GbEBASE-T RJ45 ports for uplinks, NAS or servers

80GbpsSwitching capacity with 40Gbps non-blocking throughput

FanlessQuiet desktop operation in a compact metal enclosure

Smarter Network Management Without Full Layer 2 Complexity

Practical controls for SMBs, studios and advanced home networks.

Lite Managed switching provides more control than an unmanaged switch while remaining simpler to operate than a full Layer 2 managed model. The QSW-L2110-10T supports traffic segmentation, bandwidth prioritisation, link aggregation and traffic monitoring without adding unnecessary management complexity.

Its web-based interface helps simplify everyday configuration and network monitoring, making it suitable for users who need control over key connections without a complex setup.

Flexible 2.5GbE and 10GbE Network Architecture

Use the two port speeds together to support endpoint access and backbone traffic.

10GbE Uplink Backbone

Connect Wi-Fi 6/6E/7 access points and workstations through the 2.5GbE ports, then use 10GbE to link to a core switch or server-room backbone. This aggregates traffic for environments with multiple simultaneous users.

Direct 10GbE Device Connection

Where uplink requirements are lower, the 10GbE ports can connect directly to critical devices such as a NAS or server, while the eight 2.5GbE ports continue serving endpoint devices.

Traffic, Bandwidth and Packet Controls

Manage important connections and organise traffic using supplied Lite Managed features.

LACP

Combines multiple network connections into a single high-speed link to increase total bandwidth.

VLAN

Segments departmental or device networks for more organised traffic management.

QoS, CoS and DSCP

Prioritises performance-sensitive traffic such as VoIP and video streaming.

IGMP Snooping

Manages multicast streams to help prevent packet loss or duplication during audio and video delivery.

Port Mirroring

Supports practical traffic monitoring as part of the Lite Managed feature set.

Web Management

An intuitive web interface simplifies configuration and day-to-day network monitoring.

Quiet, Efficient and Easy to Maintain

Designed for desktop deployment in offices, studios and workspaces.

Fanless Metal Enclosure

The full-metal enclosure supports heat dissipation and long-term stability, while the fanless design keeps operation quiet.

Energy Efficient Ethernet

IEEE 802.3az EEE support automatically adjusts power use according to network traffic.

Online Firmware Updates

QSS supports online firmware checks and Qfinder Pro for one-click updates.

Switch Type Comparison

Compare the supplied management levels, benefits and recommended applications.

Switch Type	Key Features	Management Benefits	Recommended Use Cases
Lite Managed	LACP, VLAN, QoS, Port Mirroring	Easy traffic control and bandwidth segmentation	SMBs, retail and basic multi-device segments
L2 Managed	ACL, SNMP, RSTP	Advanced security and diagnostics	Virtualisation, storage networks and campus backbones
Unmanaged	EEE, Flow Control, Loop Protection	Plug-and-play operation with no maintenance	Homes, small offices and quick meeting-room setups

Frequently Asked Questions

Quick answers about the QNAP QSW-L2110-10T.

How many network ports does the QSW-L2110-10T have?

It has ten RJ45 ports: eight 2.5GbE ports and two 10GbE BASE-T ports.

Can the 10GbE ports be used for devices instead of uplinks?

Yes. The two 10GbE ports can be used for uplinks or connected directly to devices such as a NAS or server.

Is the QSW-L2110-10T fanless?

Yes. It uses a fanless desktop design for quiet deployment in offices, studios and workspaces.

Which management features are included?

The supplied information includes VLAN, QoS, CoS, DSCP, LACP, Port Mirroring, IGMP Snooping, flow control and web-based management.

Does it support Energy Efficient Ethernet?

Yes. It supports IEEE 802.3az Energy Efficient Ethernet, which adjusts power use according to network traffic.

How are firmware updates managed?

QSS supports online firmware checks and Qfinder Pro for one-click updates.

What is the warranty period?

The supplied datasheet lists a two-year warranty.

Product note: Product images are for illustrative purposes only and may differ from the actual product. Designs and specifications are subject to change without notice.

(QSW-L2110-10T)

QNAP QSW-L2110-10T Specifications

Review the ports, switching performance, management, power, physical and environmental specifications.

Specification	Details
Product and Management
Model	QSW-L2110-10T
Management Type	Lite Managed
Number of Ports	10
Management Interface	Web
Console	RJ45
Network Interfaces
10GbE BASE-T (RJ45)	2 ports 10G/5G/2.5G/1G/100M
2.5GbE (RJ45)	8 ports
Switching Performance
MAC Address Table	16K
Total Non-Blocking Throughput	40Gbps
Switching Capacity	80Gbps
Jumbo Frames	12K
Standards and Features
Energy Efficient Ethernet	Yes - IEEE 802.3az compliant
Fanless	Yes
Supported Standards	IEEE 802.3 Ethernet IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3bz 2.5G/5GBASE-T IEEE 802.3an 10GBASE-T IEEE 802.3x Full-Duplex Flow Control IEEE 802.1Q VLAN Tagging IEEE 802.3ad LACP IEEE 802.1p Class of Service IEEE 802.3az EEE
Power
Power Supply Description	Adapter
Input Power Type	DC
Input Voltage Range	12V/1.5A
Maximum Power Consumption	18W
Physical Specifications
Form Factor	Desktop
LED Indicators	Per port: Speed/Link/Activity Per system: Power/Loop
Buttons	Reset button
Dimensions (H x W x D)	27 x 240 x 105 mm
Weight (Net)	0.69 kg
Weight (Gross)	0.989 kg
Operating Environment and Compliance
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	10-95% non-condensing
Certifications	CE, VCCI, BSMI, FCC, ICES, RCM, UKCA, LVD
Electromagnetic Compliance	Class B
Warranty	2 years
