SKU: QSW-L2110-2S8T
The QNAP QSW-L2110-2S8T is a cost-effective Lite Managed switch with eight 2.5GbE Base-T ports and two 10GbE SFP+ ports. It combines high-speed endpoint connectivity, 10GbE uplinks and practical management features in a compact, fanless desktop design.
The QSW-L2110-2S8T is a 10-port Lite Managed switch designed for homes, advanced home users and small-to-medium businesses that need more control than an unmanaged switch without the complexity of a full Layer 2 managed model. It provides VLAN, QoS, LACP, port mirroring, IGMP Snooping and browser-based management through an intuitive Web GUI.
Build a flexible network for endpoint access, traffic aggregation and high-bandwidth devices.
Connect Wi-Fi 6, Wi-Fi 6E or Wi-Fi 7 access points and workstations through the 2.5GbE ports, then use the 10GbE SFP+ ports to connect to a core switch or server-room backbone. This arrangement aggregates traffic from multiple users through the higher-speed uplink.
When a dedicated backbone uplink is not required, the 10GbE SFP+ ports can connect directly to critical devices such as a NAS or server, while the eight 2.5GbE ports continue serving endpoint devices.
Essential management functions without the complexity of a full Layer 2 managed switch.
The QSW-L2110-2S8T combines 2.5GbE and 10GbE connectivity to support a staged upgrade to a higher-speed network. Existing devices can remain connected while 10GbE is introduced for uplinks, NAS systems, servers or other high-bandwidth connections.
Lite Managed switching provides more control than an unmanaged switch while maintaining simpler administration than a full Layer 2 managed model. It is suited to SMBs, studios and advanced home users seeking straightforward traffic control, segmentation and bandwidth management.
Organise traffic, prioritise important applications and manage available bandwidth.
Link Aggregation Control Protocol combines multiple network connections into a single high-speed link to increase total available bandwidth.
Virtual LAN support enables logical segmentation of departmental or device networks for more organised traffic management.
Traffic prioritisation helps ensure that performance-sensitive applications such as VoIP and video streaming receive sufficient resources.
IGMP Snooping manages multicast streams to help prevent packet loss or duplication during audio and video streaming.
Port mirroring is included among the Lite Managed functions for practical traffic management and observation.
Port management allows flow control to be configured alongside port speed, connection and duplex information.
Complete everyday configuration and monitoring through a clear browser interface.
View real-time system information, port connection status, activation status and traffic usage from the dashboard.
Review port status, connection speed and duplex mode, and configure flow control from the Web GUI.
QSS supports online firmware checks and Qfinder Pro, enabling straightforward one-click firmware updates.
Designed for placement in offices, studios and other shared workspaces.
The fanless design supports quiet operation without disrupting everyday office or studio tasks.
The full-metal enclosure provides robust protection and thermal performance during high-speed network access.
Energy Efficient Ethernet automatically adjusts power usage according to network traffic while maintaining network performance.
Compare the supplied management characteristics of Lite Managed, Layer 2 managed and unmanaged switches.
| Switch Type | Key Features | Management Benefits | Recommended Uses |
|---|---|---|---|
| Lite Managed | LACP, VLAN, QoS and port mirroring | Easy traffic control and bandwidth segmentation | SMBs, retail and basic multi-device segments |
| Layer 2 Managed | ACL, SNMP and RSTP | Advanced security and diagnostics | Virtualization, storage networks and campus backbones |
| Unmanaged | EEE, flow control and loop protection | Plug-and-play operation with no management requirements | Homes, small offices and quick meeting-room setups |
Answers to common questions about the QNAP QSW-L2110-2S8T.
It has ten ports in total: eight 2.5GbE RJ45 ports and two 10GbE SFP+ ports.
Yes. The two 10GbE SFP+ ports can be used for uplinks or connected directly to high-bandwidth devices such as a NAS or server.
Lite Managed switching provides practical functions such as LACP, VLAN, QoS and port mirroring, with simpler administration than a full Layer 2 managed switch.
Yes. IEEE 802.1Q VLAN tagging is supported for logical network segmentation and more organised traffic management.
Yes. It uses a fanless design for quiet operation in offices, studios and other shared workspaces.
The switch is managed through an intuitive Web GUI. The interface provides system information, port status, traffic usage and configuration controls.
The supplied datasheet specifies an 80Gbps switching capacity and 40Gbps total non-blocking throughput.
The supplied datasheet lists a two-year warranty.
Product images are for illustrative purposes only and may differ from the actual product. Product colours may appear different due to monitor settings. Designs and specifications are subject to change without notice.
(QSW-L2110-2S8T)
Review the ports, switching performance, management, power, physical and environmental specifications.
| Specification | Details |
|---|---|
| Product and Management | |
| Model | QSW-L2110-2S8T |
| Management Type | Lite Managed |
| Management Interface | Web |
| Console | RJ45 |
| Form Factor | Desktop |
| Network Interfaces | |
| Number of Ports | 10 |
| 10GbE SFP+ | 2 |
| 2.5GbE RJ45 | 8 |
| Switching Performance | |
| Switching Capacity | 80Gbps |
| Total Non-Blocking Throughput | 40Gbps |
| MAC Address Table | 16K |
| Jumbo Frames | 12K |
| Management Features | |
| Link Aggregation | LACP |
| VLAN | IEEE 802.1Q VLAN tagging |
| Traffic Prioritisation | QoS, CoS and DSCP |
| Multicast Management | IGMP Snooping |
| Additional Management Features | Port mirroring, port status monitoring, duplex mode configuration and flow control |
| Firmware Management | Online firmware checks and Qfinder Pro with one-click updates |
| Supported Standards | |
| Ethernet Standards |
|
| Energy Efficient Ethernet | Yes, IEEE 802.3az |
| Power and Cooling | |
| Power Supply | Adapter |
| Input Power Type | DC |
| Input Voltage Range | 12V/1A |
| Maximum Power Consumption | 12W |
| Fanless | Yes |
| Physical Specifications | |
| Dimensions (H × W × D) | 27 × 240 × 105mm |
| Net Weight | 0.63kg |
| Gross Weight | 0.89kg |
| LED Indicators | Per port: speed, link and activity Per system: power and loop |
| Buttons | Reset button |
| Operating Environment | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Relative Humidity | 10–95%, non-condensing |
| Compliance and Warranty | |
| Certifications | CE, VCCI, BSMI, FCC, ICES, RCM, UKCA and LVD |
| Electromagnetic Compliance | Class B |
| Warranty | 2 years |
QNAP reserves the right to replace parts or accessories when the original is no longer available from its manufacturer or supplier. Replacement components are tested and verified for compatibility, stability and equivalent performance.
Product images are for illustrative purposes only and may differ from the actual product. Product colours may appear different due to monitor settings. Designs and specifications are subject to change without notice.
| SKU | QSW-L2110-2S8T |
| Brand | QNAP |
| Shipping Weight | 1.4000kg |
| Shipping Width | 0.320m |
| Shipping Height | 0.220m |
| Shipping Length | 0.060m |
| Shipping Cubic | 0.002940000m3 |
