Overview

Dimensions

Device with wall mount: 93.5 x 22.5 x 24.7 mm (3.7 x 0.89 x 0.97") Device with corner mount: 93.5 x 22.5 x 27.9 mm (3.7 x 0.89 x 1.1")

Mounting

Adhesive and screw mount

UniFi Application Suite

Protect

Performance

Connectivity

SuperLink (Proprietary)

Operating Frequency

US

915.6–927.6 MHz

EU

865.1–869.5 MHz

Antenna Gain

SuperLink

1 dBi

Max. TX Power

SuperLink

14 dBm

Max. Range

SuperLink

2 km (1.2 mi)

Sensor Features

Horizontal PIR Sensor

Detection range up to 1.5 m (4.9 ft)

Vertical PIR Sensor

Detection range up to 6 m (19.7 ft) with pet immunity

Hardware

Max. Power Consumption

22.6mW

Supported Voltage Range

3V

Power Method

Lithium battery CR123A

Battery Life

Up to 6 years

Weight

45 g (1.6 oz)

Enclosure Material

Polycarbonate, high-density polyethylene (HDPE)

Mount Material

Polycarbonate

Buttons

(1) Factory reset (1) Function button (1) Tamper switch

LEDs

(1) Status: R/B/W (1) Signal: B/R

Ambient Operating Temperature

0 to 40° C (32 to 104° F)

Ambient Operating Humidity

10 to 90% noncondensing

Certifications

FCC, IC, CE

NDAA Compliant

✓

Software

Application Requirements

Web Application

UniFi Protect

Mobile App

UniFi Protect iOS™ and Android™
