QNAP QGD-3014-16PT-8G

QNAP QGD-3014-16PT-8G 16-Port GbE PoE Managed Switch with 8GB Memory

A rackmountable QNAP managed PoE switch combining 16 GbE switch ports, Intel Celeron J4125 processing, 8GB DDR4 memory and supplied SATA and M.2 storage positions.

Switch ports16 × GbE

Installed memory8GB DDR4

Storage positions4 SATA + 2 M.2

InstallationRackmountable

Switching and PoE connectivity

14 × GbE RJ45 ports
2 × GbE SFP/RJ45 combo ports
30W is listed for ports 116
32Gbps switching capacity and 16Gbps non-blocking throughput

Integrated compute, management and storage

Intel Celeron J4125 four-core processor, 2.0GHz up to 2.7GHz
8GB DDR4 installed as 2 × 4GB, with up to 64GB stated
4GB flash memory
4 × 3.5-inch SATA drive positions and 2 × M.2 B-key SATA 2230 positions
2 × 2.5GbE management ports, 2 × HDMI, 3 × USB 3.2 and 2 × PCIe Gen3 x4

Need help choosing the right NAS?

Compare NAS types, storage planning and buying considerations in the DeviceDeal NAS Buying Guide.

Read NAS Buying Guide

Deployment details to confirm

The supplied row does not state the total PoE budget, power specifications, dimensions, software feature set, included accessories or drive inclusion. Confirm these requirements for the intended deployment before purchase.

Frequently asked questions

Quick answers based on the supplied information for QGD-3014-16PT-8G.

How are the 16 switch ports arranged?

The supplied specification lists fourteen GbE RJ45 ports and two GbE SFP/RJ45 combo ports.

Which ports provide PoE?

The source lists PoE output for ports 116, with 30W stated. It does not specify the total PoE budget.

What processor and memory are supplied?

The product data lists an Intel Celeron J4125 four-core processor and 8GB DDR4 installed as two 4GB modules, with up to 64GB stated.

What storage positions are included?

The supplied information lists four 3.5-inch SATA drive positions and two M.2 B-key SATA 2230 positions.

What management and expansion connections are listed?

The source lists two 2.5GbE management ports, two HDMI ports, three USB 3.2 ports and two PCIe Gen3 x4 expansion positions.

What warranty applies to the QGD-3014-16PT-8G?

The product is covered by the applicable QNAP manufacturer warranty, but no warranty duration is stated in the supplied product information.

(QGD-3014-16PT-8G)

Features and highlights

QNAP QGD-3014-16PT-8G 16-Port GbE PoE Managed Switch with 8GB Memory

16 GbE switch ports

Combines fourteen GbE RJ45 ports with two GbE SFP/RJ45 combo ports.

PoE across ports 116

The supplied data lists 30W for ports 1 through 16.

Integrated storage positions

Includes four 3.5-inch SATA positions and two M.2 B-key SATA 2230 positions.

Compute and expansion

Uses an Intel Celeron J4125, 8GB DDR4 and two PCIe Gen3 x4 positions.

Key details to check before purchase

16-port arrangement: 14 × GbE RJ45 plus 2 × GbE SFP/RJ45 combo
Installed memory: 8GB DDR4 as 2 × 4GB
Switching capacity: 32Gbps; non-blocking throughput: 16Gbps
Confirm PoE budget, drive inclusion, power and dimensions before deployment

QNAP QGD-3014-16PT-8G 16-Port GbE PoE Managed Switch with 8GB Memory specifications

Technical information below is organised from the supplied product data.

Specification	Details
Product Details
Brand	QNAP
SKU	QGD-3014-16PT-8G
Product Type	Rackmountable managed PoE switch with integrated storage positions
Installation	Rackmountable
Processor and Memory
Processor	Intel Celeron J4125, 4-core, 2.0GHz up to 2.7GHz
Installed Memory	8GB DDR4 (2 × 4GB)
Stated Memory Support	Up to 64GB
Flash Memory	4GB
Storage
Drive Positions	4 × 3.5-inch SATA
M.2 Positions	2 × M.2 B-key SATA 2230
Networking and PoE
Switch Ports	14 × GbE RJ45; 2 × GbE SFP/RJ45 combo
Management Ports	2 × 2.5GbE
PoE Output	Ports 116; 30W stated
Switching Capacity	32Gbps
Non-Blocking Throughput	16Gbps
Other Interfaces and Expansion
HDMI	2
USB 3.2	3
PCIe Expansion	2 × PCIe Gen3 x4

The supplied PoE wording states ports 116 and 30W, but does not identify the total PoE power budget.

Power specifications, dimensions, included accessories, drive inclusion and warranty duration were not supplied.

SKU	QGD-3014-16PT-8G
Model #	QGD-3014-16PT
Brand	QNAP
Shipping Weight	2.9400kg

QNAPManufacturer warranty

QNAP manufacturer warranty

The QNAP QGD-3014-16PT-8G is supplied with the applicable QNAP manufacturer warranty.

No warranty duration was included in the supplied product information. Warranty coverage, eligibility and claim assessment are subject to QNAP terms. Please retain your DeviceDeal tax invoice as proof of purchase.
