StarTech 1 Port PCIe DP Parallel Adapter Card - PEX1P
Model # PEX1P
-
SKU: PEX1P
- Pick Up Available
- Australian Warranty
- Checkout Securely
The PEX1P PCIe Parallel Adapter card can be installed in a PCI Express (PCIe) slot, allowing you to connect EPP/ECP parallel peripherals to any computer system. Relying on a native single-chip design(Oxford OXPCIe952), this adapter harnesses the true capability of PCI Express - ensuring maximum performance and reliability.
This high performance SPP/EPP/ECP parallel card adds one DB25 parallel port, perfect for connecting printers, scanners, CD-R/RW drives, memory card readers, bar code scanners and more. With the added convenience of plug and play capability, installing the parallel adapter card is hassle-free!
The PCIe Parallel Adapter card includes both standard and half-height/low profile mounting brackets and is backed by a StarTech.com two year warranty and free lifetime technical support.
Applications
- Connects any parallel peripheral including printers, scanners, CD-R/RWs, Zip® drives, and memory card readers.
The StarTech.com Advantage
- Standard and low profile bracket included allowing install into almost any system
- Use existing parallel devices with PCI Express systems saving the cost and hassle of upgrading peripherals to work with newer systems
- Supports SPP, EPP and ECP communication modes for maximum compatibility with your parallel peripherals
(PEX1P)
| Warranty Information | ||
|---|---|---|
| Warranty | 2 Years | |
| Hardware | ||
| Bus Type | PCI Express | |
| Card Type | Standard Profile (LP bracket incl.) | |
| Chipset ID | PLX/Oxford - OXPCIe952 | |
| Interface | Parallel | |
| Port Style | Integrated on Card | |
| Ports | 1 | |
| Performance | ||
| Maximum Data Transfer Rate | 2.5 Mbps | |
| MTBF | 26,297 Hours | |
| Connector(s) | ||
| Connector Type(s) | 1 - PCI Express x1 Male | |
| External Ports | 1 - DB-25 (25 pin, D-Sub) Female | |
| Software | ||
| OS Compatibility | Windows® CE 6.0 / 5.0, 95, 98SE, 2000, XP, XP Embedded, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 Linux 2.4.x to 4.11.x LTS Versions only | |
| Physical Characteristics | ||
| Product Height | 4.7 in [12 cm] | |
| Product Length | 0.8 in [21 mm] | |
| Product Width | 4.3 in [11 cm] | |
| Weight of Product | 1.5 oz [42 g] | |
| Packaging Information | ||
| Package Height | 1.2 in [30 mm] | |
| Package Length | 6.7 in [17 cm] | |
| Package Width | 5.6 in [14.3 cm] | |
| Shipping (Package) Weight | 4.7 oz [133 g] | |
| What's in the Box | ||
| Included in Package | 1 - PCI Express Parallel Card | |
| 1 - Low Profile Bracket | ||
| 1 - Driver CD | ||
| 1 - Instruction Manual | ||
| SKU | PEX1P |
| Barcode # | 65030824170 |
| Brand | Startech |
| Shipping Weight | 0.1300kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.170m |
| Shipping Cubic | 0.000850000m3 |
