STARTECH.COM | FPWARTB2

Full-Motion TV Wall Mount for 3270in Displays

Mount one VESA-compatible 3270in flat or curved display weighing up to 45kg, with dual-arm extension, swivel, tilt and screen levelling.

3270in, up to 45kg

Supports one VESA-compatible flat or curved display within the verified size and weight limits.

Articulating adjustment

Dual arms extend from 57 to 517.5mm, swivel ±90°, tilt +5°/-8° and provide ±5° levelling.

Verified VESA support

Includes mounting hardware for the listed VESA patterns: 200×100; 200×200; 200×300; 200×400; 300×200; 300×300; 400×200; 400×300; 400×400; 600×200; 600×300; 600×400mm.

What to know

Confirm the display size, weight and exact VESA pattern before installation. The wall structure and selected fasteners must safely support the entire installed load. Follow the supplied instructions and local building requirements; professional installation may be appropriate.

Australian supply and warranty: Supplied by DeviceDeal as an Australian-market product with the official 5-year StarTech.com manufacturer warranty in Australia. Keep your DeviceDeal tax invoice; terms, eligibility and product assessment apply.

Frequently asked questions

Which displays fit the FPWARTB2?

It supports one flat or curved VESA-compatible display within the verified 3270in and 45kg limits.

Which VESA patterns does the FPWARTB2 support?

It supports 200×100; 200×200; 200×300; 200×400; 300×200; 300×300; 400×200; 400×300; 400×400; 600×200; 600×300; 600×400mm.

How can the FPWARTB2 display be adjusted?

Its dual arms extend from 57 to 517.5mm, swivel ±90°, tilt +5°/-8° and provide ±5° screen levelling.

How far does the FPWARTB2 sit from the wall?

Approximately 57mm minimum to 517.5mm maximum from the wall

Can the FPWARTB2 hold a curved display?

Yes, provided the display meets the supported size, weight and VESA requirements.

Does the FPWARTB2 include cable management?

Yes. It has integrated cable management to help keep display cables organised.

What should be checked before installing the FPWARTB2?

Confirm the display size, weight and VESA pattern, and ensure the wall and fasteners safely support the complete installed load.

What warranty applies to the FPWARTB2?

It is supplied by DeviceDeal as an Australian-market product and is backed by a 5-year StarTech.com manufacturer warranty in Australia.

Not sure this is the right product for your setup? Visit the DeviceDeal Buying Guides.

(FPWARTB2)

Features and highlights

Single-display wall mount for 3270in flat or curved screens
Maximum display weight 45kg
Supported VESA patterns: 200×100; 200×200; 200×300; 200×400; 300×200; 300×300; 400×200; 400×300; 400×400; 600×200; 600×300; 600×400mm
Arm extension from 57 to 517.5mm; up to 880mm total lateral range
Display swivel ±90°, tilt +5°/-8° and screen levelling ±5°
Approximately 57mm minimum to 517.5mm maximum from the wall
±5° screen-level adjustment
Integrated cable management
Powder-coated black steel construction
5-year StarTech.com manufacturer warranty

Compatibility check: Use only with a display within the stated 3270in, 45kg and VESA limits. Confirm the wall structure, fasteners, clearance and local installation requirements before mounting.

Specifications

Product type	Full-motion articulating single-display TV wall mount
Supported display size	3270in
Weight capacity	45kg
Supported display types	Flat and curved VESA-compatible displays
VESA patterns	200×100; 200×200; 200×300; 200×400; 300×200; 300×300; 400×200; 400×300; 400×400; 600×200; 600×300; 600×400mm
Arm extension	57517.5mm
Total lateral range	Up to 880mm
Display swivel	+90° / -90°
Display tilt	+5° / -8°
Distance from wall	Approximately 57mm minimum to 517.5mm maximum from the wall
Screen levelling	±5° screen-level adjustment
Cable management	Integrated
Construction	Powder-coated black steel
Product dimensions	Approximately 64.3 × 51.7 × 41.8cm (L × W × H)
Product weight	Approximately 6.8kg
Environmentally friendly	Yes, as listed in the supplied catalogue
In the box	Wall-mount assembly, display brackets, mounting hardware, tools and instruction manual
Warranty	5-year StarTech.com manufacturer warranty

SKU	FPWARTB2
Barcode #	65030870368
Brand	Startech
Shipping Weight	7.7000kg
Shipping Width	0.420m
Shipping Height	0.090m
Shipping Length	0.625m
Shipping Cubic	0.023625000m3

Warranty and Australian supply

FPWARTB2 is supplied by DeviceDeal as an Australian-market product and carries the official 5-year StarTech.com manufacturer warranty in Australia.

Keep your DeviceDeal tax invoice as proof of purchase. Warranty service is subject to StarTech.com terms, eligibility requirements and product assessment.
