DiskStation

DS223

Name: Synology DiskStation DS223 2-Bay 3.5" Diskless 1xGbE NAS (Tower) (HMB)
Brand: SYNOLOGY
SKU: DS223
Price: 488 AUD
Availability: InStock

Enterprise-grade diskstation storage solution

DS223 is 30% faster in photo indexing than its predecessor 30% faster photo indexing Data protection Safeguard digital memories and important projects with intuitive backup tools.

Uncompromising performance

Throughput

1x 1GbE LAN ports

Scalability

2 drive bays

CPU

4-core Realtek RTD1619B @ 1.7 GHz

Memory

2 GB DDR4 non-ECC

Private cloud made easy

Import data from PCs, Macs, and other external storage devices at a 14% faster rate and keep all your devices in sync for smoother file management.Learn more

Your data is in safe hands

Not all data storage is created equal. Synology DiskStation Manager (DSM), the operating system that powers the DS223, leverages the efficient Btrfs file system to protect your data against data corruption and roll back any accidental or malicious changes thanks to the snapshot technology.Learn more

Versatile NAS for the modern home

Configure your DS223 to best suit your needs thanks to a host of complete solutions designed for every scenario.

Protect your data platform

Add an extra layer of protection to your files with one of the built-in, license-free solutions available to back up your DS223.

Works best with Synology drives

Leverage high sustained performance and reliability with well-engineered drives designed specially for Synology systems.

More ways to harness your NAS

Synology NAS brings speed, simplicity, and security to all your creative projects.

Powered by Synology DiskStation Manager

Enterprise-grade software solutions included

Access from any device

Get to your files from PC, Mac, Linux, Chromebook, Android, iOS, or any device equipped with a browser. Keep your data private or easily share it using secure links.

Save storage space

Save space on your personal devices by only synchronizing the files you need from your Synology system. Pin frequently accessed files for convenient offline accessibility.

Integrate with the cloud

Sync files between your private cloud and public cloud services, including Google Drive, Dropbox, and Microsoft OneDrive. Retain local copies of your cloud data for centralized management and data own

Sync across locations

Say goodbye to long waits while downloading or uploading files. Continuously synchronize content between two Synology devices to enable fast local access at any location, no matter the amount of data.

Photo management

Store and organize photos, albums, and other media with smart and intuitive features. Leverage privacy-focused options to share media securely with friends, family, or colleagues.

Data protection

Safeguard digital memories and important projects with intuitive backup tools.

(DS223)

Technical Specifications

Complete hardware and software specifications

CPU

CPU Model Realtek RTD1619B

CPU Quantity 1

CPU Cores 4

CPU Threads 4

CPU Architecture 64-bit

CPU Frequency 1.7 GHz

Hardware Encryption Engine Yes

Memory

System Memory 2 GB DDR4 non-ECC

Notes Synology may revise pre-installed memory module specifications in response to component lifecycle and supply conditions. All revised components undergo the same rigorous validation to ensure equivalent compatibility, stability, and performance.

Storage

Drive Bays 2

Drive Type(See all supported drives) 3.5" SATA HDD 2.5" SATA SSD

Hot Swappable Drive* Yes

External Ports

RJ-45 1GbE LAN Port 1

USB 3.2 Gen 1 Port 3

USB Copy Yes

Notes MTU value of 1GbE LAN port has a limit of 1500.

Appearance

Size (Height x Width x Depth) 165 mm x 108 mm x 232.7 mm

Weight 1.28 kg

Others

System Fan 92 mm x 92 mm x 1 pcs

Fan Speed Mode Full-Speed Mode Cool Mode Quiet Mode

Brightness Adjustable Front LED Indicators Yes

Power Recovery Yes

Noise Level* 14.6 dB(A)

Scheduled Power On / Off Yes

Wake on LAN / WAN Yes

Power Supply Unit / Adapter 60 watts

AC Input Power Voltage 100V to 240V AC

Power Frequency 50/60 Hz, Single Phase

Power Consumption 17.343 watts (Access) 4.08 watts (HDD Hibernation)

British Thermal Unit 59.19 BTU/hr (Access) 13.92 BTU/hr (HDD Hibernation)

Notes For more information on how power consumption is measured, refer to this article . Noise testing was conducted with the Synology system fully installed with Synology SATA SSDs and in an idle state. Two G.R.A.S. type 40AE microphones were placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%.

Temperature

Operating Temperature 0°C to 40°C (32°F to 104°F)

Storage Temperature -20°C to 60°C (-5°F to 140°F)

Operating Humidity 8% to 80% RH

Storage Humidity 5% to 95% RH

Certification

Certification FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS

Warranty

Warranty 2-year hardware warranty

Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) In the event that a valid receipt of purchase of Product or Product invoice is not presented, or is apparently erroneous or falsified, the Warranty Period for the presented Product shall commence from the manufacturing date in accordance with Synology's internal records.

Environment

Environment RoHS Compliant

Packaging Content

Packaging Content Main Unit X 1 Accessory Pack X 1 AC Power Adapter X 1 AC Power Cord X 1 RJ-45 LAN Cable X 1 Quick Installation Guide X 1

Optional Accessories

Optional Accessories Enterprise Series 3.5" SATA HDD: HAT5300 Series Plus Series 3.5" SATA HDD: HAT3300 Series Enterprise Series 2.5" SATA SSD: SAT5200 Series

Storage Management

Maximum Single Volume Size 108 TB

Maximum Internal Volume Number 64

SSD TRIM Yes

Supported RAID Type Synology Hybrid RAID Basic JBOD RAID 0 RAID 1

RAID Migration Basic to RAID 1

Volume Expansion with Larger HDDs Synology Hybrid RAID RAID 1

Notes Actual maximum storage pool and volume sizes depend on drive sizes used, the number of drive bays available, and the RAID configuration. Usable capacity for each volume will be lower than the maximum volume size and is dependent on the filesystem and the amount of system metadata stored.

File System

Internal Drives Btrfs ext4

External Drives Btrfs ext4 ext3 FAT32 NTFS HFS+ exFAT

File Services

File Protocol SMB AFP NFS FTP WebDAV Rsync

Maximum Number of SMB Connections (FSCT-Based) 5

Windows Access Control List (ACL) Integration Yes

NFS Kerberos Authentication Yes

Notes Connection value of this model is tested with Synology SATA HDD fully populated and all onboard network ports SMB performance was evaluated using Microsoft File Server Capacity Tool (FSCT) version 1.3, with the following configuration: Test workload: HomeFolder scenario provided by the FSCT tool Test duration: 600 seconds Domain controller & FSCT controller: Windows Server 2022 FSCT clients: 8 × Windows 10 machines SMB feature: Directory leasing enabled

Account & Shared Folder

Maximum Local User Accounts 256

Maximum Local Groups 64

Maximum Shared Folder 64

Maximum Shared Folder Sync Tasks 2

Hyper Backup

Data & Folder Backup Yes

Log Center

Syslog Events per Second 400

General Specifications

Supported Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Supported Browsers Chrome Firefox Edge Safari

Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文

Notes For an updated list of supported browser versions, check the DSM Technical Specifications .

Synology Chat

Synology Chat Yes

Download Station

Maximum Concurrent Download Tasks 80

SAN Manager

Maximum iSCSI Target Number 2

Maximum LUN 4

LUN Clone/Snapshot, Windows ODX Yes

Media Server

DLNA Compliance Yes

Synology Photos

Facial Recognition Yes

Snapshot Replication

Maximum Snapshots per Shared Folder 128

Maximum Snapshots per LUN 32

Maximum Snapshots per System 1,024

Maximum Replication Tasks for Shared Folders 16

Maximum Replication Tasks for LUNs 8

Maximum Replication Tasks per System 16

Surveillance Station

Default Licenses 2 (Additional cameras require purchase of licenses)

Maximum IP Cameras and Total FPS (H.264) 1080p: 20 channels, 460 FPS 3M: 20 channels, 300 FPS 5M: 15 channels, 150 FPS 4K: 11 channels, 110 FPS

Maximum IP Cameras and Total FPS (H.265) 1080p: 20 channels, 500 FPS 3M: 20 channels, 400 FPS 5M: 20 channels, 350 FPS 4K: 20 channels, 200 FPS

Notes Performance figures are obtained from testing conducted with the device fully populated with drives, with their default memory configuration, and under a continuous recording setup. Actual system capabilities may vary based on configuration, drive performance, enabled features, and the presence of additional workloads. Use NVR Selector to quickly find a suitable model based on your requirements. The number of video channels that can be viewed simultaneously is double the maximum number of cameras for the same codec and resolution.

Synology Drive

Maximum Number of Users 5

Maximum Number of Hosted Files 100,000 (applies to files indexed or hosted by Synology Drive . For file access through other standard protocols, refer to the File Services section above)

Notes The suggested maximum number of users is based on the following workload: 20% of users randomly perform file operations (upload, download, move, and delete), and 80% of users are logged in but idle. Learn more Models with SSD support are tested with a single SSD volume. Exceeding the recommended numbers above will not block application operations, but may result in longer response time. Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.

Synology Office

Maximum Number of Users 5

Notes The suggested maximum number of users is based on the following workload: 20% of users are executing random actions at an average of 30-second intervals, and 80% of users are logged in and viewing a file. Learn more Models with SSD support are tested with a single SSD volume. Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM

VPN Server

Maximum Connections 2

SKU	DS223
Barcode #	846504004775
Brand	SYNOLOGY
Shipping Weight	2.7000kg
Shipping Width	0.290m
Shipping Height	0.120m
Shipping Length	0.270m
Shipping Cubic	0.010530000m3
