The Best NAS 4 Flash

ASUSTOR AS5402T Nimbustor 2 Bay NAS

The best of both worlds for hard drives and flash SSDs, with four M.2 NVMe slots, dual 2.5-Gigabit Ethernet and 4K transcoding.

2 BayNAS Storage

4x M.2NVMe SSD Slots

4GBDDR4-2933 RAM

Dual 2.5GbENetwork Ports

Key Features

Quad-Core 10 nm Intel Celeron N5105 CPU
4x M.2 slots for NVMe SSDs
4 GB of DDR4-2933 RAM
Dual 2.5-Gigabit Ethernet ports
3x USB 3.2 Gen 2 at 10 Gbps
HDMI 2.0b
Aesthetically pleasing M.2 SSD heat dissipation thermal vents
Enjoy, download, upload and stream content with 4K transcoding
Supports Wake on LAN and Wake on WAN

Enthusiast-Grade NAS with Entry-Level Pricing

Four M.2 slots for NVMe SSDs to accelerate volumes or assist in content creation

Easy content creation and storage. Adobe certified

Cross-platform live streaming and real-time backup of live streams with convenient editing

Easy local and remote collaboration

Packed Full of Value

Intel’s all-new N5105 10 nm Quad-Core Celeron SoC at 2.0 GHz. With a boost frequency of up to 2.9 GHz, the powerful performance of the CPU ensures that working with the NAS is as smooth as butter while remaining affordable.

End of the Road…for Gigabit Ethernet

2.5GbE is not the future. It’s now. With 2.5GbE ubiquitous on enthusiast motherboards and available as an affordable USB adapter, the ubiquity of 2.5GbE makes all transfers fast. Break barriers even further by combining the dual 2.5-Gigabit Ethernet ports in SMB Multichannel to enjoy speeds exceeding 2.5 Gbps.

Best 4 Flash

The AS54 series is equipped with four M.2 slots for NVMe SSDs to accelerate tasks that require high random IO performance to save unbelievable amounts of time in applications that can take advantage of SSDs, such as content creation. Each M.2 slot for NVMe SSDs is tool-free for easier installation while the cooling vents ensure SSDs run at optimum performance.

All New Gaming-Inspired Theme for ADM

Take a look at the all new gaming-inspired elements brought to ADM.

Upgradeable 4GB DDR4-2933 RAM

The AS54 comes with four Gigabytes of DDR4 RAM and can be upgraded up to 16GB. DDR4 RAM provides up to 30% greater performance than DDR3 while also lowering energy requirements by 40%.

Frequently Asked Questions

Product FAQs

Answers based on the product information supplied for this item.

Which processor does the ASUSTOR AS5402T use?

The supplied description lists an Intel Celeron N5105 10 nm quad-core processor at 2.0 GHz with a boost frequency of up to 2.9 GHz.

How much memory does the AS5402T include?

It includes 4GB DDR4-2933 RAM and is listed as upgradeable up to 16GB.

How many M.2 slots does the AS5402T have?

The AS54 series is listed with four tool-free M.2 slots for NVMe SSDs.

Which network connections are included?

The supplied feature list includes dual 2.5-Gigabit Ethernet ports.

Can the dual network ports be combined?

The supplied information states that the dual 2.5-Gigabit Ethernet ports can be combined in SMB Multichannel for speeds exceeding 2.5 Gbps.

Which USB and HDMI connections are listed?

It lists 3x USB 3.2 Gen 2 at 10 Gbps and HDMI 2.0b.

Does the AS5402T support 4K transcoding?

Yes. The supplied feature list includes downloading, uploading and streaming content with 4K transcoding.

Does the AS5402T support Wake on LAN and Wake on WAN?

Yes. Both are included in the supplied feature list.

(AS5402T)

Hardware Specifications
CPU	CPU Model	Intel Celeron N5105
	CPU Architecture	x64 64-bit
	CPU Frequency	Quad-Core 2.0GHz (burst up 2.90 GHz)
Memory	Memory	4GB SO-DIMM DDR4
	Memory Module Pre-installed	4GB (1x 4GB)
	Total Memory Slots	2
	Memory Expandable up to	16GB (2x 8GB) Support mixed capacity
	Flash Memory	8GB eMMC
Storage	Drive Bays	2
	M.2 Drive Slots	4
	Compatible Drive Type	3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD M.2 2280 NVMe
	M.2 PCIe Interface	PCIe 3.0 x1
	Maximum Drive Bays with	14
	Supports Hot Swappable Drives
External Ports	Expansion	3x USB 3.2 Gen 2 (10Gbps)
	Network	2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
	Multimedia Output	1x HDMI 2.0b
Others	System Fan	1x 70mm
	Infrared Receiver
	Power Supply Unit / Adapter	65W x1
	Input Power Voltage	100V to 240V AC
	Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
	Warranty	3 Years
Operation	Power Consumption	22.9 W (Operation); 12.7 W (Disk Hibernation); 0.71 W (Sleep Mode)
	Noise Level	18.6dB (HDD idle)
	Operation Temperature	0°C~40°C (32°F~104°F)
	Storage Temperature	-20°C~70°C (-4°F~158°F)
	Humidity	5% to 95% RH
Size and Weight	Size	170 (H) x 114 (W) x 230 (D) mm
	Weight	1.71 kg / 3.77 lb
