NETGEAR JGS524AU
NETGEAR (JGS524) 24-PORT UNMANAGED SWITCH, GbE(24)

Name: NETGEAR JGS524 24 Port Gigabit Ethernet Switch
Brand: Netgear
SKU: JGS524
Price: 220 AUD
Availability: OutOfStock

24-port 10/100/1000BASE-T

10/100/1000 Mbps devices within a network.

Silently delivers up to 2000 Mbps on each port.

Certifications and standards

Overview:

16 or 24 ports deliver up to 2000Mbps of dedicated, non-blocking bandwidth per port
Instant Plug-N-Play connectivity with Auto-negotiation and Auto MDI/MDI-X
Easily combine new or existing 10-, 100- and 1000Mbps devices within your network
802.1p QoS support for prioritizing voice and video in the network
Jumbo Frame Support up to 9KB
Each port delivers up to 2000Mbps of network speed (full duplex)
Fast, auto-switching and auto-sensing 10/100/1000Mbps Ethernet connectio
16 or 24 switched ports provide bandwidth for PCs, servers or switches
Auto Uplink™ automatically adjusts for straight-through or crossover cables
Plug and play—begins working as soon as it is powered on
ntegrates 10-,100- and 1000Mbps devices into your network
Compact size for desktop or for mounting in a standard 19-inch rack
Secure, durable metal housing includes a Kensington locking slot for theft prevention
Backed by a NETGEAR Limited Lifetime* Warranty
Honors TOS/802.1p prioritization
Up to 50% lower power consumption**
Auto power-down mode saves energy when port is unused
Auto green mode detects cable length and adjusts power usage to save energy
Packaging manufactured with at least 80% recycled materials

The NETGEAR Gigabit Unmanaged Switch series helps businesses cost-effectively expand their network to Gigabit speeds and higher port counts
Unmanaged Gigabit switches come in a wide range of models including desktop, wall-mount and rackmount form factors and 5 to 24 port configurations
Energy efficient, built to last, and rigorously tested to provide the reliability businesses need
802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks

24 ports deliver up to 2000Mbps of dedicated, non-blocking bandwidth per port
Instant Plug-N-Play connectivity with Auto-negotiation and Auto MDI/MDI-X
Easily combine new or existing 10-, 100- and 1000Mbps devices within your network
802.1p QoS support for prioritizing voice and video in the network
Jumbo Frame Support up to 9KB

NETGEAR JGS524AU Diagram

(JGS524)

NETGEAR JGS524AU Specifications
Physical Specification	Dimensions (WxDxH) @mm : 328 x 169 x 43 mm Weight (kg) 1.65
Technical Specification	Speed : 10/100/1000Mbps Gigibit Ethernet Number of Ports : 24 PoE ports : n/a Total PoE Budget : n/a Loop Detection : n/a Short cable power saving : n/a Energy Efficient Ethernet Support (IEEE 802.3az) : Yes Jumbo Frame Support : 9KB Queue WRR Ratio : 1:2:4:8 MAC Table Size : 8K Packet buffer size : 256KB IEEE 802.1p QoS : Yes Max Power Consumption : 17.9W Operating Temperature : 0 to 50° C MTBF (hours) : 238,872 FCC Class : A
Support & Warranty	Warranty: This product is backed by a NETGEAR ProSAFE ® Limited Lifetime Hardware Warranty. Lifetime Next Business Day Hardware Replacement. Support : ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts. ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat.
