Standard&Protocol

IEEE802.3, IEEE802.3u, IEEE802.3ab

CPU

4-Core 2GHz CPU

RAM

512MB

Interface

2*10/100/1000/2500Mbps WAN/LAN ports
3*10/100/1000Mbps WAN/LAN ports

Antenna

5*external antennas

Button

1*Mesh/WPS button, 1*Reset button

Power

Input: AC 100-240V~50/60Hz, 0.5A
Output: DC12V⎓2A

LED indicator

1* LED

Dimensions

(L*W*H) 290.25mm* 52.4mm*230mm

Wireless Standards

IEEE 802.11be/ax/ac/n/a 5 GHz
IEEE 802.11be/ax/n/b/g 2.4 GHz

Data Rate

5 GHz: 5765 Mbps (802.11be, HE160)
2.4 GHz: 1376 Mbps (802.11be)

Frequency

CE:
2.4G: 2412-2472MHz(CH1-CH13)
5G: 5150-5350MHz(CH36-CH64)
FCC:
2.4G: 2412-2462MHz(CH1-CH11)
5G: 5150-5350MHz(CH36-CH64)
5725-5850MHz(CH149-CH165)

Transmission Power

CE:
＜20 dBm（2.4 GHz）
＜23 dBm（5 GHz）
FCC:
＜30 dBm（2.4 GHz）
＜30 dBm（5 GHz）

Basic Features

SSID broadcasting and hiding
MU-MIMO
Beamforming signal directional transmission technology
OFDMA
Multi-Link Operation（MLO）
4K-QAM
Multi-RUs

Wireless Security

WPA2-PSK
WPA3-SAE/WPA2-PSK
Wireless Security: Enable/Disable
WPS（WiFi Protected Set-up) fast encryption
