Mechanical

Dimensions

130 x 155 x 126 mm (5.1 x 6.1 x 5")

Weight

490 g (1.1 lb)

Enclosure Material

Aluminium alloy, polycarbonate

Mount Material

Aluminium alloy

Weatherproofing

IPX5

Colour

White

Compatibility

UVC-G6-Pro-Bullet, UVC-AI-Pro

Hardware

Radar

Recommended Mounting Height: 2-5 m (6.6-16.4 ft)
Recommended Mounting Tilt: 0-30°
Detection Range
Person: 0.5-20 m (1.6-65.6 ft)
Vehicle: 2-35 m (6.6-115 ft)
Field of Detection: H: 110°
Distance Accuracy: 0.5 m (1.6 ft)

IR Distance

UVC-G6-Pro-Bullet: 60 m (197 ft)
UVC-AI-Pro: 40 m (131 ft)

Lights

5700 K, 600 lm

Speaker

Yes

Power Method

Camera G6 Pro Bullet, AI Pro

Power Supply

5 V DC, 3 A

Max. Power Consumption

15 W

Ambient Operating Temperature

-30 to 50° C (-22 to 122° F)

Ambient Operating Humidity

10 to 90% noncondensing

NDAA Compliant

Yes

Certifications

FCC, IC, CE

Software

Application Requirements

Web Application: UniFi Protect
Mobile App: UniFi Protect iOS™ and Android™

Manufacturer Warranty: 1 Year Manufacturer Warranty
