StarTech 2.5" SATA to Mini SATA Adapter Enclosure - SAT2MSAT25
Model # SAT2MSAT25
-
SKU: SAT2MSAT25
Stock Availability
🟢Live
Allow 1–2 business days for stock transfer
- Pick Up Available
- Australian Warranty
- Checkout Securely
mSATA SSD to standard 2.5-inch SATA enclosure adapter
An aluminium-and-plastic enclosure that converts one mSATA mini SSD into a standard 2.5-inch SATA drive form factor for compatible laptops, desktops, enclosures and docks.
Key capabilities
mSATA to 2.5-inch SATA
Converts one mSATA / Mini SATA SSD into a standard 2.5-inch SATA format.
SATA III interface
Supports transfer speeds up to 6Gbps with compatible equipment.
Standard mounting points
Uses standard 2.5-inch drive mounting points.
Enclosed adapter design
Aluminium-and-plastic enclosure protects the installed mSATA module.
What to know before buying
This exact model is for mSATA / Mini SATA SSDs, not M.2 SATA or M.2 NVMe drives.
Australian version and manufacturer warranty
This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 2-year manufacturer warranty in Australia.
Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
Frequently asked questions
What drive does SAT2MSAT25 accept?
What form factor does it create?
What speed is supported?
Can it use M.2 SSDs?
Does it need drivers?
What material is the enclosure?
What is included?
What warranty applies in Australia?
(SAT2MSAT25)
Features and highlights
mSATA to 2.5-inch SATA
Converts one mSATA / Mini SATA SSD into a standard 2.5-inch SATA format.
SATA III interface
Supports transfer speeds up to 6Gbps with compatible equipment.
Standard mounting points
Uses standard 2.5-inch drive mounting points.
Enclosed adapter design
Aluminium-and-plastic enclosure protects the installed mSATA module.
- 1 × mSATA SSD
- 2.5in SATA form factor
- SATA III up to 6Gbps
- 2-year warranty
Specifications
Verified specifications for StarTech SAT2MSAT25.
Warranty Information
| Warranty | 2 Years |
|---|
Hardware
| Compatible Drive Types | mSATA (Mini SATA) |
|---|---|
| Drive Installation | Fixed |
| Interface | SATA |
| Number of Drives | 1 |
Connector(s)
| Drive Connectors | 1 - mSATA (52 pin, Mini SATA) Slot Female |
|---|---|
| Host Connectors | 1 - SATA Data & Power Combo (7+15 pin) Plug |
Software
| OS Compatibility | OS independent; No software or drivers required |
|---|
Environmental
| Humidity | 5% ~ 95% RH |
|---|---|
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -10°C to 85°C (14°F to 185°F) |
Physical Characteristics
| Color | Silver |
|---|---|
| Enclosure Type | Aluminum and Plastic |
| Product Height | 0.3 in [0.8 cm] |
| Product Length | 3.9 in [10 cm] |
| Product Width | 2.8 in [70 mm] |
| Weight of Product | 1.8 oz [52 g] |
Packaging Information
| Package Height | 1.3 in [32 mm] |
|---|---|
| Package Length | 5.2 in [13.1 cm] |
| Package Width | 6.5 in [16.6 cm] |
| Shipping (Package) Weight | 4.1 oz [117 g] |
What's in the Box
| Included in Package | 1 - mSATA to 2.5in SATA converter |
|---|---|
| Included in Package | 2 - Mounting Screws |
| Included in Package | 1 - Instruction Manual |
| SKU | SAT2MSAT25 |
| Barcode # | 65030845694 |
| Brand | Startech |
| Shipping Weight | 0.1000kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.150m |
| Shipping Cubic | 0.000750000m3 |
StarTech.com warranty in Australia
This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 2-year manufacturer warranty in Australia.
Please retain your DeviceDeal tax invoice as proof of purchase.
Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.
