StarTech.com SFPGESST

Cisco SFP-GE-S compatible 1000BASE-SX multimode SFP

A Cisco SFP-GE-S compatible SFP optical module for 1GbE multimode fibre links up to 550m, using duplex LC at 850nm with DDM.

1GbE / 1.25GbpsMultimode fibreLC / 850nm / 550mLifetime warranty

StarTech SFPGESST Cisco compatible 1000BASE-SX multimode SFP

Key capabilities

Cisco SFP-GE-S compatible

Designed, programmed and tested for compatible Cisco switches and routers.

550m multimode reach

Supports 1000BASE-SX links up to 550m / 1804ft.

850nm duplex LC

Uses multimode fibre with a duplex LC optical connection.

DDM and hot swap

DDM is supported and the module can be hot-swapped.

What to know before buying

Confirm the target switch/router accepts Cisco SFP-GE-S compatible SFP modules and that the multimode fibre plant supports the required 1000BASE-SX link distance.

Australian version and manufacturer warranty

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com Lifetime manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.

Frequently asked questions

What is the StarTech SFPGESST compatible with?

Cisco SFP-GE-S compatible networking equipment.

What network speed does it support?

1GbE with a listed maximum data rate of 1.25Gbps.

What fibre type does it use?

Multimode fibre.

What connector and wavelength are used?

Duplex LC at 850nm.

What is the maximum distance?

Up to 550m / 1804ft.

Does it support DDM?

Yes.

What power consumption is listed?

Less than 1W.

What warranty applies in Australia?

The Australian version supplied by DeviceDeal is covered by the official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com terms and product assessment.

(SFPGESST)

Features and highlights

Cisco SFP-GE-S compatible

Designed, programmed and tested for compatible Cisco switches and routers.

550m multimode reach

Supports 1000BASE-SX links up to 550m / 1804ft.

850nm duplex LC

Uses multimode fibre with a duplex LC optical connection.

DDM and hot swap

DDM is supported and the module can be hot-swapped.

1GbE / 1.25Gbps
Multimode fibre
LC / 850nm / 550m
Lifetime warranty

Warranty confidence: Official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com terms and assessment.

Specifications

Verified specifications for StarTech SFPGESST.

Warranty Information

Warranty	Lifetime

Hardware

Compatible Brand	Cisco
Industry Standards	IEEE 802.3z 1000BASE-SX
WDM	No

Performance

Compatible Networks	1000 Mbps (1 Gbps)
DDM	Yes
Fiber Operating Mode	Half/Full-Duplex
Max Transfer Distance	550 m (1804 ft)
Maximum Data Transfer Rate	1.25 Gbps
MTBF	3,381,761 hours
Type	Multi Mode
Wavelength	850nm

Connector(s)

Local Unit Connectors	1 - Fiber Optic LC Duplex Female

Special Notes / Requirements

Note	For use in Gigabit fiber networking equipment and media converters
System and Cable Requirements	MSA or Cisco compliant SFP port

Power

Power Consumption (In Watts)	< 1 W

Environmental

Humidity	30~70% RH
Operating Temperature	0°C to 70°C (32°F to 158°F)
Storage Temperature	-40°C to 85°C (-40°F to 85°F)

Physical Characteristics

Product Height	0.4 in [1 cm]
Product Length	2.4 in [60 mm]
Product Width	0.5 in [12 mm]
Weight of Product	0.6 oz [17 g]

Packaging Information

Package Height	1.3 in [32 mm]
Package Length	3.6 in [92 mm]
Package Width	4.7 in [11.9 cm]
Shipping (Package) Weight	3.4 oz [95 g]

What's in the Box

Included in Package	1 - 1.25 Gbps Multimode LC SFP

SKU	SFPGESST
Barcode #	65030849432
Brand	Startech
Shipping Weight	0.0400kg
Shipping Width	0.100m
Shipping Height	0.050m
Shipping Length	0.110m
Shipping Cubic	0.000550000m3

Lifetime official manufacturer warranty

StarTech.com warranty in Australia

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com Lifetime manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase.

Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment. This wording does not promise automatic replacement or guaranteed claim approval.
