StarTech Hot Swap Hard Drive Bay 2.5" SATA SSD HDD USB 3.1 Enclosure - S251BU31REM
Model # S251BU31REM
-
SKU: S251BU31REM
- Pick Up Available
- Australian Warranty
- Checkout Securely
(S251BU31REM)
| Warranty Information | ||
|---|---|---|
| Warranty | 2 Years | |
| Hardware | ||
| Bus Type | USB 3.1 Gen 2 | |
| Chipset ID | ASMedia - ASM1351 | |
| Compatible Drive Types | SATA | |
| Drive Installation | Removable | |
| Drive Size | 2.5in | |
| Front Door Key Lock | No | |
| Interface | SATA | |
| USB 3.1 Gen 2 | ||
| Number of Drives | 1 | |
| Supported Drive Height(s) | 5mm | |
| 7mm | ||
| 9.5mm | ||
| Performance | ||
| 4Kn Support | Yes | |
| Max Drive Capacity | Currently tested with hard drives up to 2TB at 7200 RPM. | |
| Maximum Data Transfer Rate | 10Gbps | |
| MTBF | 100,000 hours | |
| TRIM Support | Yes | |
| Type and Rate | USB 3.1 Gen 2 - 10 Gbit/s | |
| SATA III (6 Gbps) | ||
| UASP Support | Yes | |
| Connector(s) | ||
| Drive Connectors | 1 - SATA Data & Power Combo (7+15 pin) Receptacle | |
| Host Connectors | 1 - USB 3.1 USB Type Micro-B (10 pin, Gen 2, 10 Gbps) Female | |
| 1 - SATA (7 pin, Data) Plug | ||
| 1 - SP4 (4 pin, Small Drive Power) Male | ||
| Software | ||
| OS Compatibility | OS independent; No software or drivers required | |
| Special Notes / Requirements | ||
| System and Cable Requirements | Available 3.5" or 5.25" front bay | |
| Available internal SATA data connector | ||
| Available SATA or LP4 Molex internal power connector | ||
| Indicators | ||
| LED Indicators | 1 - Power(Green) | |
| 1 - Activity(Red) | ||
| Power | ||
| Power Source | USB-Powered | |
| Environmental | ||
| Humidity | Operation Humidity: 10% ~ 90% RH Storage Humidity: 5% ~ 95% RH | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) | |
| Storage Temperature | -10°C to 65°C (14°F to 149°F) | |
| Physical Characteristics | ||
| Color | Black | |
| Enclosure Type | Aluminum and Plastic | |
| Max Drive Height | 0.4 in [9.5 mm] | |
| Product Height | 1.6 in [4.2 cm] | |
| Product Length | 6.1 in [15.5 cm] | |
| Product Width | 5.7 in [14.6 cm] | |
| Weight of Product | 15 oz [426 g] | |
| Packaging Information | ||
| Package Height | 3.1 in [79 mm] | |
| Package Length | 9.4 in [23.9 cm] | |
| Package Width | 6.2 in [15.7 cm] | |
| Shipping (Package) Weight | 25.2 oz [715 g] | |
| What's in the Box | ||
| Included in Package | 1 - 2.5” SATA enclosure | |
| 1 - 3.5” front-panel drive bay | ||
| 1 - 3.5” to 5.25” front bay adapter bracket | ||
| 1 - SATA data cable | ||
| 1 - SATA power cable | ||
| 1 - Molex power cable | ||
| 1 - USB-C to Micro-B cable | ||
| 1 - USB-A to Micro-B cable | ||
| 1 - set of drive-mounting hardware | ||
| 4 - bay-mounting screws | ||
| 4 - bracket-mounting screws | ||
| 1 - quick-start guide | ||
| SKU | S251BU31REM |
| Barcode # | 65030868211 |
| Brand | Startech |
| Shipping Weight | 0.7000kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.230m |
| Shipping Cubic | 0.001150000m3 |
Manufacturer Warranty: 2 Years Limited Warranty
