StarTech M.2 SSD Enclosure for M.2 SATA SSDs - USB 3.1 (10Gbps) with USB-C Cable SM21BMU31C3
Model # SM21BMU31C3
-
SKU: SM21BMU31C3
- Pick Up Available
- Australian Warranty
- Checkout Securely
This compact M.2 SATA SSD enclosure lets you add highly portable data storage to any laptop or computer with a USB-C™ port - such as MacBook, Chromebook Pixel™, Dell™ XPS laptops, and many others. It turns your SATA M.2 drive into a high-speed storage solution over a USB 3.1 Gen 2 connection, at up to 10Gbps throughput.
A truly portable solution
This slim, pocket-sized enclosure for M.2 NGFF SATA SSDs has been specially designed for mobility, with a small form factor design that fits easily into your laptop bag. Its lightweight yet durable aluminum housing helps to ensure your drive won’t be damaged while you’re on the move.
Ventilation holes help to dissipate heat and help ensure an optimum operating temperature.
Maximize the performance of your M.2 SATA SSD
Leverage the speed of your M.2 NGFF SATA drive with this external enclosure. It delivers USB 3.1 Gen 2 data transfer speeds up to 10Gbps as well as UASP support, so you can achieve higher transfer speeds when you connect it to a UASP-enabled host computer.
The enclosure works with tablets, laptops and desktop computers and is compatible with hosts equipped with Thunderbolt 3 USB-C ports.
Broad compatibility
The enclosure is compatible with all of the common M.2 SATA SSDs, and enables you to mount multiple drive lengths, including: 30mm (2230), 42mm (2242), 60mm (2260), and 80mm (2280).
The SM21BMU31C3 is backed by a 2-year StarTech.com warranty and free lifetime technical support.
(SM21BMU31C3)
| Warranty Information | ||
|---|---|---|
| Warranty | 2 Years | |
| Hardware | ||
| Bus Type | USB 3.1 Gen 2 | |
| Chipset ID | ASMedia - ASM1351 | |
| Compatible Drive Types | M.2 (SATA, B-Key, NGFF) | |
| M.2 SATA (NGFF, B+M-Key) | ||
| Drive Installation | Fixed | |
| Interface | USB 3.1 Gen 2 | |
| Number of Drives | 1 | |
| Performance | ||
| 4Kn Support | Yes | |
| General Specifications | Not compatible with M.2 NVMe or AHCI PCI-Express SSDs | |
| Maximum Data Transfer Rate | 10 Gbps | |
| MTBF | 1,000,000 hours | |
| TRIM Support | Yes | |
| Type and Rate | USB 3.1 Gen 2 - 10 Gbit/s | |
| SATA III (6 Gbps) | ||
| UASP Support | Yes | |
| Connector(s) | ||
| Drive Connectors | 1 - M.2 (SATA, B-Key, NGFF) Receptacle | |
| Host Connectors | 1 - USB 3.1 USB Type Micro-B (10 pin, Gen 2, 10 Gbps) Female | |
| Software | ||
| OS Compatibility | OS independent; No software or drivers required | |
| Indicators | ||
| LED Indicators | 1 - Power & Activity | |
| Power | ||
| Power Source | USB-Powered | |
| Environmental | ||
| Humidity | Operation Humidity: 10% ~ 90% RH Storage Humidity: 5% ~ 95% RH | |
| Operating Temperature | 0¡C to 40¡C (32¡F to 104¡F) | |
| Storage Temperature | -10¡C to 65¡C (14¡F to 149¡F) | |
| Physical Characteristics | ||
| Color | Black & Silver | |
| Enclosure Type | Aluminum | |
| Max Drive Height | 3.1 in [80 mm] | |
| Product Height | 0.5 in [1.3 cm] | |
| Product Length | 3.9 in [99 mm] | |
| Product Width | 1.7 in [42 mm] | |
| Weight of Product | 2.2 oz [61 g] | |
| Packaging Information | ||
| Package Height | 1.3 in [32 mm] | |
| Package Length | 5.2 in [13.1 cm] | |
| Package Width | 6.3 in [16.1 cm] | |
| Shipping (Package) Weight | 4.9 oz [139 g] | |
| What's in the Box | ||
| Included in Package | 1 - M.2 NGFF SATA Enclosure - USB 3.1 | |
| 1 - USB-C to Micro B cable - 18.5 inches | ||
| 1 - M.2 screw kit | ||
| 1 - screwdriver | ||
| 1 - quick install guide | ||
| SKU | SM21BMU31C3 |
| Barcode # | 65030864435 |
| Brand | Startech |
| Shipping Weight | 0.1300kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.160m |
| Shipping Cubic | 0.000800000m3 |
