StarTech mSATA to SATA HDD/SSD Adapter Converter - MSAT2SAT3
Model # MSAT2SAT3
-
SKU: MSAT2SAT3
- Pick Up Available
- Australian Warranty
- Checkout Securely
StarTech MSAT2SAT3 mSATA to SATA HDD and SSD Adapter
mSATA to SATA HDD and SSD Adapter designed for professional IT, electronics, security or workstation use.
Frequently asked questions
What is StarTech MSAT2SAT3?
It is a mSATA-host to standard SATA drive adapter that connects one 2.5in or 3.5in SATA HDD or SSD to an available mSATA host port at up to SATA III 6Gbps.
Which connections or mounting method are provided?
One mSATA 52-pin male host connector to one SATA 7-pin data receptacle
What performance is specified?
SATA I, II and III compatible; up to 6Gbps; tested with a 4TB 7200rpm hard drive
How is the product constructed?
Compact bare-board adapter supplied with a screw kit and installation guide
What drive types are supported?
The adapter supports one fixed 2.5in or 3.5in SATA HDD or SSD.
What is the tested drive capacity?
StarTech specifies testing with a 4TB 7200rpm hard drive.
What should be checked before ordering?
The computer must provide a compatible mSATA host port; the adapter connects one fixed SATA drive and does not convert a SATA host into mSATA.
What warranty applies?
MSAT2SAT3 carries a StarTech.com 2 years manufacturer warranty, subject to the manufacturers terms and eligibility requirements.
Planning a broader setup? Browse the DeviceDeal buying guides.
(MSAT2SAT3)
Why choose MSAT2SAT3?
MSAT2SAT3 specifications
Exact-model specifications for compatibility checking. Measurements may be rounded.
| Warranty Information | |
|---|---|
| Warranty | 2 Years |
| Hardware | |
| Compatible Drive Types | SATA |
| Drive Installation | Fixed |
| Drive Size | 2.5in & 3.5in |
| Interface | Micro SATA |
| Number of Drives | 1 |
| Performance | |
| Max Drive Capacity | Currently tested with up to 4TB 7200 RPM hard drive |
| Type and Rate | SATA III (6 Gbps) |
| Connector(s) | |
| Drive Connectors | 1 - SATA (7 pin, Data) Receptacle |
| Host Connectors | 1 - mSATA (52 pin, Mini SATA) Male |
| Software | |
| OS Compatibility | OS independent; No software or drivers required |
| Environmental | |
| Humidity | Operating 20% to 80%; Non Operating 15% to 90% |
| Operating Temperature | 5°C to 50°C (41°F to 122°F) |
| Storage Temperature | -25°C to 70°C (-13°F to 158°F) |
| Physical Characteristics | |
| Product Height | 0.3 in [0.8 cm] |
| Product Length | 2 in [51 mm] |
| Product Width | 1.2 in [30 mm] |
| Weight of Product | 0.4 oz [10 g] |
| Packaging Information | |
| Package Height | 0.4 in [10 mm] |
| Package Length | 8.9 in [22.5 cm] |
| Package Width | 4.9 in [12.5 cm] |
| Shipping (Package) Weight | 0.5 oz [15 g] |
| What's in the Box | |
| Included in Package | 1 - mSATA to SATA Adapter |
Sources: https://www.devicedeal.com.au/startech-msata-to-sata-hdd-ssd-adapter-converter and https://www.startech.com/
| SKU | MSAT2SAT3 |
| Barcode # | 65030854825 |
| Brand | STARTECH |
| Shipping Weight | 0.0200kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.110m |
| Shipping Cubic | 0.000550000m3 |
This Australian-version product is supplied by DeviceDeal and is covered by the 2-year manufacturer warranty term listed for this exact product.
- Keep your DeviceDeal tax invoice as proof of purchase.
- Coverage is subject to StarTech.com warranty terms, eligibility and product assessment.
- Warranty service does not replace rights that may apply under Australian Consumer Law.
