StarTech USB-C Dock 4K Triple Monitor DisplayPort/HDMI 100W PD, USB Hub - DK30CH2DEP
Model # DK30CH2DEP
-
SKU: DK30CH2DEP
- Pick Up Available
- Australian Warranty
- Checkout Securely
Triple-Monitor 4K USB-C Dock with 100W Power Delivery
Expand a USB-C laptop into a three-display workstation with two DisplayLink DisplayPort outputs, one DP Alt Mode HDMI output, five downstream USB ports and up to 100W laptop charging.
Triple-display layout
Connect two DisplayPort monitors plus one HDMI monitor.
Two 4K 60Hz outputs
Each DisplayLink DisplayPort output supports up to 4096 x 2160 at 60Hz.
5K display option
Use both DisplayPort outputs for one 5120 x 2880 monitor at 60Hz.
100W charging
The included 150W adapter provides up to 100W USB-C Power Delivery.
What to know
Triple-display operation combines DisplayLink and USB-C DP Alt Mode, so the host must support DP Alt Mode and DisplayLink software must be installed. USB-A use needs the separately sold USB315AC1M cable and is limited to dual displays with no laptop charging.
Frequently asked questions
How many monitors does the DK30CH2DEP support?
It supports up to three monitors: two through DisplayPort and one through HDMI.
What resolution do the DisplayPort outputs support?
Each DisplayPort output supports up to 4096 x 2160 or 3840 x 2160 at 60Hz.
What resolution does the HDMI output support?
The HDMI output supports up to 4096 x 2160 at 24Hz or 3840 x 2160 at 30Hz.
Can it drive a 5K display?
Yes. One 5120 x 2880 display at 60Hz can use both DisplayPort outputs.
How much power can it deliver to a laptop?
It provides up to 100W USB Power Delivery through USB-C using the included 150W adapter.
Can I use it with a USB-A laptop?
Yes, with the separately sold USB315AC1M cable, but USB-A use is limited to dual displays and does not charge the laptop.
Does it require drivers?
DisplayLink software is required for the DisplayPort graphics functions. The USB-C host must also support DP Alt Mode for HDMI.
How many downstream USB ports are available?
There are five: one USB-C and four USB-A, including one 7.5W power-only fast-charge port.
Not sure this is the right product for your setup? Visit the DeviceDeal Buying Guides.
(DK30CH2DEP)
Features and highlights
- Triple-monitor USB-C dock with two DisplayPort outputs and one HDMI output
- DisplayPort outputs support up to 4K 60Hz; HDMI supports 3840 x 2160 at 30Hz or 4096 x 2160 at 24Hz
- Single 5K 60Hz display supported through both DisplayPort outputs
- Up to 100W USB Power Delivery with included 150W adapter
- Five downstream USB ports: one USB-C and four USB-A, including a 7.5W power-only fast-charge port
- Gigabit Ethernet, TRRS headset, stereo audio output and microphone input
- USB-A host compatibility available with optional cable, with stated display and charging limitations
- Kensington-style security slot and included 1m USB-C host cable
Specifications
| Product type | USB-C triple-monitor universal docking station |
|---|---|
| Host connection | USB-C; USB-A supported with USB315AC1M cable sold separately |
| Video outputs | 2 x DisplayPort (DisplayLink); 1 x HDMI (USB-C DP Alt Mode) |
| DisplayPort resolution | Up to 4096 x 2160 at 60Hz or 3840 x 2160 at 60Hz per output |
| HDMI resolution | Up to 4096 x 2160 at 24Hz or 3840 x 2160 at 30Hz |
| Single 5K mode | 5120 x 2880 at 60Hz using both DisplayPort outputs |
| USB ports | 1 x USB-C 5Gbps; 3 x USB-A 5Gbps data; 1 x USB-A 7.5W power-only fast-charge |
| Networking | Gigabit Ethernet |
| Audio | 3.5mm TRRS headset; separate 3.5mm stereo audio and microphone ports |
| Laptop charging | Up to 100W USB Power Delivery with USB-C host; unavailable over USB-A |
| Power adapter | 150W adapter included |
| Dimensions / weight | 270 x 82 x 34mm; 382g |
| Package dimensions / weight | 162 x 318 x 84mm; 1,598g |
| In the box | Dock, 1m USB-C cable, universal power adapter and power cords, anti-slip pads and documentation |
| UPC | 065030879996 |
| Warranty | 3 years |
| SKU | DK30CH2DEP |
| Barcode # | 65030861212 |
| Brand | STARTECH |
| Shipping Weight | 1.6000kg |
| Shipping Width | 0.160m |
| Shipping Height | 0.080m |
| Shipping Length | 0.320m |
