Startech DKT30CHPD3 USB C Multiport Adapter 4K 60Hz HDMI/PD
Model # DKT30CHPD3
-
SKU: DKT30CHPD3
- Pick Up Available
- Australian Warranty
- Checkout Securely
USB-C Multiport Adapter with 4K 60Hz HDMI and 100W PD
Connect a high-resolution HDMI display and three USB-A devices while passing USB-C power to a compatible laptop through a portable five-in-one adapter.
4K 60Hz HDMI
DP 1.4 Alt Mode hosts support 4K 60Hz and HDR10.
Three USB-A ports
Connect 5Gbps peripherals, with one BC 1.2 charging-capable port.
Up to 88W charging
A 100W source leaves up to 88W for the laptop after 12W is reserved.
300mm host cable
Extra reach for tablets, 2-in-1 devices and raised laptops.
What to know
A USB-C power adapter is not included. The USB-C downstream socket is for Power Delivery input only, while the three USB-A sockets carry data.
Frequently asked questions
What video output and resolution does the DKT30CHPD3 support?
HDMI supports 4K 60Hz on DP 1.4 Alt Mode hosts and 4K 30Hz on DP 1.2 hosts; HDR10 is supported.
How many external displays can the DKT30CHPD3 connect?
It supports one external HDMI display.
Does the DKT30CHPD3 charge the connected laptop?
Yes. It accepts up to 100W USB Power Delivery 3.0, reserves 12W for the adapter and provides up to 88W to the laptop.
Which USB ports are included on the DKT30CHPD3?
It includes three USB-A 5Gbps ports; one supports BC 1.2 charging. The USB-C port is for PD input only.
What other connections or readers does the DKT30CHPD3 include?
This compact model focuses on HDMI, USB and Power Delivery and does not include Ethernet or memory-card readers.
What must the host USB-C port support?
The host must support DP Alt Mode; DP 1.4 is required for 4K 60Hz, and USB Power Delivery is required for laptop charging.
Is a separate power adapter required or included?
A USB-C power adapter is not included. The adapter can be bus powered, or used with a compatible USB-C PD source for charging.
What cable and warranty are supplied with the DKT30CHPD3?
It has an attached 300mm USB-C host cable. It is backed by a 3-year StarTech.com manufacturer warranty.
Not sure this is the right product for your setup? Visit the DeviceDeal Buying Guides.
(DKT30CHPD3)
Features and highlights
- HDMI 2.0b output with HDR10 support
- 4K 60Hz on DP 1.4 Alt Mode hosts; 4K 30Hz on DP 1.2 hosts
- Three USB-A 5Gbps ports
- One USB-C 100W Power Delivery input port
- USB Power Delivery 3.0 with Fast Role Swap
- Up to 88W available to the laptop from a 100W USB-C power source
- Attached 300mm USB-C host cable
- USB bus powered when a USB-C charger is not connected
Specifications
| Product type | Portable USB-C multiport adapter |
|---|---|
| Host connection | Attached USB-C 5Gbps cable |
| Video output | 1 x HDMI 2.0b with HDR10 |
| Maximum resolution | 4K 60Hz with DP 1.4 Alt Mode; 4K 30Hz with DP 1.2 Alt Mode |
| Displays supported | 1 |
| USB ports | 3 x USB-A 5Gbps; 1 x USB-C 100W PD input only |
| Power Delivery | 100W PD 3.0 input; 12W reserved; up to 88W to laptop |
| Power adapter | Not included; USB bus powered or host USB-C PD adapter |
| Cable length | 300mm |
| Dimensions / weight | 34 x 150 x 11mm; 61g |
| Package dimensions / weight | 143 x 172 x 34mm; 118g |
| In the box | USB-C multiport adapter and product documentation |
| UPC | 065030891806 |
| Warranty | 3 years |
| SKU | DKT30CHPD3 |
| Barcode # | 65030891806 |
| Brand | STARTECH |
| Shipping Weight | 0.1100kg |
| Shipping Width | 0.003m |
| Shipping Height | 0.018m |
| Shipping Length | 0.015m |
