STARTECH.COM | DKT31CHVL

USB-C 10Gbps Travel Dock with 4K HDMI or VGA, USB Hub and Gigabit Ethernet

Add a choice of HDMI or VGA video, one USB-A and one USB-C 10Gbps port plus Gigabit Ethernet through a lightweight bus-powered adapter.

HDMI or VGA

Choose 4K 30Hz HDMI or VGA for one external screen.

USB-A and USB-C

Connect one legacy and one modern 10Gbps peripheral.

Gigabit Ethernet

Add reliable 10/100/1000Mbps wired networking.

Bus powered

No separate power adapter is required or supported.

What to know

Use either HDMI or VGA, not both. The adapter is powered from the host and does not charge the connected laptop.

Frequently asked questions

What video output and resolution does the DKT31CHVL support?

Choose HDMI up to 3840 x 2160 at 30Hz or VGA up to 2048 x 1280 at 30Hz.

How many external displays can the DKT31CHVL connect?

It supports one external display at a time through either HDMI or VGA.

Does the DKT31CHVL charge the connected laptop?

No. It is USB bus powered and does not support USB Power Delivery passthrough.

Which USB ports are included on the DKT31CHVL?

It includes one USB-A 10Gbps port and one USB-C 10Gbps downstream data port.

What other connections or readers does the DKT31CHVL include?

It includes Gigabit Ethernet with auto MDIX and full-duplex support; it does not include a card reader.

What must the host USB-C port support?

The host USB-C port must support DisplayPort Alt Mode for HDMI or VGA video.

Is a separate power adapter required or included?

No power adapter is required or included; the travel dock is powered from the host USB-C connection.

What cable and warranty are supplied with the DKT31CHVL?

It has an attached USB-C host cable for convenient travel use. It is backed by a 3-year StarTech.com manufacturer warranty.

Not sure this is the right product for your setup? Visit the DeviceDeal Buying Guides.

(DKT31CHVL)

Features and highlights

Portable USB-C 10Gbps travel dock
HDMI output up to 3840 x 2160 at 30Hz
VGA output up to 2048 x 1280 at 30Hz
One external display supported at a time
One USB-A and one USB-C 10Gbps downstream port
Gigabit Ethernet with auto MDIX and full duplex
Attached USB-C host cable
USB bus powered with no Power Delivery passthrough

Compatibility check: The host USB-C port must support DisplayPort Alt Mode for video. This model does not support USB Power Delivery passthrough.

Specifications

Product type	Bus-powered USB-C 10Gbps travel dock
Video outputs	1 x HDMI; 1 x VGA; one output at a time
Maximum HDMI resolution	3840 x 2160 at 30Hz
Maximum VGA resolution	2048 x 1280 at 30Hz
Displays supported	1
USB ports	1 x USB-A 10Gbps; 1 x USB-C 10Gbps
Networking	Gigabit Ethernet; 10/100/1000Mbps; auto MDIX; full duplex
Power	USB bus powered; no PD passthrough
Power adapter	Not required or included
Colour	Black
Warranty	3 years

SKU	DKT31CHVL
Barcode #	65030887779
Brand	STARTECH
Shipping Weight	0.1600kg
Shipping Width	0.004m
Shipping Height	0.021m
Shipping Length	0.015m

Warranty and Australian supply

DKT31CHVL is supplied by DeviceDeal as an Australian-market product and carries the official 3-year StarTech.com manufacturer warranty in Australia.

Keep your DeviceDeal tax invoice as proof of purchase. Warranty service is subject to StarTech.com terms, eligibility requirements and product assessment.
