StarTech Dual Monitor USB C Dock, Windows/Mac, 4K DP/HDMI, 60W PD, SD - DK30CHDDPPD
Model # DK30CHDDPPD
-
SKU: DK30CHDDPPD
- Pick Up Available
- Australian Warranty
- Checkout Securely
Dual-Monitor USB-C Dock with DisplayPort, HDMI, 60W PD and SD
Turn a compatible USB-C laptop into a dual-monitor workstation with DisplayPort, HDMI, four USB-A ports, Gigabit Ethernet, headset audio and a fast UHS-II SD card reader.
Dual 4K 30Hz
Connect one HDMI and one DisplayPort monitor at up to 3840 x 2160 at 30Hz.
60W laptop charging
USB Power Delivery 2.0 powers compatible laptops from the included 100W adapter.
UHS-II SD reader
Transfer compatible SD media at up to 312MB/s.
Essential workstation I/O
Four USB-A ports, Gigabit Ethernet and TRRS headset audio.
What to know
The HDMI output requires USB-C DisplayPort Alt Mode, while the DisplayPort output uses DisplayLink software. The host USB-C port must support DP Alt Mode and USB Power Delivery for full video and charging functionality.
Frequently asked questions
How many monitors can the DK30CHDDPPD support?
It supports two monitors: one through DisplayPort and one through HDMI.
What resolution can each display use?
Both the HDMI and DisplayPort outputs support up to 3840 x 2160 at 30Hz.
Does it charge the connected laptop?
Yes. It provides up to 60W USB Power Delivery 2.0 to a compatible USB-C laptop.
Does it require a driver?
The DisplayPort output uses DisplayLink software. The HDMI output uses the host USB-C DP Alt Mode capability.
How fast is the SD card reader?
The SD 4.0 UHS-II reader supports transfer rates up to 312MB/s with compatible cards.
Which memory cards are supported?
It supports SD, MMC, SDHC and SDXC. MicroSD and miniSD cards can be used with suitable adapters.
How many USB ports are included?
It has four USB-A 5Gbps ports, including one fast-charge port supplying up to 7.5W.
What is included in the package?
It includes the dock, a 1m USB-C host cable, a 100W universal power adapter with power cords and documentation.
Not sure this is the right product for your setup? Visit the DeviceDeal Buying Guides.
(DK30CHDDPPD)
Features and highlights
- Dual-monitor dock with one HDMI DP Alt Mode output and one DisplayLink DisplayPort output
- Both display outputs support up to 3840 x 2160 at 30Hz
- Up to 60W USB Power Delivery 2.0 from included 100W adapter
- Four USB-A 5Gbps ports, including one 7.5W fast-charge port
- SD 4.0 UHS-II card reader with transfers up to 312MB/s
- Reads SD, MMC, SDHC and SDXC; microSD and miniSD require adapters
- Gigabit Ethernet and 3.5mm four-position headset connection
- Includes a 1m USB-C host cable
Specifications
| Product type | USB-C dual-monitor docking station |
|---|---|
| Host connection | USB-C via included 1m cable |
| Video outputs | 1 x DisplayPort (DisplayLink); 1 x HDMI (USB-C DP Alt Mode) |
| Maximum display resolution | Up to 3840 x 2160 at 30Hz on each output |
| USB ports | 3 x USB-A 5Gbps data (up to 4.5W each); 1 x USB-A 5Gbps fast charge (up to 7.5W) |
| Card reader | SD 4.0 UHS-II, up to 312MB/s; SD/MMC/SDHC/SDXC |
| Networking | Gigabit Ethernet |
| Audio | 3.5mm four-position headset port |
| Laptop charging | Up to 60W USB Power Delivery 2.0 |
| Power adapter | 100W adapter included |
| Dimensions / weight | 220 x 80 x 25mm; 261g |
| Package dimensions / weight | 159 x 271 x 93mm; 1,280g |
| In the box | Dock, 1m USB-C cable, universal power adapter and power cords, documentation |
| UPC | 065030868242 |
| Warranty | 3 years |
| SKU | DK30CHDDPPD |
| Barcode # | 65030868242 |
| Brand | Startech |
| Shipping Weight | 1.2900kg |
| Shipping Width | 0.160m |
| Shipping Height | 0.090m |
| Shipping Length | 0.260m |
| Shipping Cubic | 0.003744000m3 |
