STARTECH.COM | DK30CH2DPPD

Triple-Monitor 4K USB-C Dock with 60W Power Delivery

Create a three-monitor workspace with two 4K 60Hz DisplayPort outputs, one 4K HDMI output, five USB ports, Gigabit Ethernet and up to 60W laptop charging.

Triple-monitor support

Use two DisplayPort displays and one HDMI display together.

Dual 4K 60Hz DP

Both DisplayLink DisplayPort outputs support up to 4K 60Hz.

Single 5K mode

Connect one 5K 60Hz display using both DisplayPort outputs.

60W USB-C charging

Power a compatible laptop from the included 120W adapter.

What to know

The two DisplayPort outputs use DisplayLink, while HDMI uses USB-C DP Alt Mode. USB-A connectivity requires the separately sold USB315AC1M cable and then supports only dual displays without host charging.

Frequently asked questions

How many monitors can the DK30CH2DPPD support?

It supports up to three monitors using two DisplayPort outputs and one HDMI output.

What is the maximum DisplayPort resolution?

Each DisplayPort output supports up to 4096 x 2160 or 3840 x 2160 at 60Hz.

What is the maximum HDMI resolution?

HDMI supports up to 4096 x 2160 at 24Hz or 3840 x 2160 at 30Hz.

Can the dock support a 5K monitor?

Yes. One 5120 x 2880 display at 60Hz can connect using both DisplayPort outputs.

How much charging power does it provide?

It supplies up to 60W USB Power Delivery to a compatible USB-C laptop.

Can it connect to USB-A?

Yes, with the separately sold USB315AC1M cable. USB-A operation supports only dual displays and does not provide laptop charging.

Does it need DisplayLink software?

Yes. The DisplayPort outputs use DisplayLink; the HDMI output additionally requires USB-C DP Alt Mode.

What USB ports does it include?

It provides five downstream USB ports: one USB-C and four USB-A, including one 7.5W power-only fast-charge port.

Not sure this is the right product for your setup? Visit the DeviceDeal Buying Guides.

(DK30CH2DPPD)

Features and highlights

Two DisplayLink DisplayPort outputs plus one USB-C DP Alt Mode HDMI output
DisplayPort up to 4096 x 2160 at 60Hz; HDMI up to 3840 x 2160 at 30Hz or 4096 x 2160 at 24Hz
Single 5120 x 2880 display at 60Hz through both DisplayPort outputs
Up to 60W USB Power Delivery from the included 120W power adapter
Five downstream USB ports, including USB-C and a 7.5W USB-A power-only fast-charge port
Gigabit Ethernet, TRRS headset and separate stereo audio and microphone jacks
USB-A laptop support with optional USB315AC1M cable and documented limitations
Kensington-style security slot, 1m USB-C cable and anti-slip pads included

Compatibility check: Install DisplayLink software and use a USB-C host with DP Alt Mode for the HDMI output. USB-A use requires USB315AC1M, sold separately.

Specifications

Product type	USB-C triple-monitor universal docking station
Host connection	USB-C; USB-A supported with USB315AC1M cable sold separately
Video outputs	2 x DisplayPort (DisplayLink); 1 x HDMI (USB-C DP Alt Mode)
DisplayPort resolution	Up to 4096 x 2160 at 60Hz or 3840 x 2160 at 60Hz per output
HDMI resolution	Up to 4096 x 2160 at 24Hz or 3840 x 2160 at 30Hz
Single 5K mode	5120 x 2880 at 60Hz using both DisplayPort outputs
USB ports	1 x USB-C 5Gbps; 3 x USB-A 5Gbps data; 1 x USB-A 7.5W power-only fast-charge
Networking	Gigabit Ethernet
Audio	3.5mm TRRS headset; separate 3.5mm stereo audio and microphone ports
Laptop charging	Up to 60W USB Power Delivery with USB-C host; unavailable over USB-A
Power adapter	120W adapter included
Dimensions / weight	270 x 82 x 34mm; 385g
Package dimensions / weight	165 x 295 x 73mm; 1,390g
In the box	Dock, 1m USB-C cable, universal power adapter and power cords, anti-slip pads and documentation
UPC	065030867672
Warranty	3 years

SKU	DK30CH2DPPD
Barcode #	65030867672
Brand	STARTECH
Shipping Weight	1.4000kg
Shipping Width	0.100m
Shipping Height	0.050m
Shipping Length	0.290m
Shipping Cubic	0.001450000m3
