RACK PDU, BASIC, HALF HEIGHT, 100-240V/20A, 220-240V/16A, (14) C13

SKU: AP6003A | Brand: APC Brand

Key Features

Features 14 C13 outlets for extensive power distribution
Compact size for flexible installation
Supports up to 20A, 100V to 240V power distribution
Includes toolless mounting kit for quick setup

Description

It is a basic rack PDU with a Zero U vertical mounting design.
It supports a maximum input current of 20A and operates at 100-240V.
The PDU features 14 IEC 60320 C13 outlets, providing ample connections for IT equipment.
It includes an IEC 60320 C20 plug.
The unit is designed for reliable power distribution and includes an installation guide and safety guide.

Product Images

Downloads & Documents

Compatible Products & Accessories

Racks

AR3100

APC NetShelter SX, Server Rack Enclosure, 42U, Black, 1991H ...

AR3003

APC NetShelter SX, Server Rack Enclosure, 12U, Black, 658H x...

AR3006

APC NetShelter SX, Server Rack Enclosure, 18U, Black, 925H x...

AR3103

APC NetShelter SX, Server Rack Enclosure, 12U, Black, 658H x...

AR3105

APC NetShelter SX, Server Rack Enclosure, 45U, Black, 2124H ...

ER6202

APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...

ER8222

APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...

(AP6003A)

Specifications - AP6003A

Overview

Lead time

Usually in Stock

Main

Colour	Black
Product or component type	PDU
PDU type	Basic
Provided equipment	Installation guide Safety guide

Complementary

Input Voltage	230 V
Height	523 mm
Width	56 mm
Output Voltage	100 V 120 V 200 V 208 V 230 V 240 V
Depth	47 mm
Net weight	1.88 kg
Mounting location	Side
Mounting preference	Lower
Input Plug Type	IEC 60320 C20
Mounting mode	Not rack-mountable
Rack units	0U
USB compatible	No
Mounting position	Vertical
[In] rated current	16 A
permissible voltage	100…240 V
Max line current	20 A
Input current limits	20 A
Load capacity	3300 VA
Network frequency	50/60 Hz
Outlet type and quantity	14 IEC 60320 C13

Environment

Product certifications	cUL listed UL listed
Ambient air temperature for operation	0…50 °C
Relative humidity	5…95 %
Operating altitude	0...10000 ft
Ambient air temperature for storage	-15…65 °C
Storage Relative Humidity	5…95 %
Storage altitude	0…15240 m

Packing Units

Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	61.2 cm
Package 1 Width	10.7 cm
Package 1 Length	12.3 cm
Package 1 Weight	2.55 kg
SCC14	10731304327766

Contractual warranty

Warranty (in months)

SKU	AP6003A
Barcode #	731304327769
Brand	APC
Shipping Weight	1.8700kg
Shipping Width	0.011m
Shipping Height	0.061m
Shipping Length	0.012m
