View PDF BrochureGrandstream GWN7062 Wi-Fi 6 802.11ax Wireless dual-band Router
Model # GWN7062
-
SKU: GWN7062
You Might Want To Add
- Pick Up Available
- Australian Warranty
- Checkout Securely
The GWN7062 is a secure dual-band router powered by the latest Wi-Fi 6(802.11ax) technology. Ideal for small offices, home offices, and remote workers, the GWN7062 provides dual-band 2×2 MU-MIMO with DL/UL OFDMA technology and supports wireless Mesh networking and wired AP connections.
The GWN7062 features a powerful 64-bit 1.2Ghz quad-core processor to provide blazing-fast Wi-Fi speeds up to 1.8 Gbps with 4-times increased data capacity to 64 devices, allowing the GWN7062 to power smart office and home automation, smooth 4K Ultra HD streaming, web meetings, video conferences, online gaming and more. It supports VPN to allow remote employees to securely connect to the corporate network from home or branch offices. The GWN7062 also provides enterprise-grade security features to ensure secure Wi-Fi and VPN access, including unique security certificates and random default passwords.
By combining accelerated Wi-Fi speeds, mesh networking, and wired AP connections with advanced features including VPN, beamforming technology, and intelligent QoS, the GWN7062 is the ideal router for a growing home network.
Cordless Wi-Fi Phones
• The GWN7062's Wi-Fi 6 MU-MIMO and UL/DL OFDMA create a wireless environment that can simultaneously serve both Wi-Fi voice devices and typical wireless workstations
• All GWN series devices autorecognize Grandstream WP800 series wireless handsets and automatically share security authentications across the network, creating a seamless roaming experience
Desktop Endpoints
• Grandstream has a variety of Wi-Fienabled desktop phones, deploying these devices will allow for less costly ethernet cabling and a streamlined infrastructure
• QoS standards will keep a highquality experience, whether video conferencing on Grandstream multi-media video phones or calling on one of the GRP series of carriergrade IP phones
Configuration and Management
• Grandstream's GWN routers can be entirely configured and managed from the cloud by using our free GWN.Cloud service, which supports both our Wi-Fi access point and routers*. Full GWN. Cloud integration pending December firmware update, currently only GUI access is available.
• GWN routers support a built-in controller for Grandstream's GWN Wi-Fi access points. In situations where GWN. Cloud cannot be used, a single router can support a small Wi-Fi network deployment Wi-Fi Access Points
• Both routers within the GWN series support Mesh networking with Grandstream
Wi-Fi access points
, allowing for easy network expansion that provides a consistent network connection throughout a residence or small office
(GWN7062)
Wi-Fi Standards IEEE 802.11 a/b/g/n/ac/ax Antennas 4 individual internal antennas, 2 per band 2.4GHz: maximum gain 4.5dBi 5 GHz: maximum gain 5dBi Wi-Fi Data Rates 5G: IEEE 802.11ax: 7.3 Mbps to 1201 Mbps IEEE 802.11ac: 6.5 Mbps to 867 Mbps IEEE 802.11n: 6.5 Mbps to 300 Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 2.4G: IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps IEEE 802.11n: 6.5 Mbps to 300 Mbps IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network Frequency Bands 2.4GHz radio: 2400 – 2483.5 MHz (2412-2472MHz are channel central frequency range; 2400-2483.5MHz is Frequency band) 5GHz radio: 5150 - 5850 MHz *Not all frequency bands can be used in all regions Channel Bandwidth 2.4G: 20 and 40 MHz 5G: 20, 40 and 80 MHz Wi-Fi and System Security WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device MU-MIMO 2×2:2 2.4GHz 2×2:2 5GHz Maximum TX Power 5G: 26dBm 2.4G: 27dBm *Maximum power varies by country, frequency band and MCS rate Receiver Sensitivity 2.4G 802.11b: -97dBm@1Mbps, -89dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7; 802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -63dBm @MCS11 5G 802.11a: -93dBm @6Mbps, -75dBm @54Mbps; 802.11n: 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7 802.11ac 20MHz: -70dBm@MCS8; 802.11ac: HT40:- 66dBm @MCS9; 802.11ac 80MHz: -62dBm @MCS9; 802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -61dBm @MCS11;802.11ax 80MHz: -58dBm @MCS11 Memory and NAT Sessions 512MB RAM, 120K NAT sessions NAT Routing & IPSec VPN Performance 2 Gbps NAT routing and 850Mbps IPSec VPN performance SSIDs 32 SSIDs total, 16 per radio (2.4GHz & 5GHz) Concurrent Wireless Clients Up to 256 wireless clients Network Interfaces 1x Gigabit Ethernet WAN port, 1x Gigabit Ethernet port (WAN/LAN configurable), and 3x Gigabit Ethernet LAN ports Auxiliary Ports 1x USB 3.0 port, 1x Reset button, 1x SYNC button Mounting Desktop LEDs 1 tri-color LED and 7 single-color LEDs for device tracking and status indication Network Protocols IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM QoS 802.11e/WMM, VLAN, TOS Firewall DDNS, Port Forwarding, DMZ, UPnP, Anti-DoS, traffic rules, NAT, ALG VPN Client: L2TP, PPTP, IPSec, OpenVPN Server: IPSec, OpenVPN Network Management GWN7062 embedded controller can manage it self and up to 50 GWN Aps GWN.Cloud offers a free cloud management platform for unlimited GWN7062 routers and GWN APs (coming soon) Power and Green Energy Efficiency Universal power adaptor included: Input 100-240VAC 50-60Hz Output: 12VDC 1.5A (18W); Environmental Operation: 0°Cto 50°C Storage: -30°C to 60°C Humidity: 10% to 90% Non-condensing Physical Unit Dimension: 95mm(L)x95mm(W)x193mm(H); Unit Weight: 690g Entire Package Dimension: 286mm(L)x126.5mm(W)x105mm(H); Entire Package Weight: 960g Package Content GWN7062 Router, Universal Power Supply, Network Cable, Quick Installation Guide Compliance FCC, CE, RCM, IC, UKCA
| SKU | GWN7062 |
| Barcode # | 6947273703600 |
| Brand | GRANDSTREAM |
| Shipping Weight | 3.0000kg |
Manufacturer Warranty: 3 Years Manufacturer Warranty
