NETGEAR WAX214-200APS
NETGEAR (WAX214) AX1800 DUAL BAND POE WIRELESS AP, WIFI-6, DESKTOP

600Mbps (2.4GHz), 1,200Mbps (5.0GHz)

Antenna Gain : 3dBi (2.4GHz), 4dBi (5GHz)

Maximum # of Concurrent Devices : 40

Coverage Area per Unit : 1, 500 sq. ft. (130 sq. m)

Overview:

WiFi 6 high performance PoE Powered wireless connectivity for Small Office and Home Office

The NETGEAR WiFi 6 AX1800 PoE Wireless Access Point (AP) delivers 802.11ax high performance wireless connectivity for Small Office and Home Office (SOHO) deployments and supports dual band concurrent WiFi 6 operations at 2.4GHz and 5GHz with a combined throughput of 1.8Gbps (600Mbps at 2.4GHz and 1200Mbps at 5GHz). The WAX214 WiFi 6 Access Point provides standalone configuration with easy setup for a reliable, WiFi 6 802.11ax high performance, and cost effective wireless solution.

The WAX214 can be powered by Powerover-Ethernet or a DC power adapter.

Highlights

Easy to Configure

• Simple setup in minutes with intuitive Graphical User Interface (GUI)
• Comprehensive monitoring and management through a local web portal user interface

802.11ax high performance and superior coverage

• WiFi 6 802.11ax technology
• Dual band concurrent operation between 2.4GHz and 5GHz frequency ranges
• Maximize coverage for optimal deployment for SOHO

Comprehensive security

• Supports wireless security features (WPA, WPA2 and WPA3)
• MAC based Access Control List to protect against intruders

Convenient Deployment

• Hardware harness included for easy ceiling and wallmount installation
• Flexible options for power source, either by a DC power adapter (included in the WAX214PA model only) or by a PoE Ethernet switch

Interoperate with both new and legacy clients

• Support latest WiFi 6 802.11ax wireless clients to achieve maximum speed
• Backward compatible to allow legacy devices to connect at their fastest speed

Features:

Performance Features

Latest Business WiFi

Upgrade to WIFi 6 with speeds of up to 1.8 Gbps for faster streaming, downloading, video conferencing, and more

Budget Friendly Solution

The perfect WiFi 6 business solution for your small office, retail shop, conference room, or lobby.

Compact with Versatile Mounting

Small size and easy to mount on a wall or ceiling make it ideal for a lobby or retail showroom where you want your access point to be discrete.

Security Features

Secure & Isolated

4 unique SSID’s, WPA3 authentication, and a dedicated Ethernet connection isolate it from the rest of your office network

Ease of Use

Easy DIY Set Up

Easy 10 minute configuration with an intuitive Web GUI. No need for professional installation or IT equipment cost.

Power over Ethernet (PoE+) Powered

Non-Blocking Fabric for Near-Zero Switch Latency

NETGEAR IGMP Plus™

Connect it to your router with a single Ethernet cable for both power and data, without complicated wiring, professional installation, or added IT equipment costs.

(WAX214-100EUS)

Specifications:

NETGEAR WAX214-200APS Specifications
Physical Specification	Dimensions (WxDxH) @mm : 7.71x7.71x1.74 in (196x196x44.4 mm) Weight (kg) : 1.15lb (523g)
Technical Specification	Speed : AX1800 Maximum Theoretical Throughput : 600Mbps (2.4GHz), 1,200Mbps (5.0GHz) Antenna Gain : 3dBi (2.4GHz), 4dBi (5GHz) Maximum Number of Users : 128 Maximum # of Concurrent Devices : 40 Coverage Area per Unit : 1, 500 sq. ft. (130 sq. m) Ideal Use : Small and medium business, home office Ethernet port : 1 x 1G port PoE : Yes PoE Power Consumption : 18W Local management Security : WiFi Protected Access (WPA/WPA2/WPA3), MAC Address filtering, 4 SSID
Support & Warranty	Hardware Limited Warranty 3 years Next-Business-Day (NBD) Replacement 5 years
