UniFi 5G Backup U5G

Compact PoE-powered 5G RedCap antenna system with versatile mounting that plugs into any UniFi PoE port to provide automatic internet backup.

UniFi Mobile App Requirements:
iOS - 10.35.0
Android - 10.38.2

5G RedCap Connectivity

Optimized 5G performance with balanced speed and power efficiency, providing seamless IoT failover.

Flexible SIM and eSIM Support

Support for a Nano SIM and an integrated eSIM enables quick setup and seamless carrier switching.

WAN or LAN Ports

Connect and adopt via UniFi Gateway WAN or LAN ports anywhere on your network.

GbE PoE Port

High-speed data with PoE power over a single cable for clean installs.

(U5G)

What is UniFi 5G Backup?

UniFi 5G Backup is a specialized 5G cellular modem designed to provide reliable internet failover for any UniFi Cloud Gateway or UniFi Gateway. Built on 5G RedCap technology, it ensures your network stays online during primary ISP outages using a highly efficient 5G architecture optimized for reliable, always-on backup connectivity.

What is 5G RedCap, and how does it differ from "standard" 5G?

5G RedCap (Reduced Capability) is a modern cellular standard designed to bridge the gap between legacy 4G LTE and high-performance 5G. While "standard" 5G focuses on extreme gigabit speeds, RedCap prioritizes the core strengths of the 5G network: superior reliability and lower latency. By using a more streamlined hardware architecture, it serves as the ideal successor to ULTE for applications like network backup, where maintaining a consistent, "always-on" connection is more critical than reaching absolute peak throughput.

What kind of speeds should I expect from the UniFi 5G Backup?

The UniFi 5G Backup is built for resilient connectivity rather than peak bandwidth. While 5G RedCap is capable of higher theoretical speeds, real-world performance typically ranges between 30–80 Mbps download and 10–20 Mbps upload, depending on your carrier's signal strength and network congestion.

What is the difference between UniFi 5G Backup and UniFi 5G Max?

Core Technology. The UniFi 5G Backup utilizes 5G RedCap for an efficient, streamlined connection, while the UniFi 5G Max uses Full 5G for maximum performance.

Ideal Use Case. Choose the UniFi 5G Backup for essential business continuity and "always-on" backup; opt for the UniFi 5G Max if you require a high-speed primary WAN or handle heavy data traffic.

Operational Focus. The UniFi 5G Backup emphasizes balanced efficiency for backup scenarios, while the UniFi 5G Max focuses on delivering the full power and bandwidth of the 5G spectrum.

How do I power the UniFi 5G Backup?

The power method depends on how the device is connected:

For LAN Connections: Power the device using any PoE switch or a PoE adapter (not included).
For WAN Connections: Power the device using a PoE adapter (not included) before connecting it directly to your gateway's WAN port.

Does UniFi 5G Backup support eSIM?

Yes. The UniFi 5G Backup features Dual SIM Single Standby (DSSS) functionality: (1) External physical nano-SIM + (1) Internal eSIM.

Important Note for T-Mobile Users: T-Mobile Home Internet SIMs are not supported; please use a data-only plan.

Can UniFi 5G Backup work as a standalone device?

No. The UniFi 5G Backup must be adopted by a UniFi Cloud Gateway or UniFi Gateway and cannot function independently.

Overview
Dimensions
Device: 200 x 38 x 20.2 mm
(7.9 x 1.5 x 0.8")
Table stand: 48.1 x 48 x 55.2 mm
(1.9 x 1.9 x 2.2")
Networking Interface
(1) GbE RJ45 port
5G RedCap and LTE
SIM
(1) Nano-SIM (4FF)
(1) eSIM
PoE Interface
(1) PoE input
Mounting
Desktop stand, wall, window mount (Included)

Mechanical
Weight
Device: 122 g (4.3 oz)
Stand: 138 g (4.9 oz)
Wall mount: 66 g ( 2.3 oz)
Enclosure Material
Polycarbonate, aluminum alloy
Mount Material
Galvanized steel, silicone rubber

Hardware
Management
Ethernet
5G NR
Category
5G RedCap
Frequency Bands
n2, n5, n7, n12, n13, n14, n25 ,n26 ,n30, n38, n41, n48, n66, n71, n77, n78
Max. TX Power
23 dBm
4G LTE
Frequency Bands
B2, B4, B5, B7, B12, B13, B14, B25, B26, B30, B38, B41,B42, B43, B48, B66, B71
Max. TX Power
HPUE power class 2: 26 dBm
Peak Data Speed
5G SA
Downlink 220 Mbps / Uplink 120 Mbps
4G LTE
Downlink 195 Mbps / Uplink 100 Mbps
LTE Throughput Speed
Downlink 195 Mbps / Uplink 100 Mbps
Antennas
Type
(2) Embedded omni-directional cellular antennas
Power Method
PoE
Display
1.14" status display
Buttons
(1) Factory reset
Ambient Operating Temperature
0 to 40 °C (32 to 104 °F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
✓
Certifications
FCC, IC, PTCRB, GCF, AT&T, T-Mobile

Software
Application Requirements
UniFi Network
Version 10.4.57 and later
Mobile App
UniFi iOS™ version 10.35.0 and later
UniFi Android™ version 10.38.2 and later
