StarTech.com ST1000SPEXI

Intel I210 PCIe Gigabit Ethernet network adapter

A 1-port PCI Express Gigabit Ethernet NIC built around the Intel I210-AT controller, with 10/100/1000Mbps RJ45, 9K jumbo frames, VLAN, AVB, PXE and Wake-on-LAN.

Intel I210-AT1 × Gigabit RJ45AVB + PXE + 9K jumbo2-year warranty

StarTech ST1000SPEXI Intel I210 PCIe Gigabit Ethernet NIC

Key capabilities

Intel I210-AT controller

Current exact StarTech documentation identifies the Intel I210-AT chipset.

Gigabit full-duplex throughput

Provides up to 1000Mbps in each direction, 2000Mbps total full-duplex.

Advanced network features

Supports VLAN tagging, 9K jumbo frames, Wake-on-LAN, PXE and Auto-MDIX.

AVB support

Audio-Video Bridging helps support time-sensitive media-stream applications.

What to know before buying

Requires an available PCI Express expansion slot. Advanced features such as AVB, VLAN and PXE depend on host operating system, drivers, BIOS and network configuration.

Australian version and manufacturer warranty

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 2-year manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.

Frequently asked questions

Which chipset does ST1000SPEXI use?

Intel I210-AT.

What network speeds are supported?

10/100/1000Mbps.

What full-duplex throughput is listed?

Up to 2000Mbps total.

Does it support jumbo frames?

Yes, up to 9K.

Does it support VLAN tagging?

Yes.

Does it support AVB and PXE?

Yes, current StarTech documentation lists both.

Is a low-profile bracket included?

Yes.

What warranty applies in Australia?

The Australian version supplied by DeviceDeal is covered by the official StarTech.com 2-year manufacturer warranty in Australia, subject to StarTech.com terms and product assessment.

(ST1000SPEXI)

Features and highlights

Intel I210-AT controller

Current exact StarTech documentation identifies the Intel I210-AT chipset.

Gigabit full-duplex throughput

Provides up to 1000Mbps in each direction, 2000Mbps total full-duplex.

Advanced network features

Supports VLAN tagging, 9K jumbo frames, Wake-on-LAN, PXE and Auto-MDIX.

AVB support

Audio-Video Bridging helps support time-sensitive media-stream applications.

Intel I210-AT
1 × Gigabit RJ45
AVB + PXE + 9K jumbo
2-year warranty

Warranty confidence: Official StarTech.com 2-year manufacturer warranty in Australia, subject to StarTech.com terms and assessment.

Specifications

Verified specifications for StarTech ST1000SPEXI.

Warranty Information

Warranty	2 Years

Hardware

Bus Type	PCI Express
Card Type	Standard Profile (LP bracket incl.)
Chipset ID	Intel - I210-AT
Industry Standards	IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
Industry Standards	IEEE 802.1Q VLAN Tagging
Industry Standards	IEEE 802.3x Full Duplex Flow Control
Ports	1

Performance

Auto MDIX	Yes
Compatible Networks	10/100/1000 Mbps
Full Duplex Support	Yes
Jumbo Frame Support	9K max.
Maximum Data Transfer Rate	2000 Mbps (full-duplex)
Promiscuous Mode	Yes
Supported Protocols	IEEE 802.3ad (link aggregation), IEEE 1588 (time sync)

Connector(s)

Connector Type(s)	1 - PCI Express x1 Male
Connector Type(s)	1 - RJ-45 Female

Software

OS Compatibility	Windows¨ 7, 8, 8.1, 10 Windows Server¨ 2008 R2, 2012 R2, 2016, 2019 Linux 2.4.x to 4.11.x LTS versions only

Special Notes / Requirements

System and Cable Requirements	Available PCI Express expansion card slot

Indicators

LED Indicators	1 - 100/1000 Mbps Indicator
LED Indicators	1 - Link/Activity

Power

Power Consumption (In Watts)	Max 0.8W

Environmental

Humidity	20% ~ 80% RH
Operating Temperature	5°C to 50°C (41°F to 122°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)

Physical Characteristics

Color	Black
Product Height	0.7 in [1.8 cm]
Product Length	4.7 in [12 cm]
Product Width	2.6 in [66 mm]
Weight of Product	1.3 oz [38 g]

Packaging Information

Package Height	1.1 in [28 mm]
Package Length	6.7 in [17 cm]
Package Width	5.6 in [14.2 cm]
Shipping (Package) Weight	3.5 oz [100 g]

What's in the Box

Included in Package	1 - 1 Port Network Card
Included in Package	1 - Low Profile Bracket
Included in Package	1 - Instruction Manual

Current Official Features

PXE Network Boot	Supported
Audio-Video Bridging (AVB)	Supported
Energy Efficient Ethernet	IEEE 802.3az

SKU	ST1000SPEXI
Barcode #	65030861038
Brand	STARTECH
Shipping Weight	0.1000kg
Shipping Width	0.100m
Shipping Height	0.050m
Shipping Length	0.170m
Shipping Cubic	0.000850000m3

2-year official manufacturer warranty

StarTech.com warranty in Australia

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 2-year manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase.

Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment. This wording does not promise automatic replacement or guaranteed claim approval.
