Here’s a powerful and cost-effective solution for upgrading your server or workstation to 10 Gigabit Ethernet networking over copper. This PCI Express 10G NIC lets you add an Ethernet port to your server or desktop computer and access your network at multiple speeds: 10G, 5G, 2.5G 1G and 100Mbps.

Reliable, high-performance connectivity

This 10G network card utilizes the Intel® X550-AT chipset, delivering the power, performance and enhanced capabilities you need for dependable network connections. Compliant with IEEE 802.3u/ab/an standards, the 1-port 10G card delivers a dependable way to upgrade or replace your existing network port, providing throughput capability of up to 10Gbps in each direction (20Gbps total). It connects easily through a single, four-lane (x4 or higher) PCI Express slot.

The Intel X550-AT chipset provides many advanced features including Intel® Virtualization Technology for connectivity and PXE network boot support. The Intel chipset provides many advanced features to support load-balancing the flow of network traffic, to enhance throughput and provide greater data reliability. It supports Audio-Video Bridging (AVB) to enable tightly controlled media stream synchronization, buffering and resource reservation. It also lets you take advantage of advanced features such as VLAN tagging, up to 15K jumbo frame support and Auto MDIX.

Cost-effective and versatile multimode connectivity

This five-speed NIC provides a cost-effective and versatile networking solution, by giving you the additional bandwidth your network needs without having to overhaul your infrastructure wiring. It lets you add an Ethernet port which can be accessed at multiple speeds 10G, 5G, 2.5G 1G and 100Mbps. Compatible with a broad range of operating systems, the 10G NIC is fully compliant with 10GBase-T and NBASE-T™ specifications. (10G network speeds require Cat6a cable. All other speeds require Cat5e cable.)

The PCIe 10G network card features advanced NBASE-T technology, supporting the latest multigigabit equipment, including new Cisco® campus switches and Aruba Networks® access points. The card enables you to connect to NBASE-T based equipment at network speeds of 2.5Gbps or 5Gbps, over your existing Cat5e infrastructure, without having to upgrade to more expensive Cat6a. The Ethernet network card also supports the more common 10G over copper, and 1G network connections using existing Cat 6/Cat5e or better cabling.

Easy installation

With its dual-profile design, the network card is easy to install into a wide range of computer/server chassis, regardless of form factor. The card comes equipped with a full-sized bracket, and includes a low-profile/half-height installation bracket that you can use as needed.

The ST10000SPEXI is backed by a StarTech.com 2-year warranty and free lifetime technical support.


Applications

  • Upgrade your server or workstation to provide enhanced performance, advanced features and greater reliability
  • Upgrade a 10/100/1000 Ethernet port on your computer to 10GbE networking
  • Ideal for high-demand database servers and mission-critical systems that need redundant network connectivity
+ More- Less

(ST10000SPEXI)

Warranty Information
Warranty 2 Years
Hardware
Bus Type PCI Express
Card Type Standard Profile (LP bracket incl.)
Chipset ID Intel - X550AT
Industry Standards IEEE 802.3an (10GBASE-T), IEEE 802.3ab (1GBASE-T), IEEE 802.3u (100BASE-T)
NBASE-T
PCI Express Rev 2.0
IEEE 802.1Q VLAN Tagging
IEEE 802.3x Full Duplex Flow Control
Interface RJ45 (10 Gigabit Ethernet)
Port Style Integrated on Card
Ports 1
Performance
Auto MDIX Yes
Compatible Networks 10 Gbps/5G/2.5G/1G/100 Mbps
Full Duplex Support Yes
Jumbo Frame Support 9K max.
Maximum Data Transfer Rate 10 Gbps
Promiscuous Mode Yes
Supported Protocols IEEE 802.3x (Flow Control Support)
IEEE 802.1Q (VLAN tagging)
Connector(s)
Connector Type(s) 1 - PCI Express x4 Male
Internal Ports 1 - RJ-45 Female
Software
OS Compatibility Windows® 7, 8, 8.1, 10
Windows Server® 2008 R2, 2012, 2012 R2, 2016, 2019
(Windows Drivers are supported in 64-bit only)
Linux 2.4.x to 4.11.x LTS Versions Only
ESXi 5.1/5.5/6.0
Special Notes / Requirements
System and Cable Requirements For Windows, NBase-T support requires Windows 8 or higher
Indicators
LED Indicators 1 - Link/Activity
1 - 10G/1G Speed
Environmental
Humidity 20~80%
Operating Temperature 5°C to 50°C (41°F to 122°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Physical Characteristics
Cable Length 3.9 in [100 mm]
Color Black
Product Height 4.8 in [12.1 cm]
Product Length 6 in [15.2 cm]
Product Width 2.7 in [68.5 mm]
Weight of Product 3.4 oz [96 g]
Packaging Information
Package Height 1.6 in [40 mm]
Package Length 8.2 in [20.9 cm]
Package Width 5.7 in [14.5 cm]
Shipping (Package) Weight 0.4 lb [0.2 kg]
What's in the Box
Included in Package 1 - 10G network card
1 - low-profile bracket
1 - quick-start guide
SKU ST10000SPEXI
Barcode # 65030866156
Brand STARTECH
Shipping Weight 0.1900kg
Shipping Width 0.100m
Shipping Height 0.050m
Shipping Length 0.170m
Shipping Cubic 0.000850000m3
Manufacturer Warranty: 2 Years Limited Warranty
