StarTech 1 Port PCI RS232 Serial Adapter Card - PCI1S550
Model # PCI1S550
-
SKU: PCI1S550
- Pick Up Available
- Australian Warranty
- Checkout Securely
The PCI1S550 16550 Serial PCI Card can be installed in a PCI slot to add one RS232 serial port - a cost-effective solution for connecting any new serial device or old legacy serial device, with data transfer rates of up to 115.2 Kbps.
Perfect for connecting serial modems, POS devices, PDAs, digital cameras, printers, ISDN terminal adapters and more, to your system, the 1 serial port PCI card supports IRQ sharing and operates flawlessly in Windows®, DOS® and Linux® platforms.
A convenient easy to install solution, the PCI serial card can be connected in minutes through simple plug and play installation and is backed by a StarTech.com lifetime warranty and free lifetime technical support.
Applications
- Manufacturing (CNC machinery, process control equipment, bar code scanners, serial printers)
- POS (credit/debit card readers, receipt printers, bar code scanners, cash registers, scales)
- Consumer (modems, PDAs, digital cameras, printers)
The StarTech.com Advantage
- Compatible with any PC running Windows®, DOS® or Linux® for simple integration into your application
- Data transfer rates of up to 115.2 Kbps for efficient serial device performance
- Easy to install and use with full step-by-step instruction providing a hassle free serial solution
(PCI1S550)
| Warranty Information | ||
|---|---|---|
| Warranty | Lifetime | |
| Hardware | ||
| Bus Type | PCI (5 Volt) | |
| Card Type | Standard Profile (LP bracket incl.) | |
| Chipset ID | ASIX - MCS9820CV | |
| Industry Standards | PCI 2.1 | |
| Interface | Serial | |
| Port Style | Integrated on Card | |
| Ports | 1 | |
| Performance | ||
| Max Baud Rate | 115.2 Kbps | |
| MTBF | 6,548,788 Hours | |
| Serial Protocol | RS-232 | |
| Connector(s) | ||
| Connector Type(s) | 1 - PCI (5V, 32-bit) Male | |
| External Ports | 1 - DB-9 (9 pin, D-Sub) Male | |
| Software | ||
| OS Compatibility | Windows® DOS, 95, 98SE, 2000, Embedded System 2009, XP Embedded, POS Ready 2009, XP, Vista, 7, 8, 8.1, 10 Windows Server® 2003, 2008 R2, 2012 Linux 3.5.x to 4.11.x LTS Versions only | |
| Environmental | ||
| Humidity | 5~85% RH | |
| Operating Temperature | -10°C to 80°C (14°F to 176°F) | |
| Storage Temperature | -20°C to 100°C (-4°F to 212°F) | |
| Physical Characteristics | ||
| Product Height | 4.7 in [12 cm] | |
| Product Length | 4.7 in [12 cm] | |
| Product Width | 0.8 in [20 mm] | |
| Weight of Product | 1.8 oz [52 g] | |
| Packaging Information | ||
| Package Height | 1.3 in [32 mm] | |
| Package Length | 5.6 in [14.3 cm] | |
| Package Width | 6.9 in [17.4 cm] | |
| Shipping (Package) Weight | 4.6 oz [130 g] | |
| What's in the Box | ||
| Included in Package | 1 - 1 Port PCI Serial Card | |
| 1 - Low Profile PCI Bracket | ||
| 1 - Driver CD | ||
| 1 - Instruction Manual | ||
| SKU | PCI1S550 |
| Barcode # | 65030785396 |
| Brand | Startech |
| Shipping Weight | 0.1300kg |
| Shipping Width | 0.140m |
| Shipping Height | 0.030m |
| Shipping Length | 0.172m |
| Shipping Cubic | 0.000722000m3 |
