StarTech 2x M.2 SATA SSD Controller Card - PCIe PEX2M2
Dual-slot M.2 SATA SSD controller card for installing two B-key M.2 SATA drives in a PCIe x4 or larger desktop slot.
Frequently asked questions
What does PEX2M2 do?
Adds two M.2 SATA III drive positions through PCIe, supporting common 2230, 2242, 2260, 2280 and 22110 form factors.
Who is this product best for?
Expanding internal SATA SSD storage, reusing laptop M.2 SATA drives or recovering data from compatible M.2 SATA media.
What should I check before ordering?
This card supports M.2 SATA B-key drives, not PCIe/NVMe M-key drives. It requires a PCIe x4 or larger slot and does not provide RAID.
Does it require drivers or software?
The controller is operating-system independent and requires no additional drivers or software.
What is included in the package?
Dual M.2 SATA controller card, low-profile bracket, M.2 mounting hardware and quick-start guide.
What is the key installation requirement?
Mount compatible M.2 SATA drives to the card, secure them with the supplied hardware and install the card in a PCIe x4 or larger slot.
Is it suitable for an Australian setup?
Yes. DeviceDeal supplies the Australian-market version; always confirm the available ports, power and system compatibility for your installation.
What warranty applies?
PEX2M2 carries a StarTech.com 2 years manufacturer warranty, subject to the manufacturers terms and eligibility requirements.
Planning a broader setup? Browse the DeviceDeal buying guides. View the DeviceDeal product page.
(PEX2M2)
Why choose PEX2M2?
PEX2M2 specifications
Exact-model specifications for compatibility checking.
| Warranty Information | |
|---|---|
| Warranty | 2 Years |
| Hardware | |
| Bus Type | PCI Express |
| Card Type | Standard Profile (LP bracket incl.) |
| Chipset ID | ASMedia - ASM1062 |
| Industry Standards | Serial ATA 3.0 specification - SATA I/II/III (1.5/3/6Gbps) |
| Interface | M.2 SATA |
| Port Style | Integrated on Card |
| Ports | 2 |
| Performance | |
| Port Multiplier | No |
| RAID | No |
| Type and Rate | SATA III (6 Gbps) |
| Connector(s) | |
| Connector Type(s) | 1 - PCI Express x4 Male |
| Internal Ports | 2 - M.2 (SATA, B-Key, NGFF) Receptacle |
| Additional Internal Port | 1 - SP4 (4 pin, Small Drive Power) |
| Software | |
| OS Compatibility | OS Independent; No additional drivers or software required |
| Special Notes / Requirements | |
| Note | The maximum throughput of this card is limited by the bus interface. If used with PCI Express Gen 1.0 enabled computers, the max throughput is 2.5Gbps per lane. If used with PCI Express Gen 2.0 enabled computers, the max throughput is 5Gbps per lane. |
| System and Cable Requirements | PCI Express x4 slot (backward compatible with x8, and x16 slots) |
| Environmental | |
| Humidity | 20%~80% RH (Non-condensing) |
| Operating Temperature | 5°C to 50°C (41°F to 122°F) |
| Storage Temperature | -25°C to 70°C (-13°F to 158°F) |
| Physical Characteristics | |
| Product Height | 4.7 in [12 cm] |
| Product Length | 7.1 in [18 cm] |
| Product Width | 0.8 in [20 mm] |
| Weight of Product | 2.2 oz [62 g] |
| Packaging Information | |
| Package Height | 1.9 in [48 mm] |
| Package Length | 6.3 in [16 cm] |
| Package Width | 8.6 in [21.8 cm] |
| Shipping (Package) Weight | 5.9 oz [167 g] |
| What's in the Box | |
| Included in Package | 1 - M.2 SATA SSD controller card |
| Additional Items | 1 - low-profile bracket; M.2 mounting hardware; 1 - quick-start guide |
