Tycon Power • TP-MS616

Tycon Power TP-MS616 16-Port 1U Gigabit Managed IEEE 802.3af/at PoE Midspan - 576W

The Tycon Power TP-MS616 is a 16-port managed Gigabit PoE midspan supporting IEEE 802.3af/at and forced passive operation, with up to 40W per port and a stated 576W total capacity.

16 PoE ports 802.3af/at Up to 40W/port 576W total Managed Gigabit

Product highlights

Key supplied and exact-model details for the TP-MS616.

Sixteen central PoE channels

The 1U rackmount unit supplies data and PoE to as many as 16 connected devices.

IEEE 802.3af/at support

Ports support standards-based detection and can also be configured for forced passive output.

High per-port power

Maximum output is stated as up to 40W per individual port.

576W chassis capacity

The complete rack unit is specified with a maximum power capacity of 576W.

Managed operation

The RJ45 management interface and supplied PC software support port enable/disable, mode selection and status.

AC or DC power input

The unit accepts 120/240VAC or 56VDC input.

Buy with confidence from DeviceDeal

DeviceDeal is an authorised Tycon Power reseller. This product is supplied with the applicable Tycon Power manufacturer warranty in Australia, subject to the manufacturer’s current terms, eligibility requirements and product assessment.

Frequently asked questions

Helpful answers based on the supplied and exact-model product information.

How many devices can the TP-MS616 power?

It provides 16 Gigabit PoE midspan channels.

Which PoE standards are supported?

The unit supports IEEE 802.3af and IEEE 802.3at.

How much power is available?

The manufacturer states up to 40W per port and up to 576W total.

Can ports be forced into passive mode?

Yes. Ports can be configured for forced passive output, but compatibility must be confirmed before use.

How is the unit managed?

The front-panel RJ45 interface and supplied PC software provide configuration and status functions.

What warranty applies?

DeviceDeal is an authorised Tycon Power reseller. The applicable manufacturer warranty applies, subject to Tycon Power’s terms and assessment.

(TP-MS616)

Technical specifications

Tycon Power TP-MS616

Product details
Brand Tycon Power
Model TP-MS616
Product type Managed high-power Gigabit PoE midspan injector
PoE port count 16
Rack format 19-inch 1U
Power and PoE
Power input 120/240VAC or 56VDC
PoE output voltage 55VDC stated
PoE standards IEEE 802.3af and 802.3at
Forced passive mode Supported
Maximum power per port 40W
Maximum total power 576W
Output protection Overload and short-circuit protection
Networking and management
Network data rate Gigabit Ethernet
Management Front-panel RJ45 or network connection with PC software
Maximum stated cable distance Up to 100m
SKU TP-MS616
Brand TYCON POWER
DeviceDeal authorised reseller

Tycon Power manufacturer warranty

DeviceDeal is an authorised reseller of Tycon Power. The TP-MS616 is supplied with the applicable Tycon Power manufacturer warranty in Australia. Warranty coverage and claims remain subject to the manufacturer’s current terms, eligibility requirements and product assessment.

Manufacturer warranty The applicable Tycon Power manufacturer warranty applies. No unverified warranty duration has been stated.
Keep your proof of purchase Retain your DeviceDeal tax invoice or order record to support a warranty request.
Assessment process Eligibility and the available remedy are determined under Tycon Power’s warranty terms and product assessment process.
Warranty approval, replacement, repair or other remedy is not automatic and is not represented as on-site service.
