TP-Link TL-POE10R PoE Splitter



What This Product Does

The PoE Splitter TL-POE10R fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PSE (Power Source Equipment) or PoE Supplier Adapter, such as TP-LINK's T1600G-52PS, TL-SG1008PE or TL-POE150S, or other equivalent product, to deliver 12V, 9V or 5V Direct Current to where there are no power line or outlet, where you wish to fix device such as AP, IP Camera or IP Phone, etc.

(TL-PoE10R)

HARDWARE FEATURES
Interface 2 10/100/1000Mbps RJ45 Port
AUTO Negotiation/AUTO MDI/MDIX
1 POWER OUTPUT PORT (5.5 mm round barrel)
Network Media 10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
Power Supply 12VDC 1A, 9VDC 1A, 5VDC 2A selectable
Basic Function Compatible With IEEE 802.3af Compliant PSEs
Delivers Power Up To 100 Meters
Optional 12VDC, 9VDC or 5VDC Power Output
LED Indicator PWR
Dimensions ( W x D x H ) 3.2 × 2.1 × 0.9 in.
(81 × 54 × 24 mm)
SOFTWARE FEATURES
Basic Function Compatible with IEEE 802.3af compliant power sources (PSE)
Delivers power up to 100 meters
Selectable 12VDC, 9VDC or 5VDC power output
OTHERS
Certification FCC, RoHS
Package Contents PoE Splitter TL-POE10R
Power Cord
RJ45 Cable
Installation Guide
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
SKU TL-PoE10R
Barcode # 6935364030490
Brand TP-Link
Shipping Weight 0.2300kg
Shipping Width 0.100m
Shipping Height 0.050m
Shipping Length 0.190m
Shipping Cubic 0.000950000m3

Manufacturer Warranty: 3 Years Limited Warranty

Be The First To Review This Product!

Help other DeviceDeal users shop smarter by writing reviews for products you have purchased.

Write a product review

TP-Link TL-POE10R PoE Splitter

Model # TL-POE10R

  • SKU: TL-PoE10R

$12.60
In Stock
