Dimensions: 196.4 x 93.5 x 32.4 mm ( 7.73 x 3.68 x 1.28")
• Weight: 288g (10.2 oz)
• Enclosure: White Polycarbonate
• Interface Connections:
    (1) 1 Gbps SFP Port
    (1) DC Terminal Block
    (1) DC RJ45 Port DC Injection
    (1) 1000 Mbps Ethernet PoE Port1
• Typical Power Consumption: 1.5W
• Power Method:
    DC Terminal Block, 2-Wire, 24VDC or 50VDC
    DC In RJ45 Port, 2-Pair (4, 5+; 7, 8-) (24VDC Input), or
      4-Pair (24VDC or 50VDC Input) Passthrough
    PoE RJ45 Port, 2-Pair (4, 5+; 7, 8-) (24VDC Input), or
      4-Pair (24VDC or 50VDC Input) PoE Passthrough
• PoE Output: PoE RJ45 Port, 2-Pair (4, 5+; 7, 8-) (24VDC), or 4-Pair (24VDC or 50VDC) PoE
• DC Output Terminal Block, 2-Wire (24VDC or 50VDC)
• Input DC Voltage 16 to 57V
• Surge Protection Built-In High-Current Gas Discharge Tube for DC Terminal Block and PoE Port
• LED White: Power On, Blue: Connected, Blue (Flashing): Activity
• Operating Temperature -40 to 60° C2 (-40 to 140° F)
• Operating Humidity 10 to 95% Noncondensing
• ESD/EMP Protection ± 24kV Contact / Air for Ethernet
• Certifications: CE, FCC, IC
