NETGEAR WAX220-100APS
NETGEAR (WAX220) AX4200 DUAL BAND POE WIRELESS AP, WIFI-6, DESKTOP, 3YR WTY

5GHz: 4x4 20/40/80/160MHz
2.4GHz: 2x2 20/40MHz
Small and medium business, home office
Ethernet port : 1 x 2.5G port

Overview:

High Performance WiFi 6 Access Points Insight WAX615 for the Small and Medium Size Businesses

The NETGEAR WiFi 6 AX4200 PoE Wireless Access Point (AP) delivers 802.11ax high performance wireless connectivity for Small Office and Home Office (SOHO) deployments and supports dual band concurrent WiFi 6 operations at 2.4GHz and 5GHz with a combined throughput of 4.2Gbps (600Mbps at 2.4GHz and 3600Mbps at 5GHz). The WAX220 WiFi 6 Access Point provides standalone configuration with easy setup for a reliable, WiFi 6 802.11ax high performance, and cost effective wireless solution.

The WAX220PA is powered by Powerover-Ethernet or a DC power adapter.

Business Features for higher speed, greater coverage and higher density WiFi

Easy to Configure

• Simple setup in minutes with intuitive Graphical User Interface (GUI)
• Comprehensive monitoring and management through a local web portal user interface

802.11ax high performance and superior coverage

• WiFi 6 802.11ax technology
• Dual band 4x4 (transmit x receive) concurrent operation between 2.4GHz and 5GHz frequency ranges
• Maximize coverage for optimal deployment for SOHO

Comprehensive security

• Supports wireless security features (WPA, WPA2 and WPA3)
• MAC based Access Control List to protect against intruders

Convenient Deployment

• Hardware harness included for easy ceiling and wallmount installation
• Flexible options for power source, either by a DC power adapter (included in the WAX220PA model only) or by a PoE Ethernet switch

Interoperate with both new and legacy clients

• Support latest WiFi 6 802.11ax wireless clients to achieve maximum speed
• Backward compatible to allow legacy devices to connect at their fastest speed

Features:

Performance Features

LATEST BUSINESS WIFI

Upgrade to WIFi 6 with speeds of up to 4.2 Gbps for faster streaming, downloading, video conferencing, and more.

BUDGET FRIENDLY SOLUTION

The perfect WiFi 6 business solution for your small office, retail shop, conference room, or lobby.

COMPACT WITH VERSATILE MOUNTING

Small size and easy to mount on a wall or ceiling make it ideal for a lobby or retail showroom where you want your Access Point to be discrete

Security Features

SECURE & ISOLATED

4 unique SSID’s, WPA3 authentication, and a dedicated Ethernet connection isolate it from the rest of your office network

Ease of Use

POWER OVER ETHERNET(PoE+) POWERED

Connect it to your router with a single Ethernet cable for both power and data, without complicated wiring, professional installation, or added IT equipment costs.

EASY DIY SET UP

Easy 10 minute configuration with an intuitive Web GUI. No need for professional installation or IT equipment cost.

(WAX220-100APS)

Specifications:

NETGEAR WAX220-100APS Specifications
Physical Specification	Dimensions (WxDxH) @mm : 7.71 x 7.71 x 1.74 in (196 x 196 x 44.4 mm) Weight (kg) : 1.15lb (523g)
Technical Specification	Speed : AX4200 Radio : 5GHz: 4x4 20/40/80/160MHz 2.4GHz: 2x2 20/40MHz Theoretical Throughput : 5GHz: 3.6Gbps 2.4GHz: 0.6Gbps Antenna Gain : 5dBi (2.4GHz), 5dBi (5GHz) # of Max Users : 256 # of Concurrent Devices : 75 Coverage : 2,000 sqft (185 sqm) Ideal Use : Small and medium business, home office Ethernet port : 1 x 2.5G port PoE : Yes PoE Power Consumption : 15W Local management Security : WiFi Protected Access (WPA/WPA2/WPA3), MAC Address filtering, 4 SSID
Support & Warranty	Hardware Limited Warranty 3 years Next-Business-Day (NBD) Replacement 5 years
