Product Information

Product Type

Product Type

• Outdoor AP

Hardware Specifications

Wi-Fi Radio

Radio design

• Dual-radio
  4 spatial streams
  ● 2.4 GHz: 2 x 2, MU-MIMO
  ● 5 GHz: 2 x 2, MU-MIMO

Maximum wireless data rate

• 1774 Mbps

6 GHz wireless data rate

• No

5 GHz wireless data rate

• 1201 Mbps

2.4 GHz wireless data rate

• 573 Mbps

Antenna

Antenna

• 2.4 GHz: 2 built-in omnidirectional antennas
  5 GHz: 2 built-in omnidirectional antennas

Dimensions and Weight

Product dimensions (W x D x H)

• 298 mm x 298 mm x 65 mm (11.73 in. x 11.73 in. x 2.56 in.) (excluding the mounting bracket)

Color

• White

Weight

• ≤ 1.35 kg (2.98 lbs.) (without packaging materials)

Port Specifications

Number of 10/100/1000BASE-T ports

• 1

Number of 1GE SFP ports

• 1

Power Supply and Consumption

Power supply

• PoE+

Local power supply

• No

Dimensions of the DC connector

• No

PoE budget

• No

Maximum power consumption

• 18 W

Environment and Reliability

Operating temperature

• –40°C to +65°C (–40°F to +149°F)

Mounting options

• Wall/Pole

IP rating

• IP68

Software Specifications

WLAN

Maximum number of associated wireless clients

• 64 (2.4 GHz)
  256 (5 GHz)
  256 (2.4 GHz and 5 GHz enabled)

Maximum number of devices that can be managed

• 300

IP Service

IPv6

• Yes

Manuffacturer Warranty: 3 Years Manuffacturer Warranty
