TP-LINK EAP650-DESKTOP Omada AX3000 Desktop Dual-Band Wi-Fi 6 Access Point
Model # EAP650-DESKTOP
-
SKU: EAP650-DESKTOP
- Pick Up Available
- Australian Warranty
- Checkout Securely
Omada AX3000 Desktop Wi-Fi 6 Access Point
- Blazing-Fast AX3000 Wi-Fi 6 Speeds: 574 Mbps on 2.4 GHz and 2402 Mbps on 5GHz totals 2976 Mbps Wi-Fi speeds. †
- Multiple Gigabit Ports: Connect multiple devices with 4× Gigabit Ethernet Ports.
- Convenient Deployment: Supports both 802.3bt PoE++ and DC (adapter included) for easy and quick deployment.
- No Installation needed:Supports desktop installation without the need for additional setup.
- High Flexibility: Provide flexible installation solutions for both desktop and wall mounting.
- Stay Smooth with Seamless Roaming: Users can enjoy seamless streaming across the property with their devices switching effortlessly between access points.§
- Centralised Cloud Management: Integrates with the Omada SDN platform for Centralised Management. §
(EAP650-DESKTOP)
| Category | Specification |
|---|---|
| Hardware Features | |
| Interface | 4× 1 Gbps Ethernet Ports + 1× FXS Port (One Ethernet port supports PoE Out: 802.3at/af output at 802.3bt input, 802.3af class 2 output at 802.3at input) |
| Buttons | Reset, LED |
| Power Supply | 802.3 af/at/bt PoE or 12V/1.5A DC *PoE Out requires 802.3at/bt PoE power supply |
| Max. Power Consumption | 17.3W (PoE Out Off) |
| Weight | 452 g (excluding mounting base) |
| Dimensions (W × D × H) | 6.9 × 5.5 × 1.3 in (175 × 140 × 33 mm) |
| Antennas | Internal Omni Antennas: - 2.4 GHz: 2× 5 dBi - 5 GHz: 3× 4.7 dBi |
| Range | 140 ㎡ (1500 ft²)* |
| Mounting | Desktop / Wall mounting (kits included) |
| Wireless Features | |
| Concurrent Clients | 250+* |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | - 5 GHz: 2402 Mbps† <br> - 2.4 GHz: 574 Mbps |
| Wireless Functions | - 2×2 MU-MIMO (2.4G & 5G)‡ <br> - HE160 (160 MHz Bandwidth)‡ <br> - OFDMA‡ <br> - Seamless Roaming§ <br> - Multiple SSIDs (16 total: 8 per band) <br> - Enable/Disable SSID Broadcast <br> - Enable/Disable Wireless Radio <br> - Guest Network <br> - Automatic Channel Assignment <br> - Beamforming <br> - Rate Limit (SSID/Client) <br> - Band Steering <br> - Load Balance <br> - Airtime Fairness <br> - Transmit Power Control (dBm) <br> - QoS (WMM) <br> - RADIUS Accounting <br> - MAC Authentication <br> - Reboot & Wireless Schedule <br> - Wireless Statistics <br> - Static IP / Dynamic IP |
| Wireless Security | - Captive Portal Authentication§ <br> - Access Control <br> - MAC Address Filtering <br> - Client Isolation <br> - VLAN <br> - Rogue AP Detection <br> - 802.1X Support <br> - WPA-Personal/Enterprise <br> - WPA2-Personal/Enterprise <br> - WPA3-Personal/Enterprise |
| Transmission Power | CE: <br> - <20 dBm (2.4 GHz, EIRP) <br> - <23 dBm (5 GHz bands 1 & 2) <br> - <29 dBm (5 GHz band 3) <br> FCC: <br> - <26 dBm (2.4 GHz) <br> - <27 dBm (5 GHz) |
| Management Features | |
| Omada App | Yes |
| Centralized Management | Omada Hardware Controller <br> Omada Software Controller <br> Omada Cloud-Based Controller |
| Cloud Access | Yes |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging | Local / Remote Syslog |
| SSH | Yes |
| Web-Based Management | Yes |
| Zero-Touch Provisioning | Yes (Requires Omada Cloud-Based Controller) |
| Others | |
| Certification | CE, FCC, RoHS, IC |
| Package Contents | - EAP650-Desktop <br> - Desktop/Wall Mounting Kit <br> - Installation Guide <br> - Power Adapter |
| System Requirements | Microsoft Windows XP/Vista/7/8/10/11, Linux |
| Environment - Operating | Temp: 0–40 ℃ (32–104 ℉), Humidity: 10%–90% RH non-condensing |
| Environment - Storage | Temp: -40–70 ℃ (-40–158 ℉), Humidity: 5%–90% RH non-condensing |
| SKU | EAP650-DESKTOP |
| Barcode # | 8885020623734 |
| Brand | TP-LINK |
| Shipping Weight | 1.0000kg |
