StarTech.com RKCONSUV10

10 ft (3 m) USB/VGA KVM cable for StarTech rack consoles

A 10 ft (3 m) KVM cable engineered for compatible StarTech RKCONS rackmount LCD consoles and KVM switches, providing VGA video and USB server connectivity.

10 ft / 3 mVGA + USBUp to 1920 x 1200Lifetime warranty

StarTech RKCONSUV10 USB VGA KVM cable for StarTech rackmount consoles

Key capabilities

Designed for RKCONS consoles

Engineered for the supported StarTech RKCONS rackmount LCD console and KVM switch family.

VGA and USB connectivity

Provides the VGA and USB connections required by compatible VGA/USB-equipped servers.

HD video support

When used with a compatible HD rackmount console, the 10 ft cable supports resolutions up to 1920 x 1200, including 1080p.

Rack-friendly cable routing

The combined KVM lead reduces separate long VGA and USB cable runs between the rack console and server.

What to know before buying

Compatibility is product-specific. StarTech lists RKCONS1701, RKCONS17HD, RKCONS1708K, RKCONS1716K, RKCONS1901, RKCONS1908K and RKCONS1916K among the supported models. Confirm the exact console or KVM model before ordering.

Australian version and manufacturer warranty

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com Lifetime manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.

Frequently asked questions

What is the StarTech RKCONSUV10 used for?

It connects a compatible StarTech RKCONS rackmount LCD console or KVM switch to a VGA and USB-equipped server over a 10 ft (3 m) cable run.

Which RKCONS models are listed as supported?

StarTech lists RKCONS1701, RKCONS17HD, RKCONS1708K, RKCONS1716K, RKCONS1901, RKCONS1908K and RKCONS1916K.

What video resolution can the cable support?

With a compatible HD rackmount console, it supports resolutions up to 1920 x 1200, including 1080p.

What server-side connections are provided?

The cable provides VGA and USB Type-A connections for a compatible VGA/USB-equipped server.

What cable jacket material is used?

The supplied exact-SKU specification lists PVC with aluminium-Mylar foil and braided shielding.

What connector plating is used?

The exact specification lists nickel-plated connectors.

What is included in the package?

The package contains one KVM cable.

What warranty applies to the StarTech RKCONSUV10 in Australia?

The Australian version supplied by DeviceDeal is covered by the official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com terms and product assessment.

(RKCONSUV10)

Features and highlights

Designed for RKCONS consoles

Engineered for the supported StarTech RKCONS rackmount LCD console and KVM switch family.

VGA and USB connectivity

Provides the VGA and USB connections required by compatible VGA/USB-equipped servers.

HD video support

When used with a compatible HD rackmount console, the 10 ft cable supports resolutions up to 1920 x 1200, including 1080p.

Rack-friendly cable routing

The combined KVM lead reduces separate long VGA and USB cable runs between the rack console and server.

10 ft / 3 m
VGA + USB
Up to 1920 x 1200
Lifetime warranty

Warranty confidence: Official StarTech.com lifetime manufacturer warranty in Australia, subject to StarTech.com warranty terms and assessment.

Specifications

Verified specifications for StarTech RKCONSUV10.

General

Warranty	Lifetime
Cable length	10 ft [3 m]
Intended use	Compatible StarTech RKCONS rackmount LCD consoles and KVM switches
Supported resolution with compatible HD console	Up to 1920 x 1200 including 1080p

Connectors

Connector A	VGA (15-pin, High Density D-Sub) male
Connector B	USB Type-A (4-pin) USB 2.0 male
Additional connector	VGA (14-pin, High Density D-Sub) male
Connector plating	Nickel

Construction

Cable jacket type	PVC - Polyvinyl Chloride
Cable shield type	Aluminum-Mylar Foil with Braid

Physical Characteristics

Product length	3 m [10 ft]
Product width	3 cm [1.2 in]
Product height	1.5 cm [0.6 in]
Weight of product	8.1 oz [230 g]

Packaging and In the Box

Package length	8.7 in [22 cm]
Package width	0.4 in [1 cm]
Package height	7.9 in [200 mm]
Shipping weight	8.3 oz [235 g]
Included in package	1 × KVM Cable

SKU	RKCONSUV10
Barcode #	65030881791
Brand	STARTECH
Shipping Weight	0.3200kg
Shipping Width	0.100m
Shipping Height	0.050m
Shipping Length	0.200m
Shipping Cubic	0.001000000m3
