This TAA compliant 4-port industrial USB 2.0 hub gives you the scalability you need in harsh industrial environments, product and repair labs, conference rooms or office workstations. With its rugged industrial grade metal housing, it is designed to meet the advanced requirements of connecting a high number of devices in factories and office environments. Perfect for Harsh Environments This industrial USB hub delivers reliable performance with a metal, heavy-duty housing. It supports wide-range 7-48V DC terminal block input, giving you the flexibility to power the hub as required, based on your own power input capabilities. Perfect for more extreme environments, the rugged hub also supports a wide operating temperature range (-40°C to 85°C) and offers ESD protection to each USB port, which can help prevent damage to your connected devices. Connect More USB Devices Designed for a high volume of connections, this robust USB 2.0 hub offers four connection ports, for connecting more USB devices and peripherals. Locate the Hub Where You Need It Most With versatile installation options, you can install the hub where it’s best suited for your environment. With built-in mounting brackets, included DIN mount rails, and an included 2-meter USB host cable, you can securely mount the USB 2.0 hub to most surfaces such as a wall, under a desk or rack. Works with Older USB Devices The rugged USB hub supports the full 480 Mbps bandwidth of USB 2.0 and is backward compatible with previous USB devices. The HB20A4AME is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Extended Temperature| 15kV Air | 8kV Contact?| Metal | Mountable | DIN Rail | 480 Mbps - 4-Port USB 2.0 Hub - Industrial - ESD Protection
4-Port Industrial USB 2.0 Hub with ESD Protection & 350W Surge Protection

(HB20A4AME)

Hardware
USB-C Host Connection	No
Indicators
LED Indicators	Port Connection
	Power
Packaging Information
Package Height	55 mm [2.2 in]
Package Length	24 cm [9.4 in]
Package Width	17 cm [6.7 in]
Shipping (Package) Weight	504 g [17.8 oz]
Performance
Device Power Consumption (In Watts)	12 Watts
ESD Protection	+/-15kV (Air)
	+/-8kV (Contact)
Maximum Data Transfer Rate	480 Mbps
Surge Protection	350W on the DFP and UFP
Total Available Power Output (In Watts)	10 Watts
Type and Rate	USB 2.0 - 480 Mbit/s
Physical Characteristics
Enclosure Type	Metal
Form Factor	Industrial
Product Height	3.2 cm [1.3 in]
Product Length	95 mm [3.7 in]
Product Width	55 mm [2.2 in]
Weight of Product	292 g [10.3 oz]
Power
Input Current	2A
Input Voltage	7 ~ 48 DC
Power Consumption (In Watts)	14 W
Power Source	Terminal Block
Prominence
Description CDW 75 - 1st Line	StarTech.com 4-Port Industrial USB 2.0 Hub with ESD & 350W Surge Protection
Software
OS Compatibility	OS independent; No software or drivers required
Special Notes / Requirements
System and Cable Requirements	Any computer with a USB 2.0 port
What's in the Box
Included in Package	2 m [6.6 ft] USB-A to USB-B cable
	DIN rail kit
	instruction manual
	USB 2.0 hub
Hardware
USB-C Device Port(s)	No
Ports	4
Interface	USB 2.0
Industry Standards	USB 2.0
Chipset ID	Genesys Logic - GL852GT
Bus Type	USB 2.0
Environmental
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Operating Temperature	-40°C to 85°C (-40°F to 185°F)
Humidity	5 - 95% RH
Connector(s)
External Ports	USB Type-A (4 pin) USB 2.0 Female
	USB B (4 pin) Female
	Terminal Block (3 Wire)

SKU	HB20A4AME
Barcode #	65030878623
Brand	STARTECH
Shipping Weight	0.5000kg
Shipping Width	0.100m
Shipping Height	0.050m
Shipping Length	0.240m
Shipping Cubic	0.001200000m3
