StarTech Thunderbolt 3 to USB 3.1 Controller Adapter, 1x USB-C, 3x A - TB33A1C
Model # TB33A1C
-
SKU: TB33A1C
- Pick Up Available
- Australian Warranty
- Checkout Securely
This Thunderbolt 3 USB 3.2 Gen 2 multi-channel hub controller delivers maximum USB performance, adding four high-speed independent USB ports to your Thunderbolt 3 laptop. It provides three dedicated USB controllers and up to 20Gbps of aggregated bandwidth for USB devices, ideal for connecting bandwidth-demanding devices such as 3D scanners.
The Thunderbolt 3 hub lets you access multiple USB devices at greater bandwidth and improved performance, and extend the life of your USB devices.
Maximize USB Performance
The high-speed USB hub provides two 10Gbps ports for connecting high-performance devices such as storage arrays, 3D scanners, audio-video devices, and external SSDs, with dedicated bandwidth for faster read/write access. The second Thunderbolt 3 port can be used to connect an additional USB-C device with up to 10G bandwidth.
Dedicated Independent Port Bandwidth
When only one USB port is in use, the full 10Gbps bandwidth is available to the device. Two additional USB-A ports provide 5Gbps of bandwidth to each device simultaneously, ideal for portable hard drives or flash drives. For added convenience, the front USB-A port supports both data and charging of your mobile device.
Extend Your Workstation
The Thunderbolt 3 hub features a second Thunderbolt 3 port to connect an additional display to your laptop (a USB-C video adapter may be required). The port can also be used to connect additional Thunderbolt devices, daisy-chaining up to six devices.
The TB33A1C is backed by a StarTech.com 2-year warranty and free lifetime technical support.
(TB33A1C)
| Warranty Information | ||
|---|---|---|
| Warranty | 2 Years | |
| Hardware | ||
| Bus Type | Thunderbolt 3 | |
| USB 3.1 Gen 2 | ||
| USB 3.1 Gen 1 | ||
| Chipset ID | Intel - Alpine Ridge JHL6540 ASMedia - ASM1042A ASMedia - ASM1142 | |
| Fast-Charge Port(s) | No | |
| Industry Standards | Thunderbolt 3 USB Battery Charging Specification Rev. 1.2 Universal Serial Bus 3.1 Specifications Revision 1.0 Universal Serial Bus Specification Revision 2.0 Extensible Host Controller Interface Specification revision 1.1 USB Attached SCSI Protocol Revision 1.0 | |
| Ports | 4 | |
| USB-C Device Port(s) | Yes | |
| USB-C Host Connection | No | |
| Performance | ||
| Maximum Data Transfer Rate | Aggregate Bandwidth 20Gbit/s | |
| MTBF | 1,936,146 hours | |
| Type and Rate | USB 3.1 Gen 2 - 10 Gbit/s | |
| USB 3.1 Gen 1 - 5 Gbit/s | ||
| UASP Support | Yes | |
| Connector(s) | ||
| Connector Type(s) | 2 - Thunderbolt™ 3 USB-C (24-pin) (40Gbps) Female | |
| 2 - USB Type-A (9 pin) USB 3.0 Female | ||
| 1 - USB 3.1 USB Type-A (9 pin, Gen 2, 10 Gbps) Female | ||
| 1 - USB Type-C (24 pin) USB 3.1 (10Gbps) Female | ||
| Software | ||
| OS Compatibility | Windows® 7, 8, 8.1, 10 macOS 10.12 - 10.3 | |
| Special Notes / Requirements | ||
| Note | When connecting a display to the Thunderbolt 3 USB-C port, a USB-C video adapter might be required depending on the input of your display. | |
| Secondary Thunderbolt 3 port can also be used to connect USB 3.1 (10Gbps) USB-Type C devices, such as USB 3.1 Storage Enclosure or Hubs. Backwards compatible with USB 3.1 Gen 1 (USB 3.0), and USB 2.0. | ||
| USB 3.1 Gen 1 is also known as USB 3.0; this connectivity standard offers speeds up to 5Gbps. USB 3.1 Gen 2 offers speeds up to 10Gbps. | ||
| System and Cable Requirements | Thunderbolt 3 equipped computer with a Thunderbolt 3 port. | |
| Your laptop's Thunderbolt 3 port must support USB Power Delivery 2.0 in order to power and charge your laptop. | ||
| Power | ||
| Center Tip Polarity | Positive | |
| Input Current | 1.8 A | |
| Input Voltage | 100 - 240 AC | |
| Output Current | 3.25 A | |
| Output Voltage | 20V DC | |
| Plug Type | N | |
| Power Consumption (In Watts) | 65W | |
| Power Delivery | 15W | |
| Power Source | AC Adapter Included | |
| Environmental | ||
| Humidity | 90% RH | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) | |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) | |
| Physical Characteristics | ||
| Cable Length | 19.7 in [50 cm] | |
| Color | Silver & Black | |
| Enclosure Type | Aluminum | |
| Form Factor | Desktop | |
| Product Height | 0.9 in [2.4 cm] | |
| Product Length | 5.8 in [14.8 cm] | |
| Product Width | 2.9 in [74 mm] | |
| Weight of Product | 7.1 oz [200 g] | |
| Packaging Information | ||
| Package Height | 4.6 in [11.6 cm] | |
| Package Length | 11.2 in [28.5 cm] | |
| Package Width | 7.3 in [18.5 cm] | |
| Shipping (Package) Weight | 3.4 lb [1.6 kg] | |
| What's in the Box | ||
| Included in Package | 1 - Thunderbolt 3 controller | |
| 1 - Thunderbolt 3 Cable (50 cm) | ||
| 1 - universal power adapter (NA/JP, UK, EU, ANZ) | ||
| 1 - quick-start guide | ||
| SKU | TB33A1C |
| Barcode # | 65030871204 |
| Brand | Startech |
| Shipping Weight | 1.5500kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.050m |
| Shipping Length | 0.280m |
| Shipping Cubic | 0.001400000m3 |
