Dual-band AC1200 wireless
The 2.4 GHz radio supports 802.11b/g/n with a maximum rate of 300 Mbit/s. The 5 GHz radio supports 802.11a/n/ac with a maximum rate of 867 Mbit/s. Both radios use two chains, with an AC1200 wireless speed class.
MikroTik wAP ac AC1200 Dual-Band Outdoor Access Point, Black
-
SKU: RBwAPG-5HacD2HnD-BE
$147.00
Stock Availability
🟢Live
In Stock · 10+ available
Pickup from Vermont, VIC
Allow 1–2 business days for stock transfer
Allow 1–2 business days for stock transfer
- Pick Up Available
- Australian Warranty
- Checkout Securely
MikroTik wAP ac AC1200 Dual-Band Outdoor Access Point, Black
The black MikroTik wAP ac provides concurrent 2.4 GHz and 5 GHz wireless coverage in a compact weatherproof enclosure. This revision includes two Gigabit Ethernet ports, a quad-core processor and 128 MB of RAM.
End-of-life product. Available only while current and expected arriving stocks last.
Discreet installation
The unit can be fixed to an external wall from inside the case, with an anti-vandal screw and a rear opening for concealed Ethernet cabling. Ceiling mounting is also supported. The enclosure measures 185 × 85 × 30 mm and has IP54 protection.
Power and software
Use the DC jack at 1057 V or 802.3af/at PoE input at 1857 V. RouterOS is preinstalled and licensed. Software updates are included for the product's life or a minimum of five years from purchase.
Product video
Product documents
(RBwAPG-5HacD2HnD-BE)
Features
- Black enclosure, model RBwAPG-5HacD2HnD-BE
- Concurrent dual-band AC1200 wireless
- Two Gigabit Ethernet ports
- Quad-core processor and 128 MB RAM
- IP54 weatherproof enclosure
- 802.3af/at PoE or DC jack power input
- Anti-vandal screw and concealed rear cable routing
- Preinstalled, licensed RouterOS
Specifications
Product specifications
| Product code | RBwAPG-5HacD2HnD-BE |
|---|---|
| Architecture | ARM 32bit |
| CPU | IPQ-4018 |
| CPU core count | 4 |
| CPU nominal frequency | 488-896 (auto) MHz |
| Switch chip model | IPQ-4018 |
| Dimensions | 185 x 85 x 30 mm |
| RouterOS license | 4 |
| Operating System | RouterOS |
| Size of RAM | 128 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 100'000 hours at 25C |
| IPsec hardware acceleration | Yes |
| Tested ambient temperature | -40°C to 70°C |
Powering
| Number of DC inputs | 2 (DC jack, PoE-IN) |
|---|---|
| DC jack input Voltage | 10-57 V |
| Max power consumption | 10 W |
| Max power consumption without attachments | 10 W |
| Cooling type | Passive |
| PoE in | 802.3af/at |
| PoE in input Voltage | 18-57 V |
Ethernet
| 10/100/1000 Ethernet ports | 2 |
|---|
Certification & Approvals
| Certification | CE, FCC, IC, EAC, ROHS |
|---|---|
| IP | IP54 |
Other
| PCB temperature monitor | Yes |
|---|---|
| Voltage Monitor | Yes |
Wireless specifications
| Wireless 2.4 GHz Max data rate | 300 Mbit/s |
|---|---|
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 2.5 |
| Wireless 2.4 GHz chip model | IPQ-4018 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
| WiFi speed | AC1200 |
| Wireless 5 GHz Max data rate | 867 Mbit/s |
| Wireless 5 GHz number of chains | 2 |
| Wireless 5 GHz standards | 802.11a/n/ac |
| Antenna gain dBi for 5 GHz | 2.5 |
| Wireless 5 GHz chip model | IPQ-4018 |
| Wireless 5 GHz generation | Wi-Fi 5 |
2.4 GHz TX/RX
| 2.4 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 1MBit/s | 25 | -100 |
| 11MBit/s | 25 | -94 |
| 6MBit/s | 25 | -96 |
| 54MBit/s | 19 | -78 |
| MCS0 | 25 | -96 |
| MCS7 | 18 | -73 |
5 GHz TX/RX
| 5 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 6MBit/s | 24 | -96 |
| 54MBit/s | 20 | -80 |
| MCS0 | 24 | -96 |
| MCS7 | 19 | -75 |
| MCS9 | 17 | -70 |
Additional product details
| Colour | Black |
|---|---|
| Mounting | Ceiling/wall |
| Product lifecycle | End of life; available while current and expected arriving stocks last |
| SKU | RBwAPG-5HacD2HnD-BE |
| Brand | MIKROTIK |
| Shipping Weight | 3.0000kg |
Warranty assistance
For warranty assistance, contact DeviceDeal and quote product SKU RBwAPG-5HacD2HnD-BE.
