Ruijie Reyee • RG-EST330F-P

Ruijie Reyee RG-EST330F-P 5GHz 867Mbps 3km Wireless Bridge - Single Unit

The Ruijie Reyee RG-EST330F-P is a single outdoor wireless bridge unit for point-to-point or point-to-multipoint links at recommended distances up to 3km. It combines a 5GHz 867Mbps 2x2 radio, 13dBi directional antenna, three Fast Ethernet ports and two PoE output ports with flexible power input options.

3km recommended distance 867Mbps 5GHz radio 13dBi directional antenna

Product highlights

Features and capabilities

Key supplied and exact-model vendor information is organised below for faster product comparison.

3km recommended distance

Supports outdoor point-to-point and point-to-multipoint links up to the specified distance.

867Mbps 5GHz radio

Uses Wi-Fi 5 with 2x2 MIMO for the bridge connection.

13dBi directional antenna

Integrated directional gain supports long-distance outdoor alignment.

Three Fast Ethernet ports

Includes two PoE output ports for compatible downstream devices.

Three power-input options

Supports 12V DC, passive PoE and IEEE 802.3af/at input.

Cloud and app management

Supports remote configuration, monitoring and management through Ruijie Cloud and app.

?

Authorised reseller and manufacturer warranty

DeviceDeal is an authorised reseller of Ruijie Reyee. This product is supplied with the applicable 3-year Ruijie Reyee manufacturer warranty, subject to the manufacturer's terms and assessment.

Frequently asked questions

Before you buy

Is the RG-EST330F-P sold as a pair?

No. This SKU is a single bridge unit.

What distance is recommended?

The supplied specification recommends links up to 3km.

How many Ethernet and PoE-out ports are provided?

It has three 10/100Mbps Ethernet ports, including two PoE output ports.

Which power-input methods are supported?

It supports 12V DC, passive PoE and IEEE 802.3af/at power input.

What is the outdoor rating?

The product is rated IP55 and specified for operation from -30°C to 55°C.

What warranty applies to the RG-EST330F-P?

DeviceDeal is an authorised reseller of Ruijie Reyee. This product is covered by a 3-year Ruijie Reyee manufacturer warranty, subject to the manufacturer's terms, eligibility requirements and product assessment.

(RG-EST330F-P)

Technical specifications

Ruijie Reyee RG-EST330F-P 5GHz 867Mbps 3km Wireless Bridge - Single Unit

BrandRuijie Reyee
ModelRG-EST330F-P
Product TypeOutdoor wireless bridge, single unit
Primary Bridge Radio5GHz Wi-Fi 5, 2x2 MIMO
Management Radio2.4GHz 1x1
Maximum Wireless Rate867Mbps
Antenna Gain13dBi directional
Horizontal Beamwidth30°
Vertical Beamwidth30°
Recommended Distance3km
Ethernet Ports3 x 10/100Mbps
PoE Output Ports2
Power Input Options12V DC, passive PoE, IEEE 802.3af/at
PoE Input1 x PoE input and 1 x PoE/PoE+ input
Deployment ModesPoint-to-point and point-to-multipoint
TDMASupported
Self-Organising NetworkSupported
Ingress ProtectionIP55
Operating Temperature-30°C to 55°C
Relative Humidity5% to 95%, non-condensing
Dimensions103 x 53.4 x 199mm, excluding bracket
Weight0.37kg
CertificationCE
ManagementRuijie Cloud and app
Manufacturer Warranty3 years
SKU RG-EST330F-P
Brand REYEE
Shipping Weight 1.4200kg

DeviceDeal authorised reseller support

3-Year Ruijie Reyee Manufacturer Warranty

DeviceDeal is an authorised reseller of Ruijie Reyee. The RG-EST330F-P is covered by a 3-year Ruijie Reyee manufacturer warranty.

Manufacturer coverageCoverage is provided under the applicable Ruijie Reyee manufacturer warranty terms.
Proof of purchaseRetain the DeviceDeal tax invoice as the purchase record for any warranty request.
Assessment appliesEligibility, remedy and claim approval remain subject to the manufacturer's terms and product assessment.
Warranty service does not imply automatic replacement or guaranteed claim approval. Physical damage, misuse, unsupported installation or other exclusions may affect coverage under the manufacturer's terms.
