StarTech.com ST124PRO

4-port high-resolution VGA splitter with 350MHz amplifier

A professional 1×4 VGA distribution amplifier that mirrors one VGA source to four monitors or projectors with up to 350MHz video bandwidth, 2048×1536 at 80Hz and 65m reach.

1 input / 4 outputs2048×1536 @ 80Hz350MHz bandwidth2-year warranty

StarTech ST124PRO 4-port high-resolution VGA splitter

Key capabilities

Four VGA outputs

Distributes one VGA source to four displays simultaneously.

2048×1536 at 80Hz

Supports high-resolution analogue VGA output.

350MHz bandwidth

Professional analogue video bandwidth for supported deployments.

65m signal amplification

Built-in booster extends compatible VGA signals up to 210ft / 65m.

What to know before buying

A male-to-female VGA extension cable such as MXT101HQ is required for extended display connections. The splitter mirrors the source on all outputs.

Australian version and manufacturer warranty

This item is the Australian version supplied by DeviceDeal and is covered by the official StarTech.com 2-year manufacturer warranty in Australia.

Please retain your DeviceDeal tax invoice as proof of purchase. Warranty coverage and claims are subject to StarTech.com warranty terms, eligibility requirements and product assessment.

Frequently asked questions

How many displays can ST124PRO drive?

Four VGA monitors or projectors.

What maximum resolution is supported?

Up to 2048×1536 at 80Hz.

What bandwidth is listed?

350MHz.

What is the maximum extension distance?

Up to 65m / 210ft.

Does it mirror or extend the desktop?

It mirrors one source to all four outputs.

What extension cable is required?

A male-to-female VGA extension cable is required.

Is it TAA compliant?

Yes.

What warranty applies in Australia?

The Australian version supplied by DeviceDeal is covered by the official StarTech.com 2-year manufacturer warranty in Australia, subject to StarTech.com terms and product assessment.

(ST124PRO)

Features and highlights

Four VGA outputs

Distributes one VGA source to four displays simultaneously.

2048×1536 at 80Hz

Supports high-resolution analogue VGA output.

350MHz bandwidth

Professional analogue video bandwidth for supported deployments.

65m signal amplification

Built-in booster extends compatible VGA signals up to 210ft / 65m.

1 input / 4 outputs
2048×1536 @ 80Hz
350MHz bandwidth
2-year warranty

Warranty confidence: Official StarTech.com 2-year manufacturer warranty in Australia, subject to StarTech.com terms and assessment.

Specifications

Verified specifications for StarTech ST124PRO.

Warranty Information

Warranty	2 Years

Hardware

Video Input	1 × VGA
Video Outputs	4 × VGA
Function	VGA splitter / distribution amplifier

Performance

Maximum Resolution	2048×1536 @ 80Hz
Video Bandwidth	350MHz
Maximum Extension	65m [210ft]

Requirements

Display Cable	Male-to-female VGA extension cable required

SKU	ST124PRO
Barcode #	65030783101
Brand	STARTECH
Shipping Weight	0.7200kg
Shipping Width	0.100m
Shipping Height	0.050m
Shipping Length	0.240m
Shipping Cubic	0.001200000m3
