This 4K HDMI splitter lets you connect your HDMI video source to eight HDMI displays, with support for Ultra HD resolutions and HDR (High Dynamic Range) as well as 7.1 surround sound audio. Supports true 4K at 60Hz This 8-port 4K 60Hz HDMI splitter offers full support for your HDMI 2.0 equipment, including true 4K resolution at 60Hz. For smoother video and color transitions, the splitter offers 4:4:4 chroma subsampling, meaning every pixel gets its own unique color. Support for HDMI 2.0 devices means this splitter can transmit bandwidth up to 18Gbps, making it the ideal solution for high-resolution tasks requiring the highest color detail. Note: In order to support 4K 60Hz coming through the splitter, each device in the chain must support HDCP 2.2. Widely compatible The splitter supports HDCP 2.2 and is backward compatible with 4K 30Hz and 1080p displays. This ensures that it will work with lower resolution displays such as TVs or projectors around your site or in your digital signage application. Easy installation and setup The 4K HDMI splitter offers easy plug-and-play installation with no additional software or drivers required. The splitter passes EDID between your video source and the display attached to port 1, ensuring native settings such as resolution and refresh rate are configured automatically. The ST128HD20 is backed by a 2-year StarTech.com warranty.
Easily distribute an HDMI 4K60 signal to up to eight monitors with this HDMI 2.0 splitter - 8-Port HDMI Video Splitter - 4K 60Hz
8-Port 4K 60Hz HDMI Splitter

(ST128HD20)

Indicators
LED Indicators	input LED
	output LEDs
	power LED
Packaging Information
Package Height	70 mm [2.8 in]
Package Length	32.5 cm [12.8 in]
Package Width	26 cm [10.2 in]
Shipping (Package) Weight	1.2 kg [2.7 lb]
Performance
Audio Specifications	7.1 surround sound
Maximum Digital Resolutions	3840x2160 (4K) @ 60Hz
Supported Resolutions	2560x1600 1920x1200 1920x1080 (1080p) 1280x720 (720p)
Wide Screen Supported	Yes
Physical Characteristics
Product Height	2.6 cm [1 in]
Product Length	25.8 cm [10.2 in]
Product Width	11 cm [4.3 in]
Weight of Product	762 g [26.9 oz]
Power
Center Tip Polarity	Positive
Input Current	0.6A
Input Voltage	100 - 240 AC
Output Current	3 A
Output Voltage	5 DC
Plug Type	M
Power Consumption (In Watts)	15 W
Special Notes / Requirements
Note	Connect the HDMI display with the lowest resolution and refresh rate capability to output #1 If HDCP 1.4 display is connected to port #1 the whole system defaults to HDCP 1.4.
	This video splitter is not compatible with the AMD Radeon RX460 graphics card
What's in the Box
Included in Package	HDMI splitter
	set of mounting brackets
	universal power adapter (NA/JP, UK, EU, ANZ)
Hardware
Ports	9
Industry Standards	HDMI 2.0
	HDCP 2.2
Cabling	HDMI
AV Output	HDMI
AV Input	HDMI
Audio	Yes
Environmental
Storage Temperature	-10? to 70?
Operating Temperature	0 ? to +45?
Humidity	10% to 85 % RH (no condensation)
Connector(s)
Connector B	HDMI (19 pin) Female
Connector A	HDMI (19 pin) Female

SKU	ST128HD20
Barcode #	65030876049
Brand	STARTECH
Shipping Weight	1.2200kg
Shipping Width	0.260m
Shipping Height	0.080m
Shipping Length	0.330m
Shipping Cubic	0.006864000m3
