QNAP TS-h987XU-RP-E2334-16G, 9-Bay 2U rackmount NAS, Intel Xeon
Model # TS-h987XU-RP-E2334-16G
-
SKU: TS-h987XU-RP-E2334-16G
- Pick Up Available
- Australian Warranty
- Checkout Securely
9-bay 1U QuTS hero hybrid-storage NAS
QNAP TS-h987XU-RP-E2334-16G 9-Bay Xeon 10GbE 1U NAS
The QNAP TS-h987XU-RP-E2334-16G combines four 3.5-inch SATA bays and five 2.5-inch U.2/U.3 NVMe or SATA SSD bays with an Intel® Xeon® E-2334, 16GB ECC DDR4, dual 10GBASE-T, dual 2.5GbE and redundant power.
9 baysXeon® E-2334Dual 10GbERedundant powerQNAP manufacturer warranty
What is the QNAP TS-h987XU-RP-E2334-16G?
It is a 1U QuTS hero rackmount NAS designed to balance HDD capacity and U.2/U.3 NVMe or SATA SSD performance with server-grade processing, built-in 10GbE and redundant power.
Feature group 1
Hybrid HDD and NVMe storage
The 1U architecture balances capacity-focused SATA storage with five SSD positions.
Four SATA bays
The 3.5-inch bays support compatible 3.5-inch SATA hard drives and 2.5-inch SATA solid state drives.
Five SSD bays
The 2.5-inch bays support U.2/U.3 NVMe PCIe SSDs and SATA SSDs with a maximum drive height of 7mm.
Different PCIe interfaces
Bays 13 use PCIe Gen 3 x2 plus SATA, while bays 45 use PCIe Gen 4 x4 plus SATA.
Feature group 2
Server-grade processing and ECC memory
The supplied configuration combines an Intel® Xeon® processor with expandable ECC memory.
Xeon® E-2334
The processor provides four cores, eight threads, a 3.4GHz base frequency and speeds up to 4.8GHz.
16GB ECC DDR4
Installed memory supports expansion to 128GB across four ECC UDIMM DDR4 slots.
Identical-module requirement
For dual-DIMM configurations, the supplied information requires a pair of identical DDR4 modules.
Need help choosing a NAS?
Read NAS Buying Guide
Explore the DeviceDeal NAS Buying Guide
Compare NAS types, storage planning considerations and practical buying factors before selecting a system.
Feature group 3
High-speed networking and expansion
Built-in 10GbE and 2.5GbE can be extended through PCIe.
Dual 10GBASE-T
Two ports support 10G, 5G, 2.5G, 1G and 100M speeds.
Dual 2.5GbE
Two additional ports support 2.5G, 1G and 100M.
PCIe Gen 4 x8
The expansion slot supports compatible network, QM2, Fibre Channel or SATA expansion cards, including optional 25GbE.
Feature group 4
QuTS hero workloads and supplied performance
ZFS-based protection features support virtualisation, backup and hybrid-cloud use.
Data protection
The supplied feature set includes self-healing, WORM, inline data reduction, QSAL, snapshots and SnapSync.
Virtualisation and backup
The supplied content lists VMware Ready, Hyper-V, Citrix, Veeam Ready, SaaS backup, VM backup and containers.
QNAP Labs throughput
Supplied testing recorded 2,953/2,940MB/s read/write with one 25GbE link and 5,876/5,901MB/s with two 25GbE links. Results vary by environment.
Frequently asked questions
What is the QNAP TS-h987XU-RP-E2334-16G?
It is a 9-bay QuTS hero hybrid-storage rackmount NAS with an Intel® Xeon® E-2334, 16GB ECC memory, built-in 10GbE and redundant power.
What rack form factor does the TS-h987XU-RP-E2334-16G use?
The detailed description and technical specifications identify a 1U rackmount form factor with dimensions of 43.3 × 430 × 479mm.
How are the nine drive bays configured?
It has four 3.5-inch SATA bays and five 2.5-inch U.2/U.3 NVMe PCIe or SATA SSD bays.
Which interfaces do the five 2.5-inch bays use?
Bays 13 support PCIe Gen 3 x2 and SATA 6Gbps, while bays 45 support PCIe Gen 4 x4 and SATA 6Gbps.
Which processor is installed?
It uses an Intel® Xeon® E-2334 with four cores, eight threads, a 3.4GHz base frequency and speeds up to 4.8GHz.
How much memory is included and supported?
It includes 16GB ECC DDR4 memory and supports up to 128GB across four ECC UDIMM slots.
What network ports are built in?
It includes two 10GBASE-T ports and two 2.5GbE ports.
Can 25GbE networking be added?
Yes. Optional 25GbE connectivity is supported through a compatible PCIe adapter.
What PCIe expansion slot is included?
The NAS includes one PCIe Gen 4 x8 slot.
Does it support SSD cache acceleration?
Yes. SSD cache acceleration is supported.
What QNAP Labs throughput figures are supplied?
The supplied test records 2,953MB/s read and 2,940MB/s write with one 25GbE link, and 5,876MB/s read and 5,901MB/s write with two links. Results may vary by environment.
What warranty applies to the TS-h987XU-RP-E2334-16G?
The supplied specifications list a five-year QNAP manufacturer warranty. Coverage is subject to QNAPs applicable warranty terms.
(TS-h987XU-RP-E2334-16G)
Features and highlights
Key product details organised from the supplied QNAP information for TS-h987XU-RP-E2334-16G.
1U hybrid architecture
Four 3.5-inch SATA bays and five 2.5-inch U.2/U.3 NVMe or SATA SSD bays are included.
Xeon® E-2334
Four-core, eight-thread processing reaches up to 4.8GHz.
16GB ECC memory
The platform supports expansion to 128GB.
Dual 10GbE and dual 2.5GbE
Four built-in network ports support multi-gigabit connectivity.
PCIe Gen 4 x8
Compatible adapters can add 25GbE, QM2, Fibre Channel or SATA expansion.
Redundant 300W power
Two power supply units are included.
Purchase check: The 2.5-inch bays support drives up to 7mm in height. M.2 storage is optional through a compatible QM2 PCIe adapter, and M.2 SSD hot swapping is not supported.
Technical specifications
The following specifications are organised from the supplied product information for QNAP TS-h987XU-RP-E2334-16G.
Product details
| Brand | QNAP |
|---|---|
| Model / SKU | TS-h987XU-RP-E2334-16G |
| Product type | 9-bay 1U hybrid-storage rackmount NAS |
Processor and Memory
| CPU | Intel® Xeon® E-2334, 4 cores / 8 threads, 3.4GHz, up to 4.8GHz |
|---|---|
| CPU Architecture | 64-bit x86 |
| Encryption Engine | Yes (AES-NI) |
| System Memory | 16GB ECC DDR4 |
| Maximum Memory | 128GB (4 x 32GB) |
| Memory Slots | 4 x ECC UDIMM DDR4 For dual-DIMM configuration, use a pair of identical DDR4 modules. |
Storage
| Drive Bays | 9 total: 4 x 3.5-inch SATA + 5 x 2.5-inch U.2 PCIe / SATA |
|---|---|
| 2.5-inch Bay Interfaces | #1: PCIe Gen 3 x2 and SATA 6Gbps #2: PCIe Gen 3 x2 and SATA 6Gbps #3: PCIe Gen 3 x2 and SATA 6Gbps #4: PCIe Gen 4 x4 and SATA 6Gbps #5: PCIe Gen 4 x4 and SATA 6Gbps |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch U.2/U.3 NVMe PCIe solid state drives 2.5-inch SATA solid state drives The 2.5-inch bays support drives with a maximum height of 7mm. |
| Hot-Swappable | Yes The datasheet states: Not supported M.2 SSD. |
| M.2 Slot | Optional via a QM2 PCIe adapter |
| SSD Cache Acceleration | Yes |
Networking
| 2.5 Gigabit Ethernet | 2 x 2.5GbE ports (2.5G/1G/100M) |
|---|---|
| 10 Gigabit Ethernet | 2 x 10GBASE-T ports (10G/5G/2.5G/1G/100M) |
| 25 Gigabit Ethernet | Optional via a PCIe adapter |
| Wake on LAN | Yes |
Expansion and Connectivity
| PCIe Slot | 1 x PCIe Gen 4 x8 Maximum card dimensions: 215 x 68.9 x 18.76mm / 8.46 x 2.71 x 0.74 inches. |
|---|---|
| USB Ports | 4 x USB 3.2 Gen 2 Type-A ports, 5V/1A, 10Gbps |
Physical Specifications
| Form Factor | 1U rackmount |
|---|---|
| LED Indicators | Status (green/red), LAN (green), HDD status (green/red) |
| Buttons | Power, reset |
| Dimensions (H x W x D) | 43.3 x 430 x 479mm |
| Net Weight | 9.5kg |
| Gross Weight | 11.5kg |
Power and Cooling
| Power Supply Unit | 300W PSU x 2 |
|---|---|
| Disk Standby Power Consumption | 114.6W |
| Typical Operating Power Consumption | 120.58W |
| Fans | 4 x 40mm, 12VDC |
Operating Environment
| Operating Temperature | 040°C (32104°F) |
|---|---|
| Storage Temperature | -2070°C (-4158°F) |
| Relative Humidity | 595% RH non-condensing, wet bulb: 27°C (80.6°F) |
Warranty and Connections
| Standard Warranty | 5 years |
|---|---|
| Maximum Concurrent CIFS Connections | 11,000 with maximum memory installed |
| SKU | TS-h987XU-RP-E2334-16G |
| Model # | TS-h987XU-RP |
| Barcode # | 885022024650 |
| Brand | QNAP |
| Shipping Weight | 13.8000kg |
| Shipping Width | 0.540m |
| Shipping Height | 0.540m |
| Shipping Length | 0.540m |
Five yearsQNAP manufacturer warranty
5-year QNAP manufacturer warranty
The supplied specifications list a 5-year manufacturer warranty for QNAP TS-h987XU-RP-E2334-16G.
Warranty coverage, eligibility and claim assessment are subject to QNAPs applicable warranty terms. Please retain your DeviceDeal tax invoice as proof of purchase.
