AMD Ryzen 16-bay rackmount NAS

QNAP TS-1673AU-RP-16G 16-Bay 3U Rackmount NAS

A diskless 16-bay, 3U rackmount NAS with an AMD Ryzen Embedded V1500B 4-core/8-thread processor, 16GB DDR4 memory, dual 2.5GbE, two PCIe Gen 3 slots and redundant power.

16 bays16GB DDR4Dual 2.5GbE3-year manufacturer warranty

QNAP TS-1673AU-RP-16G 16-bay 3U AMD Ryzen rackmount NAS

What is the QNAP TS-1673AU-RP-16G?

It is a diskless 16-bay, 3U business NAS powered by an AMD Ryzen Embedded V1500B 4-core/8-thread 2.2GHz processor. This configuration includes 16GB DDR4 memory, dual 2.5GbE, two PCIe Gen 3 x4 slots and dual 550W power supplies, with support for QTS or QuTS hero.

16 baysSATA HDD and SSD support

4C / 8TAMD Ryzen V1500B

16GB DDR4Up to 64GB supported

2 × PCIeGen 3 x4 expansion

Need help choosing a NAS?

Explore the DeviceDeal NAS Buying Guide

Compare NAS types, storage considerations and practical features before selecting your next network attached storage solution.

Read NAS Buying Guide

AMD Ryzen processing and expandable memory

The AMD Ryzen Embedded V1500B provides four cores and eight threads at 2.2GHz with AES-NI encryption acceleration. This 16GB configuration supports up to 64GB across two UDIMM DDR4 slots, and ECC memory is supported.

64-bit x86 architecture.
For dual-DIMM configurations, use a pair of identical DDR4 modules.
The supplied source positions the platform for VDI, research and development, private cloud and server virtualisation.

2.5GbE networking and PCIe expansion

Two 2.5GbE ports support 2.5G, 1G, 100M and 10M speeds. The supplied description states that Port Trunking can provide up to 5Gbps combined transfer speed.

Two PCIe Gen 3 x4 slots support compatible networking, SSD caching, USB, wireless, Fibre Channel or graphics cards.
Wake on LAN is supported through the 2.5GbE ports only.
Optional HDMI output and hardware-accelerated transcoding are available through a compatible PCIe graphics card.

Storage efficiency and virtualisation

The supplied information lists Qtier, SSD caching, virtual machines, containers and block-based or file-based cloud storage gateways with local caching. Optional M.2 SSD support is available through a QNAP QM2 PCIe card.

QTS or QuTS hero with redundant power

The TS-1673AU-RP supports QTS and QuTS hero, allowing the operating system to be selected according to deployment requirements. Two 550W power supplies provide redundant power for rack deployment.

Important buying and deployment notes

The product is supplied without hard drives.
Use a pair of identical DDR4 modules for dual-DIMM configurations.
M.2 SSD support and HDMI output require compatible PCIe cards.
The supplied award wording refers to the QuTS hero operating system rather than clearly to this exact product.

Frequently asked questions

What is the QNAP TS-1673AU-RP-16G?

It is a diskless 16-bay, 3U rackmount NAS with an AMD Ryzen Embedded V1500B processor, 16GB DDR4 memory, dual 2.5GbE, dual PCIe expansion and redundant power.

Does the TS-1673AU-RP-16G include hard drives?

No. The supplied product information states that the system is supplied without hard drives.

Which processor is installed?

It uses an AMD Ryzen Embedded V1500B four-core, eight-thread processor running at 2.2GHz.

How much memory is included and supported?

This configuration includes 16GB UDIMM DDR4 memory and supports up to 64GB across two memory slots. ECC memory is supported.

Which drives are supported?

Its sixteen 3.5-inch SATA bays support 3.5-inch SATA hard drives and 2.5-inch SATA solid state drives.

Which network ports are included?

It includes two 2.5GbE ports supporting 2.5G, 1G, 100M and 10M speeds.

Can Port Trunking increase combined bandwidth?

Yes. The supplied description states that Port Trunking can provide up to 5Gbps combined transfer speed.

Does the NAS support PCIe expansion?

Yes. It has two PCIe Gen 3 x4 slots for compatible networking, SSD caching, USB, wireless, Fibre Channel or graphics cards.

Can M.2 SSDs be added?

Yes. Optional M.2 SSD support is available through a compatible QNAP QM2 PCIe card.

Which operating systems are supported?

The supplied information states that the TS-1673AU-RP supports both QTS and QuTS hero.

Does it have redundant power supplies?

Yes. It includes two 550W power supply units.

What warranty applies to the TS-1673AU-RP-16G?

The supplied specifications list a three-year QNAP manufacturer warranty.

(TS-1673AU-RP-16G)

Features and highlights

Key supplied capabilities and purchasing considerations for this QNAP product.

AMD Ryzen V1500B

Four cores and eight threads at 2.2GHz with AES-NI acceleration.

16-bay rack storage

Sixteen SATA bays support 3.5-inch HDDs and 2.5-inch SSDs.

16GB expandable memory

The supplied configuration includes 16GB and supports up to 64GB with ECC support.

Dual 2.5GbE

Two built-in Multi-Gig ports with a supplied Port Trunking claim of up to 5Gbps.

Two PCIe Gen 3 slots

Expansion options include networking, SSD caching, USB, wireless, Fibre Channel and graphics.

3-year manufacturer warranty

The supplied specifications list a three-year QNAP manufacturer warranty.

Key points to review

Diskless system; compatible drives are required.
Optional M.2 and HDMI require compatible PCIe cards.
QTS and QuTS hero are both listed.
Dual 550W power supplies are included.

QNAP TS-1673AU-RP-16G Specifications

Review the supplied processor, memory, storage, networking, expansion, physical, power, environmental and warranty details.

Processor and Memory

CPU	AMD Ryzen Embedded V1500B 4-core/8-thread 2.2GHz processor
CPU architecture	64-bit x86
Encryption engine	Yes (AES-NI)
Hardware-accelerated transcoding	Optional via a PCIe graphics card
System memory	16GB UDIMM DDR4
Maximum memory	64GB (2 × 32GB)
Memory slots	2 × UDIMM DDR4; ECC memory supported
Dual-DIMM note	Use a pair of identical DDR4 modules

Storage

Drive bays	16 × 3.5-inch SATA 6Gb/s, 3Gb/s; system supplied without HDDs
Drive compatibility	3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
Hot-swappable	Yes; not supported for M.2 SSDs
M.2 slot	Optional via a QNAP QM2 PCIe card
SSD cache acceleration	Supported
GPU pass-through	Yes

Networking

2.5 Gigabit Ethernet	2 × 2.5GbE ports (2.5G/1G/100M/10M)
5 Gigabit Ethernet	Optional via a network adapter
10 Gigabit Ethernet	Optional via a network adapter
Wake on LAN	Yes; supported through the 2.5GbE ports only
Jumbo Frame	Yes

Expansion and Connectivity

PCIe slots	2 × PCIe Gen 3 x4
With riser card	Slot 1: up to 160 × 68.9 × 18.76mm; Slot 2: up to 160 × 68.9 × 39.08mm
Without riser card	Slot 1: up to 160 × 111.15 × 39.08mm
Wider-card note	Wider cards can be installed if the adjacent PCIe slot is not used
USB 3.2 Gen 1	1 × Type-A
USB 3.2 Gen 2, 10Gbps	2 × Type-C and 1 × Type-A
HDMI output	Optional via a PCIe graphics card

Physical Specifications

Form factor	3U rackmount
LED indicators	HDD 116, status, LAN, USB and power
Buttons	Power and reset
Dimensions (H × W × D)	131.3 × 432 × 370.9mm; excludes the ear hook and protruding part of the power supply unit
Net weight	13.53kg
Gross weight	17.15kg

Power and Cooling

Power supply	550W × 2, 100240V AC, 5060Hz, 73.5A
Disk standby power	47.75W
Typical operating power	97.34W; tested fully populated with WD10EFRX hard drives
Fans	3 × 80mm, 12VDC
System warning	Buzzer

Operating Environment

Operating temperature	040°C (32104°F)
Storage temperature	-2070°C (-4158°F)
Relative humidity	595% RH non-condensing, wet bulb: 27°C (80.6°F)

Warranty and Connections

Standard warranty	3 years
Maximum concurrent CIFS connections	2,000 with maximum memory installed

Use QNAP memory modules with identical specifications to maintain system performance and stability. Unsupported modules may degrade performance, cause errors or prevent the operating system from starting.

SKU	TS-1673AU-RP-16G
Model #	TS-1673AU-RP
Barcode #	885022019915
Brand	QNAP
Shipping Weight	17.5000kg
Shipping Width	0.430m
Shipping Height	0.370m
Shipping Length	0.130m
