Diskless eight-bay storage
The hot-swappable SATA bays support compatible 3.5-inch and 2.5-inch drives.
QNAP TS-832PXU-RP-4G 8 Bay Rackmount NAS (NO DISK) 4GB Ram
Model # TS-832PXU-RP-4G
-
SKU: TS-832PXU-RP-4G
$2,475.00
Stock Availability
🟢Live
ONLINE: ✓ In Stock
Vermont VIC: ✓ In Stock
(Click & Collect Available)
(Click & Collect Available)
You Might Want To Add
- Pick Up Available
- Australian Warranty
- Checkout Securely
8-bay 2U rackmount NAS with redundant power
QNAP TS-832PXU-RP-4G 8-Bay NAS with Dual 10GbE and Redundant PSU
A diskless 2U rackmount NAS with an AnnapurnaLabs Alpine AL324 quad-core processor, 4GB DDR4 memory, dual 10GbE SFP+, dual 2.5GbE, PCIe expansion and two 250W power supplies.
Diskless 8-bay NAS2 × 10GbE SFP+Dual 250W PSU3-year manufacturer warranty
What is the QNAP TS-832PXU-RP-4G?
The TS-832PXU-RP-4G is an eight-bay 2U rackmount NAS for centralised file storage, collaboration, backup, synchronisation and hybrid-cloud storage. Its redundant power supplies are designed to help maintain operation if one power unit becomes unavailable.
8 BaysDiskless hot-swappable SATA storage
2 × 10GbEBuilt-in SFP+ ports
2 × 2.5GbERJ45 multi-gigabit networking
2 × 250WRedundant power supplies
Need help choosing a NAS?
Read NAS Buying Guide Explore the DeviceDeal NAS Buying Guide
Compare NAS types, storage considerations and practical features before selecting your next network storage system.
Integrated 10GbE and 2.5GbE networking
Two 10GbE SFP+ ports provide high-bandwidth connectivity, while two 2.5GbE RJ45 ports support 2.5G, 1G, 100M and 10M speeds.
Wake on LAN is supported through the 2.5GbE ports, and Jumbo Frame support is included.
- The NAS includes four network interfaces in total.
- The 2.5GbE ports provide backward compatibility with common Ethernet speeds.
- Network resources can be allocated across file access, backup and collaboration workloads.
Backup, synchronisation and snapshot protection
Hybrid Backup Sync can back up and synchronise data to other NAS devices, servers and cloud storage. Boxafe is described for protecting Google Workspace and Microsoft 365 data.
Snapshots record system status and data to help protect files against accidental deletion and malware attacks.
- Cloud storage gateway support is supplied for hybrid-cloud deployment.
- Compatible QNAP TR RAID and TL JBOD units can expand storage capacity.
- SSD cache acceleration is supported.
Quad-core processing, memory and PCIe expansion
The AnnapurnaLabs Alpine AL324 64-bit ARM Cortex-A57 processor provides four cores at 1.7GHz. This configuration includes 4GB UDIMM DDR4 memory and supports up to 16GB.
One PCIe Gen 2 x2 slot supports compatible cards for networking, SSD caching or wireless connectivity.
- M.2 SSD support is optional through a compatible PCIe adapter.
- The supported card dimensions are 220 × 68.9 × 18.76mm.
- PCIe bandwidth limitations may restrict NAS 10GbE performance.
Redundant power for rackmount availability
The TS-832PXU-RP-4G includes two 250W redundant power supply units with 100-240V input.
The redundant design helps maintain NAS operation if one power supply becomes unavailable.
- The chassis is a 2U rackmount design.
- Two 70mm system fans are listed.
- The listed typical operating consumption is 69.191W with drives fully populated.
Important purchasing and deployment notes
- This is a diskless configuration; compatible hard drives or solid state drives must be purchased separately.
- M.2 SSD support is optional through a compatible PCIe adapter and M.2 hot swapping is not supported.
- The PCIe Gen 2 x2 interface can restrict high-speed expansion performance.
- Published transfer figures depend on the stated QNAP laboratory test configuration.
Frequently asked questions
What is the QNAP TS-832PXU-RP-4G?
It is a diskless eight-bay 2U rackmount NAS with a quad-core ARM processor, dual 10GbE SFP+, dual 2.5GbE and redundant power supplies.
Does it include storage drives?
No. The product information states that the NAS is supplied without storage drives.
Which drives are supported?
The eight hot-swappable bays support compatible 3.5-inch SATA hard drives, 2.5-inch SATA hard drives and 2.5-inch SATA solid state drives.
Which processor is installed?
It uses an AnnapurnaLabs Alpine AL324 64-bit ARM Cortex-A57 four-core processor running at 1.7GHz.
How much memory is installed and supported?
The NAS includes 4GB UDIMM DDR4 memory and supports up to 16GB using one 16GB module.
Which network ports are included?
It includes two 10GbE SFP+ ports and two 2.5GbE RJ45 ports.
Does it support Wake on LAN?
Yes. Wake on LAN is supported through the 2.5GbE ports according to the specification.
Can it use M.2 SSDs?
M.2 SSD support is optional through a compatible PCIe adapter, and M.2 SSD hot swapping is not supported.
What can be installed in the PCIe slot?
Compatible QNAP cards can add networking, SSD caching or wireless connectivity.
Can storage capacity be expanded?
Yes. Compatible QNAP TR RAID expansion enclosures and TL JBOD units are listed.
Does the TS-832PXU-RP-4G have redundant power?
Yes. It includes two 250W redundant power supply units with 100-240V input.
What warranty applies to the TS-832PXU-RP-4G?
This product is covered by a three-year QNAP manufacturer warranty.
(TS-832PXU-RP-4G)
Features and highlights
Key capabilities below are organised from the supplied product information for TS-832PXU-RP-4G.
Dual 10GbE SFP+
Two built-in SFP+ ports provide high-bandwidth network connectivity.
Dual 2.5GbE RJ45
Two multi-gigabit ports support Wake on LAN and common Ethernet speeds.
Expandable DDR4 memory
The installed 4GB UDIMM can be expanded to a maximum of 16GB.
Backup and snapshot tools
Hybrid Backup Sync, Boxafe and snapshot protection are described in the product information.
Redundant power supplies
Two 250W power supply units help maintain operation if one unit becomes unavailable.
Important: The NAS is supplied without drives. M.2 support requires a compatible PCIe adapter, and PCIe bandwidth can restrict optional high-speed expansion.
TS-832PXU-RP-4G specifications
Specifications below are organised from the supplied QNAP product information for TS-832PXU-RP-4G.
Processor and Memory
| CPU | AnnapurnaLabs Alpine AL324 64-bit ARM Cortex-A57 4-core 1.7GHz processor |
|---|---|
| CPU Architecture | 64-bit ARM |
| Floating Point Unit | Yes |
| Encryption Engine | Yes |
| System Memory | 4GB UDIMM DDR4 |
| Maximum Memory | 16GB (1 x 16GB) |
| Memory Slots | 1 x UDIMM DDR4 |
| Flash Memory | 512MB with dual-boot OS protection |
Storage
| Drive Bays | 8 x 3.5-inch SATA 6Gb/s, 3Gb/s The system is supplied without storage drives. |
|---|---|
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-Swappable | Yes M.2 SSD hot swapping is not supported. |
| M.2 Slots | Optional via a PCIe adapter |
| SSD Cache Acceleration Support | Yes |
Networking
| 2.5 Gigabit Ethernet | 2 x 2.5GbE RJ45 ports (2.5G/1G/100M/10M) |
|---|---|
| 10 Gigabit Ethernet | 2 x 10GbE SFP+ ports |
| Wake on LAN | Yes Supported through the 2.5GbE ports only. |
| Jumbo Frame | Yes |
Expansion and Connectivity
| PCIe Slots | 1 x PCIe Gen 2 x2 PCIe bandwidth limitations will restrict NAS 10GbE performance. Supported card dimensions: 220 x 68.9 x 18.76mm / 8.67 x 2.71 x 0.74 inches. |
|---|---|
| USB 3.2 Gen 1 Ports | 4 |
Physical Specifications
| Form Factor | 2U rackmount |
|---|---|
| LED Indicators | HDD 18, status, LAN and storage expansion |
| Buttons | Power and reset |
| Dimensions (H x W x D) | 88.6 x 432 x 511mm Excludes the ear hook and protruding part of the power supply unit. |
| Net Weight | 12.47kg |
| Gross Weight | 14.61kg |
Power and Cooling
| Power Supply Unit | 250W x 2 redundant power supply units, 100240V |
|---|---|
| Power Consumption: Typical Operating Mode | 69.191W Tested with drives fully populated. |
| Fans | 2 x 70mm, 12VDC |
| System Warning | Buzzer |
Operating Environment
| Operating Temperature | 040°C (32104°F) |
|---|---|
| Storage Temperature | -2070°C (-4158°F) |
| Relative Humidity | 595% RH non-condensing, wet bulb: 27°C (80.6°F) |
Warranty and Connections
| Standard Warranty | 3 years |
|---|---|
| Maximum Concurrent CIFS Connections | 700 with maximum memory installed |
Software and Data Protection
| Hybrid Backup Sync | Backs up and synchronises data to other NAS devices, servers and cloud storage. |
|---|---|
| Boxafe | Backs up Google Workspace and Microsoft 365 data. |
| Snapshots | Supported for recording system status and data. |
| Storage Expansion | Compatible QNAP TR RAID expansion enclosures and TL JBOD units are listed. |
Important Notes
| Drive status | The system is supplied without storage drives. |
|---|---|
| M.2 support | M.2 SSD support is optional through a compatible PCIe adapter; M.2 hot swapping is not supported. |
| PCIe bandwidth | PCIe bandwidth can restrict NAS 10GbE performance. |
| SKU | TS-832PXU-RP-4G |
| Model # | TS-832PXU-RP |
| Barcode # | 747464134123 |
| Brand | QNAP |
| Shipping Weight | 10.2000kg |
| Shipping Width | 0.260m |
| Shipping Height | 0.720m |
| Shipping Length | 0.560m |
3 YearsQNAP manufacturer warranty
3-year QNAP manufacturer warranty
The supplied specifications list a 3-year standard manufacturer warranty for the QNAP TS-832PXU-RP-4G.
Warranty coverage, eligibility and claim assessment are subject to QNAPs applicable warranty terms. Please retain your DeviceDeal tax invoice as proof of purchase.
