QNAP 6-BAY NAS (NO DISK) KX-U6580 8C 2.5GHz, 8GB
Model # TVS-675-8G
-
SKU: TVS-675-8G
- Pick Up Available
- Australian Warranty
- Checkout Securely
Six-bay x86 tower NAS with QTS or QuTS hero support
QNAP TVS-675-8G 6-Bay 2.5GbE 4K Tower NAS
The QNAP TVS-675-8G is a diskless six-bay tower NAS with a ZhaoXin KX-U6580 8-core processor, 8GB DDR4, dual 2.5GbE, two M.2 SSD slots, two PCIe Gen 3 expansion slots and HDMI 2.0 output.
Diskless6 bays8-core CPU4K at 60HzQNAP manufacturer warranty
What is the QNAP TVS-675-8G?
It is a six-bay x86 NAS for file backup, restoration, team collaboration, virtual machines, containers, hybrid cloud gateways and 4K HDMI display. The supplied content states that it supports QTS or QuTS hero.
Feature group 1
Flexible SATA and M.2 storage
Six front drive bays and two dedicated M.2 slots support capacity and SSD acceleration.
Six SATA bays
The hot-swappable bays support compatible 3.5-inch SATA hard drives and 2.5-inch SATA solid state drives.
Dual M.2 2280 slots
Each slot supports PCIe NVMe Gen 3 x1 or SATA 6Gb/s SSDs.
Storage technologies
SSD over-provisioning, SSD cache acceleration and Qtier auto-tiering are included in the supplied feature set.
Feature group 2
Networking and PCIe expansion
Built-in 2.5GbE and two PCIe slots support changing deployment requirements.
Dual 2.5GbE
Two ports support 2.5G, 1G and 100M speeds, with Port Trunking up to 5Gbps.
Optional faster networking
Compatible adapters can add 5GbE or 10GbE connectivity.
Two PCIe Gen 3 x4 slots
Compatible network, QM2 and QXP storage expansion cards are supported.
Need help choosing a NAS?
Read NAS Buying Guide
Explore the DeviceDeal NAS Buying Guide
Compare NAS types, storage planning considerations and practical buying factors before selecting a system.
Feature group 3
USB and 4K multimedia connectivity
Fast USB ports and HDMI output support direct device and display connections.
USB 3.2 Gen 2
Two Type-A ports provide speeds up to 10Gbps.
Additional USB ports
Two USB 3.2 Gen 1 ports are also included.
HDMI 2.0
Output supports up to 3840 × 2160 at 60Hz, with hardware-accelerated playback and real-time transcoding.
Feature group 4
QTS or QuTS hero workloads
The supplied content positions this NAS for business storage, virtualisation and hybrid-cloud use.
Virtual machines and containers
The NAS can host multiple virtual machines and containers.
Backup and collaboration
Listed uses include file backup, restoration and team collaboration.
Supplied QNAP Labs figures
The source lists 2 × 10GbE results of 2216MB/s read and 1118MB/s write, and 2 × 2.5GbE results of 591MB/s read and 588MB/s write. Test conditions are not supplied in this row.
Frequently asked questions
Does the QNAP TVS-675-8G include storage drives?
The supplied Name field identifies this as a no-disk configuration, so compatible drives must be installed separately.
Which operating systems does the TVS-675 support?
The supplied product information states that it supports either QTS or QuTS hero.
How many drive bays does it have?
It has six hot-swappable 3.5-inch SATA bays supporting compatible 3.5-inch SATA hard drives and 2.5-inch SATA SSDs.
Which processor is installed?
It uses a ZhaoXin KX-U6580 eight-core 2.5GHz processor.
How much memory is included and supported?
It includes 8GB SODIMM DDR4 memory and supports up to 64GB across two slots.
Which M.2 SSDs are supported?
The two M.2 2280 slots support PCIe NVMe Gen 3 x1 or SATA 6Gb/s SSDs.
What network ports are built in?
It includes two 2.5GbE RJ45 ports supporting 2.5G, 1G and 100M speeds.
Can 10GbE networking be added?
Yes. Compatible adapters can add optional 10GbE connectivity through PCIe expansion.
How many PCIe expansion slots are included?
It has two PCIe Gen 3 x4 slots.
Does it support 4K HDMI output?
Yes. HDMI 2.0 supports output up to 3840 × 2160 at 60Hz.
What performance figures are supplied?
The row lists QNAP Labs results of 2216/1118MB/s read/write with 2 × 10GbE and 591/588MB/s with 2 × 2.5GbE. Full test conditions are not supplied and results may vary.
What warranty applies to the TVS-675-8G?
The supplied specifications list a three-year QNAP manufacturer warranty. Coverage is subject to QNAPs applicable warranty terms.
(TVS-675-8G)
Features and highlights
Key product details organised from the supplied QNAP information for TVS-675-8G.
Diskless six-bay tower
Compatible SATA hard drives and 2.5-inch SATA SSDs can be installed separately.
Eight-core processor
The ZhaoXin KX-U6580 operates at 2.5GHz.
8GB expandable memory
Two SODIMM slots support up to 64GB DDR4.
Dual 2.5GbE
Port Trunking can provide up to 5Gbps aggregate transmission.
Dual M.2 slots
M.2 2280 NVMe Gen 3 x1 or SATA SSDs are supported.
4K HDMI 2.0
Local output supports up to 3840 × 2160 at 60Hz.
Purchase check: This is a no-disk configuration. Supplied 2 × 10GbE performance figures require optional network expansion because 10GbE is not built in.
Technical specifications
The following specifications are organised from the supplied product information for QNAP TVS-675-8G.
Product details
| Brand | QNAP |
|---|---|
| Model / SKU | TVS-675-8G |
| Product type | diskless six-bay tower NAS |
Processor and Memory
| CPU | ZhaoXin KX-U6580 8-core 2.5GHz processor |
|---|---|
| CPU Architecture | 64-bit x86 |
| Graphics Processor | ZhaoXin C-960 Graphics |
| Encryption Engine | Yes (AES-NI) |
| Hardware-Accelerated Transcoding | Yes |
| System Memory | 8GB SODIMM DDR4 |
| Maximum Memory | 64GB (2 × 32GB) |
| Memory Slots | 2 × SODIMM DDR4 For dual-DIMM configuration, use a pair of identical DDR4 modules. |
Storage
| Drive Bays | 6 × 3.5-inch SATA 6Gb/s, 3Gb/s |
|---|---|
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-Swappable | Yes Not supported for M.2 SSDs. |
| M.2 Slots | 2 × M.2 2280 PCIe Gen 3 x1 or SATA 6Gb/s slots Compatible with NVMe SSD PCIe Gen 3 and above. |
| SSD Cache Acceleration | Supported |
Networking
| 2.5 Gigabit Ethernet | 2 × 2.5GbE RJ45 ports (2.5G/1G/100M) |
|---|---|
| 5 Gigabit Ethernet | Optional via an adapter |
| 10 Gigabit Ethernet | Optional via an adapter |
| Wake on LAN | Yes Supported through the 2.5GbE ports only. |
| Jumbo Frame | Yes |
Expansion and Connectivity
| PCIe Slots | 2 Slot 1: PCIe Gen 3 x4 Slot 2: PCIe Gen 3 x4 Card dimensions for slots 12: 190 × 111.15 × 18.76mm / 7.48 × 4.38 × 0.74 inches. Wider cards can be installed if the next PCIe slot is not used. |
|---|---|
| USB 3.2 Gen 1 Ports | 2 |
| USB 3.2 Gen 2 Ports | 2 × Type-A (10Gbps) |
| HDMI Output | 1 × HDMI 2.0, up to 3840 × 2160 at 60Hz |
Physical Specifications
| Form Factor | Tower |
|---|---|
| LED Indicators | HDD 16, Status, LAN, USB, M.2 SSD 12 |
| Buttons | Power, Reset, USB Copy |
| Dimensions (H × W × D) | 180.2 × 264.3 × 279.6mm Dimensions do not include the foot pad, which may be up to 30mm / 1.18 inches high depending on model. |
| Net Weight | 7kg |
| Gross Weight | 7.8kg |
| Kensington Security Slot | Yes |
Power and Cooling
| Power Supply Unit | 250W, 100240V AC, 50/60Hz, 3.5A |
|---|---|
| Power Consumption Disk Standby | 41.897W |
| Power Consumption Typical Operating | 60.794W |
| Fans | 3 × 80mm, 12VDC |
| System Warning | Buzzer |
Operating Environment
| Operating Temperature | 040°C (32104°F) |
|---|---|
| Storage Temperature | -2070°C (-4158°F) |
| Relative Humidity | 595% RH non-condensing, wet bulb: 27°C (80.6°F) |
Warranty and Connections
| Standard Warranty | 3 years |
|---|---|
| Maximum Concurrent CIFS Connections | 2000 with maximum memory installed |
| SKU | TVS-675-8G |
| Model # | TVS-675 |
| Barcode # | 885022021604 |
| Brand | QNAP |
| Shipping Weight | 7.7000kg |
| Shipping Width | 0.270m |
| Shipping Height | 0.280m |
| Shipping Length | 0.190m |
Three yearsQNAP manufacturer warranty
3-year QNAP manufacturer warranty
The supplied specifications list a 3-year manufacturer warranty for QNAP TVS-675-8G.
Warranty coverage, eligibility and claim assessment are subject to QNAPs applicable warranty terms. Please retain your DeviceDeal tax invoice as proof of purchase.
