With 5 x E1.S NVMe 3.84TB

QNAP TBS-h574TX-i5-16G
5-bay All-Flash NASbook; Intel Core i5-1340PE 12C(4P+8E)/16T up to 4.50GHz, onboard 16GB RAM (not expandable), 5 x E1.S up to 15mm ( or 5 x M.2 2280 PCIe w/ QDA-E1SM ), 1 x 10GBASE-T + 1 x 2.5GbE, 1 x HDMI 1.4b, 2 x USB 3.2 Gen2 Type-A + 1 x USB 2.0, 2 x Thunderbolt 4

TBS-h574TX is a Thunderbolt™ 4 all-flash NASbook designed for on-location shoots, small studios, small-scale video production teams, and SOHO users. Featuring an Intel® Core™ processor and high-speed I/O, TBS-h574TX enables online editing, visual effects (VFX), file transfer and backup for both Mac® and Windows® creators. Hot-swappable SSD support also ensures uninterrupted project flows. Pre-installed with QuTS hero OS, it supports ZFS data integrity, immutability, and advanced SSD optimization technologies.

Now available in two models pre-installed with QNAP enterprise-grade E1.S NVMe SSDs (9.6 TB and 19.2 TB in total).

• E1.S SSD: Workflow continuity

  Hot-swappable E1.S SSDs allow instant replacement without downtime in the event of failure.

• Flexible M.2 SSD upgrades

  Optional E1.S to M.2 SSD adapter enables hot-swappable M.2 SSD installation. Supports up to five M.2 PCIe NVMe SSDs.

• Thunderbolt™ 4 for faster direct connections

  Two Thunderbolt™ 4 ports allow directly connecting Mac®/PC workstations to the TBS-h574TX, delivering up to 20Gbps for 4K video editing.

• Hybrid-architecture CPU for multitasking

  Intel® Core™ processors with hybrid-architecture (P-core and E-core) delivers high performance and efficiency.

• 2.5GbE and 10GbE as standard

  2.5GbE and 10GbE networks accelerate large file transfer and allow for more connected devices/workstations by attaching a network switch.

• Faster USB transfer

  Two USB 3.2 Gen 2 (10Gbps) ports enable fast file import/export from/to external storage devices.

All-flash NASbook supporting E1.S SSDs – a perfect companion for video production
Compared to large rackmount all-flash array storage, the TBS-h574TX all-flash NASbook provides five SSD slots in a compact and portable design. Its high-speed read/write performance is specifically tailored for video editors and VFX professionals. Equipped with QNAP enterprise-grade E1.S SSDs, users benefit from a robust combination of performance, stability, and data security. The TBS-h574TX seamlessly works with USB DAS (such as TR-004) for efficient file backup and archiving, that keeps it in optimal condition for a seamless flow into every creative challenge.

Option 1: Configured with five 1.92 TB E1.S SSDs
Total usable storage per system

up to 9.6 TB

Option 2: Configured with five 3.84 TB E1.S SSDs
Total usable storage per system

up to 19.2 TB

Maximize uptime with hot-swappable E1.S / M.2 SSD
Frontline video production teams are sometimes at risk of project interruptions due to unexpected SSD failures in storage devices. The TBS-h574TX supports hot-swappable SSDs, along with conditional automatic RAID replacement with spares. If an SSD enters a critical state, the system automatically moves data from the affected drive to a spare in the RAID group, seamlessly integrating it into the existing RAID without the need for RAID rebuilding. This significantly reduces the risk of data loss.

Hot-swappable E1.S SSD: Future-proof storage
The TBS-h574TX supports hot-swappable E1.S SSDs, providing reliable high-density data transfer with optimal cooling efficiency and making it perfect for accommodating future storage needs.

Hot-swappable M.2 SSD: Agile innovation
An optional E1.S to M.2 adapter allows M.2 SSDs to become hot-swappable. This enables replacing SSDs without downtime and enhances system maintenance flexibility.

Seamlessly compatibility
Tested for reliability and seamless integration with QNAP NAS for peak performance.

High-speed and low latency
Up to 70,000 IOPS (4K random write) boosts the efficiency of VFX editing and small file access.

Long-lasting durability
Designed for 24/7 high-intensity read/write workloads with extended lifespan.

5-year warranty
QNAP E1.S SSDs backed by a 5-year limited warranty for long-term reliability and peace of mind.

The warranty is void if the SSD's TBW exceeds the specified product limit.

Power loss protection
Supports PLP (Power Loss Protection) to prevent data loss or corruption during unexpected power outages.

Self-encryption
TCG Opal SED hardware encryption protects confidential files from unauthorized access.

High-performance SSDs. Effective heat dissipation.
Designed with an excellent cooling system, the TBS-h574TX is equipped with dual fans and supports SSD heatsinks (heatsinks sold separately) to effectively enhance heat dissipation during intensive workloads, allowing creators to confidently enjoy the ultimate performance of SSD.

M.2 / E1.S SSD may overheat and suffer decreased performance during high-speed operations. It is recommended to purchase and install heatsinks on SSD controllers to enhance heat dissipation for stable high-speed transfer performance.

Thunderbolt™ 4 direct connection to workstations for higher productivity
The TBS-h574TX has two Thunderbolt™ 4 ports for high-speed data transfer (up to 20Gbps bandwidth). Mac® (including M1 and M2 chip models) or Windows® workstations can directly connect to the TBS-h574TX for fast and smooth real-time video editing, allowing for the transfer of a 1TB 4K video just in 11 minutes.

Notes:
• QNAP Thunderbolt NAS adopts Thunderbolt Networking for peer-to-peer connection, up to 20Gbps.
• Mac® system requirement: macOS 13.5 (or later)
• Connect the TBS-h574TX to your Mac® or Windows® PC with Thunderbolt™ 4 / Thunderbolt™ 3 cables and your connected devices with the Thunderbolt icon

Transmission efficiency
TBS-h574TX (1 x Direct connected client)    Write
1393 MB/s
Read
1410 MB/s
Tested in QNAP Labs. Figures may vary by environment.
NAS: TBS-h574TX-i5UC-05S02
CPU: Intel® Core™ i5-1235U 10-core(2P+8E), up to 4.4GHz
OS: QuTS hero h5.2.3.2970 Build 20241203
Volume Type: 5 x QNAP 3.84TB E1.S NVMe PCIe Gen4 x4 SSD, RAID 5
Client PC：PC 1 – Intel i9-12900E, 64G RAM, 2 x Thunderbolt 4, Windows server 2019

Diverse I/O, greater possibilities.

2.5GbE and 10GbE ports | Productive teamwork
The 2.5GbE and 10GbE ports can be used with a network switch to add more connected devices to the TBS-h574TX for collaboration, significantly reducing file transfer times across devices.

USB 3.2 Gen 2 ports | Faster file import/export
Creators and editors can easily import materials from external storage devices to the TBS-h574TX via two USB 3.2 Gen 2 (10Gbps) ports and one USB 2.0 port during pre-/post-production.

USB ports | Easier storage expansion
The TBS-h574TX capacity is scalable by connecting QNAP USB DAS TR-004 or USB JBOD TL-D800C to archive massive number of video files for ever-growing storage and backup needs.

Compact, aesthetic, yet unmatched performance
The TBS-h574TX provides content creators the perfect combination of stylish design and performance. With its metal-finish case, it delivers optimized cooling performance. The set-top design makes the TBS-h574TX space-saving – smaller than A4 paper and with only 2.54 liters in volume – ideal for small-scale studios or video production teams looking for a portable solution.

Next-gen Intel® Core™ processors with hybrid architecture for multitasking potential
The TBS-h574TX adopts Intel® Core™ hybrid-architecture processor with P-core (Performance-core) and E-core (Efficient-core) performance. Multi-core and multi-thread advantages enable higher multitasking performance with lower CPU workloads and resource consumption, empowering creators with higher productivity.

Processor
Intel® Core™ i5-1235U 10-core (2P+8E) and 12-thread processor, up to 4.4 GHz

Memory
Built-in 16GB DDR4 memory

GPU
Built-in Intel® Iris® Xe Graphics accelerate video processing and graphical computing

Encryption Engine
Features Intel® AES-NI 256 hardware-accelerated encryption to boost system performance while securing sensitive data

Ultimate visual experience with real-time video transcoding and 4K HDMI™ output
The TBS-h574TX features built-in Intel® Graphics that accelerates video transcoding and graphical computing for converting videos to different formats smoothly. You can also display videos from the TBS-h574TX to a large screen using HDMI™ (4K @30Hz) for capturing details and clearer quality.

The TBS-h574TX provides hardware decoding, encoding and transcoding capabilities. However, playback quality may vary due to factors (including playback software, file formats, system usage, and available bandwidth). H.265 hardware transcoding requires installing CAYIN MediaSign Player with a Plus license.

Double your protection with hybrid cloud:
Backup to myQNAPcloud Storage and access anytime
Back up your TBS-h574TX to myQNAPcloud Storage using Hybrid Backup Sync for secure, efficient data management—without any additional bandwidth fees.
The TBS-h574TX also supports 20+ major public clouds, ensuring near-LAN access speeds for seamless cloud sharing and multi-point synchronization.

ZFS-based QuTS hero operating system unleashes SSD performance, reliability and endurance
Learn More: QuTS hero operating system, SSD Extra over-provisioning optimizes SSD performance

Self-healing | Ensure data integrity
ZFS supports Self-healing to detect, correct, and prevent silent data corruption, ensuring the integrity of media files.

QSAL (QNAP SSD Antiwear Leveling) | Enhance data protection
QNAP’s patented QSAL algorithm prevents simultaneous multi-SSD failures in an SSD RAID for greater data protection and system reliability.

SSD Extra Over-provisioning | Unleash SSD performance
Resolves SSD write performance degradation and write amplification. By configuring extra Over-provisioning for an SSD RAID, it improves random write performance and mitigates write amplification, thus extending SSD lifespans.

Power Failure Protection | Bolster data security
The QuTS hero operating system ensures that the TBS-h574TX can continue completing unfinished data writes after power outage followed by a power restoration, preventing data corruption while modifying data and without the need to wait for file system check.
