Eight-bay storage platform
The SATA bays support compatible 3.5-inch and 2.5-inch storage drives.
QNAP TS-832PX-4G High Capacity 8-Bay NAS with 10GbE SFP + and 2.5GbE
Model # TS-832PX-4G
-
SKU: TS-832PX-4G
- Pick Up Available
- Australian Warranty
- Checkout Securely
high-capacity 8-bay multi-gigabit NAS
QNAP TS-832PX-4G 8-Bay NAS with Dual 10GbE SFP+ and 2.5GbE
An eight-bay tower NAS with an AnnapurnaLabs Alpine AL324 quad-core processor, 4GB DDR4 memory, dual 10GbE SFP+, dual 2.5GbE and PCIe expansion for storage, backup and sharing.
8-bay tower NAS2 × 10GbE SFP+2 × 2.5GbE2-year manufacturer warranty
What is the QNAP TS-832PX-4G?
The TS-832PX-4G is a high-capacity eight-bay tower NAS for file storage, backup, sharing and hybrid-cloud workflows. It combines four high-speed network ports, snapshot support, Qtier and SSD-cache capabilities with PCIe and external expansion options.
8 BaysSATA 6Gb/s and 3Gb/s
2 × 10GbEBuilt-in SFP+ ports
2 × 2.5GbERJ45 multi-gigabit ports
Up to 16GBSingle DDR4 memory slot
Need help choosing a NAS?
Read NAS Buying Guide Explore the DeviceDeal NAS Buying Guide
Compare NAS types, storage considerations and practical features before selecting your next network storage system.
Dual 10GbE SFP+ and dual 2.5GbE networking
Two built-in 10GbE SFP+ ports provide high-bandwidth connectivity, while two 2.5GbE RJ45 ports support 2.5G, 1G, 100M and 10M speeds.
Port Trunking and Failover are described in the product information, and Wake on LAN is supported through the 2.5GbE ports.
295MB/s writeSupplied result using one 2.5GbE connection; read result 254MB/s
589MB/s writeSupplied result using two 2.5GbE connections; read result 490MB/s
2,349MB/s readSupplied result using two 10GbE connections; write result 814MB/s
The figures were measured in the stated QNAP Labs environment and may vary with drives, RAID, client and network configuration.
Quad-core ARM processing and expandable memory
The AnnapurnaLabs Alpine AL324 64-bit ARM Cortex-A57 processor provides four cores at 1.7GHz. This configuration includes 4GB DDR4 memory and supports up to 16GB through one SODIMM slot.
The specifications list hardware encryption and a maximum of 700 concurrent CIFS connections with maximum memory installed.
- Eight drive bays support compatible 3.5-inch and 2.5-inch SATA drives.
- Hot swapping is supported for the main drive bays.
- Confirm the configured package for drive inclusion.
PCIe expansion, SSD caching and storage optimisation
One PCIe Gen 2 x2 slot supports compatible expansion cards for networking, M.2 SSD caching, wireless networking or additional USB connectivity.
Qtier auto-tiering and SSD cache acceleration are supported, while compatible QNAP TR RAID enclosures and TL JBOD units can expand capacity.
- M.2 slots are optional through a compatible PCIe adapter.
- PCIe bandwidth limitations may restrict NAS 10GbE performance.
- Three USB 3.2 Gen 1 ports are included.
Snapshots, hybrid cloud and SMB signing
Snapshots record system status to help protect files and data from accidental deletion and malware attacks. Cloud storage gateways can work with NAS cache space for lower-latency access to cloud data.
The product information states that QTS 5.1.0 supports AES-128-GMAC SMB signing acceleration for Windows Server 2022 and Windows 11 clients using SMB 3.1.1.
- Microsoft Hyper-V certification is listed in the product information.
- Qtier and SSD caching support continuous storage optimisation.
- Compatible expansion enclosures can increase storage capacity.
Important purchasing and deployment notes
- Confirm the configured package and whether storage drives are included before purchase.
- M.2 SSD support requires a compatible PCIe adapter and M.2 SSD hot swapping is not supported.
- The PCIe Gen 2 x2 interface can restrict the performance of optional high-speed expansion.
- Published transfer figures depend on the stated QNAP Labs test environment.
Frequently asked questions
What is the QNAP TS-832PX-4G?
It is an eight-bay tower NAS with a quad-core ARM processor, 4GB memory, dual 10GbE SFP+, dual 2.5GbE and PCIe expansion.
How many drive bays does the TS-832PX-4G have?
It has eight 3.5-inch SATA 6Gb/s and 3Gb/s bays supporting compatible 3.5-inch hard drives, 2.5-inch hard drives and 2.5-inch solid state drives.
Which processor is installed?
It uses an AnnapurnaLabs Alpine AL324 64-bit ARM Cortex-A57 four-core processor running at 1.7GHz.
Can the memory be upgraded?
Yes. This configuration includes 4GB DDR4 memory and supports up to 16GB through its single SODIMM slot.
Which network ports are included?
It includes two 10GbE SFP+ ports and two 2.5GbE RJ45 ports.
Does it support Port Trunking and network failover?
Yes. Both Port Trunking and Failover are described in the product information.
Can the TS-832PX use M.2 SSDs?
M.2 SSD slots are optional through a compatible PCIe adapter, such as a supported QM2 card.
What can be added through the PCIe slot?
Compatible cards can add M.2 SSD caching, network connectivity, wireless networking or additional USB connectivity.
Does the TS-832PX support snapshots?
Yes. Snapshots can record system status and help protect data from accidental deletion and malware attacks.
Can its storage capacity be expanded?
Yes. Compatible QNAP TR RAID expansion enclosures and TL JBOD units are listed for capacity expansion.
Which virtualisation certification is listed?
Microsoft Hyper-V certification is listed in the product information.
What warranty applies to the TS-832PX-4G?
This product is covered by a two-year QNAP manufacturer warranty.
(TS-832PX-4G)
Features and highlights
Key capabilities below are organised from the supplied product information for TS-832PX-4G.
Dual 10GbE SFP+
Two built-in SFP+ ports provide high-bandwidth connectivity for data-intensive workloads.
Dual 2.5GbE RJ45
Two multi-gigabit ports support Port Trunking, Failover and Wake on LAN.
Expandable DDR4 memory
The installed 4GB memory can be expanded to a maximum of 16GB.
PCIe expansion
One PCIe Gen 2 x2 slot supports compatible networking, M.2 caching, wireless or USB cards.
Snapshots and hybrid cloud
Supplied software capabilities include snapshots, cloud storage gateways, Qtier and SSD caching.
Important: Check the configured package for drive inclusion. M.2 support requires a compatible PCIe adapter, and PCIe bandwidth can restrict expansion performance.
TS-832PX-4G specifications
Specifications below are organised from the supplied QNAP product information for TS-832PX-4G.
Processor and Memory
| CPU | AnnapurnaLabs Alpine AL324 ARM Cortex-A57 4-core 1.7GHz processor |
|---|---|
| CPU Architecture | 64-bit ARM |
| Encryption Engine | Yes |
| System Memory | 4GB SODIMM DDR4 |
| Maximum Memory | 16GB (1 x 16GB) |
| Memory Slots | 1 x SODIMM DDR4 |
Storage
| Drive Bays | 8 x 3.5-inch SATA 6Gb/s, 3Gb/s |
|---|---|
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Hot-Swappable | Yes Not supported for M.2 SSDs. |
| M.2 Slots | Optional via a PCIe adapter |
| SSD Cache Acceleration Support | Yes |
Networking
| 2.5 Gigabit Ethernet | 2 x 2.5GbE RJ45 ports (2.5G/1G/100M/10M) |
|---|---|
| 10 Gigabit Ethernet | 2 x 10GbE SFP+ |
| Wake on LAN | Yes Supported through the 2.5GbE ports only. |
| Jumbo Frame | Yes |
Expansion and Connectivity
| PCIe Slots | 1 x PCIe Gen 2 x2 PCIe bandwidth limitations will restrict NAS 10GbE performance. Maximum card dimensions: 210 x 68.9 x 24.76mm / 8.27 x 2.71 x 0.97 inches. |
|---|---|
| USB Ports | 3 x USB 3.2 Gen 1 ports |
Physical Specifications
| Form Factor | Tower |
|---|---|
| LED Indicators | System status, LAN, USB and HDD 1-8 |
| Buttons | Power, reset and USB Copy |
| Dimensions (H x W x D) | 180.2 x 329.3 x 280.8mm Dimensions do not include the foot pad, which may be up to 30mm / 1.18 inches high depending on model. |
| Net Weight | 7.05kg |
| Gross Weight | 8kg |
| Kensington Security Slot | Yes |
Power and Cooling
| Power Supply Unit | 250W, 100-240V AC, 50/60Hz, 3.5A |
|---|---|
| Disk Standby Power Consumption | 27.949W |
| Typical Operating Power Consumption | 50.858W Tested with drives fully populated. |
| Fans | System fan: 2 x 120mm, 12VDC CPU fan: 1 x 60mm |
| System Warning | Voice prompts or buzzer |
Operating Environment
| Operating Temperature | 0-40°C (32-104°F) |
|---|---|
| Storage Temperature | -20-70°C (-4-158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
Warranty and Connections
| Standard Warranty | 2 years |
|---|---|
| Maximum Concurrent CIFS Connections | 700 with maximum memory installed |
Software and Expansion
| Snapshots | Supported. |
|---|---|
| Storage Optimisation | Qtier auto-tiering and SSD cache acceleration are supported. |
| Storage Expansion | Compatible QNAP TR RAID expansion enclosures and TL JBOD units are listed. |
| Virtualisation Certification | Microsoft Hyper-V |
Important Notes
| Drive inclusion | Confirm the configured package for drive inclusion. |
|---|---|
| M.2 support | M.2 slots are optional through a compatible PCIe adapter. |
| PCIe bandwidth | PCIe bandwidth can restrict NAS 10GbE performance. |
| SKU | TS-832PX-4G |
| Model # | TS-832PX |
| Barcode # | 4713213518182 |
| Brand | QNAP |
| Shipping Weight | 8.0000kg |
| Shipping Width | 0.420m |
| Shipping Height | 0.300m |
| Shipping Length | 0.400m |
| Shipping Cubic | 0.050400000m3 |
2 YearsQNAP manufacturer warranty
2-year QNAP manufacturer warranty
The supplied specifications list a 2-year standard manufacturer warranty for the QNAP TS-832PX-4G.
Warranty coverage, eligibility and claim assessment are subject to QNAPs applicable warranty terms. Please retain your DeviceDeal tax invoice as proof of purchase.
