QNAP TS-H765EU-8G ,4-Bay Intel Atom x7405C 4-core, up to 3.4GHz ,8GB DDR5 ,NAS Enclosure
Model # TS-H765EU-8G
-
SKU: TS-H765EU-8G
$1,719.00
Stock Availability
🟢Live
ONLINE: ✓ In Stock
Vermont VIC: ✓ In Stock
(Click & Collect Available)
(Click & Collect Available)
- Pick Up Available
- Australian Warranty
- Checkout Securely
292.1mm short-depth 1U QuTS hero NAS
QNAP TS-h765eU-8G 4+3-Bay Short-Depth DDR5 2.5GbE NAS
The QNAP TS-h765eU-8G is a 292.1mm short-depth 1U NAS with four SATA bays, three E1.S slots with pre-installed M.2 2280 adapters, an Intel® Atom x7405C processor, 8GB DDR5 and dual 2.5GbE.
292.1mm depth4 + 3 bays8GB DDR5Dual 2.5GbEQNAP manufacturer warranty
What is the QNAP TS-h765eU-8G?
It is a compact QuTS hero rackmount NAS for installations where rack depth is limited. The supplied configuration combines four SATA bays, three flexible E1.S/M.2 NVMe positions and optional dual 10GbE expansion.
Feature group 1
Short-depth rack design
The compact chassis is intended for locations where installation depth is restricted.
Compact dimensions
The supplied dimensions are 43 × 430 × 292.1mm.
Deployment examples
The supplied content lists small media cabinets, wall-mount network racks, factories, small offices, surveillance rooms, audiovisual rooms and in-vehicle applications.
1U form factor
The rackmount chassis uses a 1U short-depth design.
Feature group 2
Processor, memory and protection
Intel® Atom processing and DDR5 memory support storage and multitasking workloads.
Intel® Atom x7405C
The processor provides four cores and speeds up to 3.4GHz.
DDR5 with In-Band ECC
The installed 8GB SODIMM DDR5 has In-Band ECC enabled and supports expansion to 16GB.
QuTS hero
The ZFS-based operating system supports data integrity and WORM protection for data immutability.
Need help choosing a NAS?
Read NAS Buying Guide
Explore the DeviceDeal NAS Buying Guide
Compare NAS types, storage planning considerations and practical buying factors before selecting a system.
Feature group 3
Flexible SATA, E1.S and M.2 storage
Four SATA bays and three flexible NVMe positions provide mixed storage options.
Four SATA bays
The bays support compatible 3.5-inch SATA hard drives and 2.5-inch SATA solid state drives.
Three E1.S slots
Each E1.S slot includes a pre-installed adapter for an M.2 2280 NVMe PCIe SSD.
Hot-swap limitation
The drive bays are hot-swappable, but M.2 SSD hot swapping is not supported.
Feature group 4
Networking and expansion
Dual 2.5GbE is standard, with optional E1.S-based 10GbE and USB storage expansion.
Dual 2.5GbE
Port Trunking or SMB Multichannel can combine the two built-in ports.
Optional dual 10GbE
Up to two optional QXG-ES10G1T modules can be installed in the E1.S slots.
Conditional capacity example
The supplied information gives an example of up to 144TB using a TR-004U, 24TB hard drives and RAID 5.
Frequently asked questions
What is the QNAP TS-h765eU-8G?
It is a 292.1mm short-depth 1U QuTS hero NAS with four SATA bays, three E1.S/M.2 NVMe positions, 8GB DDR5 and dual 2.5GbE.
How deep is the TS-h765eU-8G?
Its chassis depth is 292.1mm, with supplied dimensions of 43 × 430 × 292.1mm.
How are the storage positions configured?
It has four 3.5-inch SATA bays and three E1.S slots, each with a pre-installed adapter for an M.2 2280 NVMe PCIe SSD.
Which drive types are supported?
The SATA bays support compatible 3.5-inch SATA hard drives and 2.5-inch SATA SSDs. The other slots support E1.S NVMe PCIe SSDs and M.2 2280 NVMe PCIe SSDs.
Are M.2 SSDs hot-swappable?
No. The supplied specification states that M.2 SSD hot swapping is not supported.
Which processor is installed?
It uses an Intel® Atom x7405C four-core processor operating at up to 3.4GHz.
How much memory is included?
It includes 8GB SODIMM DDR5 with In-Band ECC enabled and supports a maximum of 16GB.
What network ports are built in?
It includes two 2.5GbE ports supporting 2.5G, 1G, 100M and 10M speeds.
Can 10GbE networking be added?
Yes. Up to two optional QXG-ES10G1T modules can be installed in the E1.S slots.
Can storage capacity be expanded externally?
Yes. The supplied content gives a conditional example using a short-depth TR-004U USB JBOD, 24TB hard drives and RAID 5.
Which operating system does it use?
It runs the ZFS-based QuTS hero operating system with data-integrity and WORM-protection features.
What warranty applies to the TS-h765eU-8G?
The supplied specifications list a three-year QNAP manufacturer warranty. Coverage is subject to QNAPs applicable warranty terms.
(TS-H765EU-8G)
Features and highlights
Key product details organised from the supplied QNAP information for TS-h765eU-8G.
292.1mm short depth
The 1U chassis is designed for compact rack and cabinet installations.
Intel® Atom x7405C
Four-core processing operates at up to 3.4GHz.
8GB DDR5
Installed SODIMM memory has In-Band ECC enabled and supports up to 16GB.
Four SATA bays
Compatible 3.5-inch SATA HDDs and 2.5-inch SATA SSDs are supported.
Three flexible NVMe slots
E1.S slots include pre-installed M.2 2280 adapters.
Dual 2.5GbE
Optional QXG-ES10G1T modules can add up to two 10GbE ports.
Purchase check: M.2 SSD hot swapping is not supported. Optional QXG-ES10G1T modules and any external expansion enclosure are purchased separately.
Technical specifications
The following specifications are organised from the supplied product information for QNAP TS-h765eU-8G.
Product details
| Brand | QNAP |
|---|---|
| Model / SKU | TS-H765EU-8G |
| Product type | 4+3-bay short-depth 1U rackmount NAS |
Processor and Memory
| CPU | Intel® Atom x7405C 4-core, up to 3.4GHz |
|---|---|
| CPU Architecture | 64-bit x86 |
| Encryption Engine | Yes (AES-NI) |
| System Memory | 8GB SODIMM DDR5, enabled in-band ECC |
| Maximum Memory | 16GB (1 x 16GB) |
| Memory Slot | 1 x SODIMM DDR5 |
Storage
| Drive Bays | 4 x 3.5-inch SATA 6Gb/s, 3Gb/s 3 x E1.S up to 15mm A pre-installed adapter supports M.2 2280 in each E1.S slot. |
|---|---|
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives E1.S NVMe PCIe SSDs M.2 2280 NVMe PCIe SSDs |
| Hot-Swappable | Yes Hot-swapping is not supported for M.2 SSDs. |
| M.2 Slot | 3 x E1.S up to 15mm A pre-installed adapter supports M.2 2280 in each slot. |
| SSD Cache Acceleration Support | Yes |
Networking
| 2.5 Gigabit Ethernet | 2 x 2.5GbE ports (2.5G/1G/100M/10M) |
|---|---|
| 10 Gigabit Ethernet | Optional via QXG-ES10G1T |
| Wake on LAN | Yes |
| Jumbo Frame | Yes |
Connectivity and Controls
| USB 2.0 Port | 1 |
|---|---|
| USB 3.2 Gen 2 Port | 1 x Type-A USB 3.2 Gen 2, 10Gbps |
| LED Indicators | Power/Status, LAN, USB, HDD 14, E1.S/PCIe SSD 13 |
| Buttons | Power, Reset |
Physical Specifications
| Form Factor | 1U short-depth rackmount |
|---|---|
| Dimensions (H x W x D) | 43 x 430 x 292.1mm |
| Net Weight | 4.51kg |
Power and Cooling
| Power Supply Unit | 150W, 100240V |
|---|---|
| Fan | 3 x 40mm |
| System Warning | Buzzer |
Operating Environment
| Operating Temperature | 040°C (32104°F) |
|---|---|
| Storage Temperature | -2070°C (-4158°F) |
| Relative Humidity | 595% RH non-condensing, wet bulb: 27°C (80.6°F) |
Warranty and Connections
| Standard Warranty | 3 years |
|---|---|
| Maximum Concurrent CIFS Connections | 1,500 with maximum memory installed |
| SKU | TS-H765EU-8G |
| Barcode # | 885022028146 |
| Brand | QNAP |
| Shipping Weight | 4.5000kg |
Three yearsQNAP manufacturer warranty
3-year QNAP manufacturer warranty
The supplied specifications list a 3-year manufacturer warranty for QNAP TS-h765eU-8G.
Warranty coverage, eligibility and claim assessment are subject to QNAPs applicable warranty terms. Please retain your DeviceDeal tax invoice as proof of purchase.
