The DS51072 5-Port Ethernet Network Switch enables up to 5 users to share files and devices (e.g. printers, scanners) over a LAN connection, by expanding an existing network's capacity with additional ports.

Compatible with both 10Base-T (10 Mbps) and 100Base-TX (100Mbps) networks, this Fast Ethernet switch can automatically detect the type of network (auto- negotiation) as well as the type of cable (auto MDIX) and configure itself, making for an easy to install, Plug-and-Play networking solution.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.


Applications

  • For use as a Home Network Switch or for SOHO users who need to expand on the number of ports of an existing router/switch
  • Users who want to create a small local network of computers for data transfer/sharing, streaming or gaming
  • Network multiple devices in different rooms together with a single UTP Ethernet cable between locations

The StarTech.com Advantage

  • This 5-port Ethernet switch automatically detects and configures for network speed, duplex and cable type on each port, for a Plug-and-Play installation and setup
  • The switch features easily-accessed top-mounted LED indicators, and can be wall-mounted or placed on a desktop
  • The network switch uses a simple, fanless design for quiet and energy-efficient operation

(DS51072)

Warranty Information
Warranty 2 Years
Hardware
Chipset ID Atheros - AR8236
Industry Standards IEEE 802.3, IEEE 802.3u
Ports 5
Performance
Auto MDIX Yes
Flow Control IEEE 802.3x
Full Duplex Support Yes
MAC Address Automatic learning, Automatic aging
Maximum Cable Length 328 ft [100 m]
Maximum Data Transfer Rate 100 Mbps
Supported Protocols CSMA/CD
Switching Architecture Store and Forward
Connector(s)
External Ports 5 - RJ-45 Female
Software
OS Compatibility OS Independent; No additional drivers or software required
Indicators
LED Indicators 1 - Power (green)
5 - Link/ Activity (green)
Power
Input Current 0.3 A
Input Voltage 100 - 240 AC
Output Current 0.6A
Output Voltage 5 DC
Plug Type H
Power Consumption (In Watts) 3
Power Source AC Adapter Included
Environmental
Humidity 10 ~ 90% RH
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Physical Characteristics
Color Black
Enclosure Type Plastic
Product Height 1 in [2.5 cm]
Product Length 5.5 in [14 cm]
Product Width 3.5 in [90 mm]
Weight of Product 4 oz [113 g]
Packaging Information
Package Height 2.6 in [65 mm]
Package Length 8.1 in [20.5 cm]
Package Width 6.5 in [16.6 cm]
Shipping (Package) Weight 11.1 oz [315 g]
What's in the Box
Included in Package 1 - Power Adapter
1 - Instruction Manual
1 - Ethernet Switch
SKU DS51072
Barcode # 65030848213
Brand Startech
Shipping Weight 0.5000kg
Manufacturer Warranty: 2 Years Limited Warranty
